LED and Interface Explanation
Data/PoE
AC socket
DATA input
P+DATA output
Specifications
Model
Output voltage
PoE power
Standard
Pin Polarity
Data rates
Input power
requirements
Dimensions
Indicators
Connectors
Protection
Environmental
conditions
Green PoE injector got 100-240V power input.
The terminal equipment connected to P+DATA port is
Red
powered.
Connect with AC cable.
Connect to the ethernet device with cable to transmit data.
Connect to the PD device with UTP cable to supply power.
POE150
50V DC
Max. 15.4W
802.3af
1/2 (-), 3/6 (+)
10/100/1000 Mbps
AC input voltage: 100 to 240 V AC
AC input current: 0.5A 100-240 V AC
AC frequency: 50-60 Hz
121×50×36 mm
System indicator: AC power
User indicator: Channel power
Shielded RJ-45, EIA 568A and 568B
Overcurrent protection
Overload protection
Overvoltage protection
Anti-interference protection
Operating temperature: 0 to 40 °C
Operating humidity: max. 85%
Storage temperature: -40 to 60 °C
POE200
54V DC
Max. 30W
802.3af/at
5
