Product Introduction - Sonoff BASICR2/RFR2 Betriebsanweisung

SONOFF TECHNOLOGIES CO., LTD.
Compatible Pairing Mode
If you fail to enter Quick Pairing Mode (Touch), please try "Compatible Pairing Mode "
to pair.
Long press Pairing button for 5s until the Wi-Fi LED indicator changes in a cycle
1
of two short flashes and one long flash and release. Long press Pairing button
for 5s again until the Wi-Fi LED indicator flashes quickly. Then, the device enters
Compatible Pairing Mode.
Tap "+" and select " Compatible Pairing Mode " on APP.
2
Select Wi-Fi SSID with ITEAD-****** and enter the password 12345678, and then
go back to eWeLink APP and tap "Next". Be patient until pairing completes.
Specifications
Model
Input
Output
Operating systems
Wi-Fi
RF
Material
Dimension
BASICR2 does not support the remote controller with 433.92MHz.

Product Introduction

Wire Fastener Cover
Pairing button
Manual switch
The device weight is less than 1 kg.
The installation height of less than 2 m is recommended.
BASICR2/RFR2
100-240V AC 50/60Hz 10A
100-240V AC 50/60Hz Max. Load: 10A
Android & iOS
IEEE 802.11 b/g/n 2.4GHz
433,92MHz
PC V0
88x39x24mm
8
English
Wi-Fi LED indicator(Green)
On/off LED indicator(Red)
