Tripp Lite DWMSCP4570VW Bedienungsanleitung Seite 4

1. Solid Brick and Concrete Wall Mounting
WARNING
Installers must verify that the supporting surface will safely support the combined weight of the equipment and
all attached hardware and components.
A
W-B
W-C
W-A
4
2.4"
95 mm 95 mm
(60 mm)
(3.7") (3.7")
Ø 3/8"
(Ø 10 mm)
2
1
Mark the exact Drill pilot holes
location of the
mounting holes.
Screw the wall
mount onto
the wall.
