1. Technical Data

Modell
Input Voltage
Input Signal
Power output
Ambient temperature
Dimensions
Net-weight
2. Specifications
1. Power supply by a separate power supply
2. PWM-signal as Input
3. Boosted PWM signal as output

3. Dimensions and Connections

1 channel PWM
signal input
MBN GmbH, Balthasar-Schaller-Str. 3, 86316 Friedberg - Germany
PROLED POWER BOOSTER 8 A 1 -CHANNEL
12 – 24 VDC
PWM-signal
96 / 192 W (12 / 24 VDC)
-10°C – 45°C
100 mm × 37 mm x 21 mm (LxBxT)
50 g
IP 20
Booster 8A 1-channel
www.proled.com
Users manual / Bedienungsanleitung
88 mm
10 mm
1 channel output
DC power supply connection
