Copyright©2020 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für ASROCK H470 Phantom Gaming 4

  • Seite 1 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Seite 2 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI®...
  • Seite 3: Motherboard-Layout

    H470 Phantom Gaming 4 Motherboard Layout CPU_FAN1 CPU_FAN2/WP ATX12V1 ATX12V2 ADDR_LED2 RGB_LED2 BOOT DRAM USB 3.2 Gen2 T:USB31_TA_1 B: USB31_TC_1 USB 3.2 Gen1 Top: T: USB3_1 RJ-45 B: USB3_2 CHA_FAN2/WP PCIE1 PCIE2 CMOS Intel M2_WIFI_CT1 Battery H470 SUPER PCIE3 Ultra M.2...
  • Seite 4 No. Description ATX 12V Power Connector (ATX12V1) ATX 12V Power Connector (ATX12V2) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2) CPU Fan Connector (CPU_FAN1) CPU/Water Pump Fan Connector (CPU_FAN2/WP) RGB LED Header (RGB_LED2) Addressable LED Header (ADDR_LED2) Post Status Checker (PSC) ATX Power Connector (ATXPWR1)
  • Seite 5 H470 Phantom Gaming 4 I/O Panel No. Description No. Description USB 2.0 Ports (USB_1_2) USB 3.2 Gen1 Ports (USB3_1_2) USB 3.2 Gen2 Type-A Port (USB31_TA_1) USB 3.2 Gen2 Type-C Port (USB31_TC_1) LAN RJ-45 Port* Antenna Bracket Line In (Light Blue)** DisplayPort 1.4...
  • Seite 6: Package Contents

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.
  • Seite 7 • Dual Channel DDR4 Memory Technology • 4 x DDR4 DIMM Slots • Supports DDR4 2933/2800/2666/2400/2133 non-ECC, un- buffered memory * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) * Core (i9/i7) support DDR4 up to 2933; Core (i5/i3), Pentium®...
  • Seite 8 Graphics * Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. • Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1 * VP9 10bit and VC-1 are for decode only. * VP8 and VP9 encode are not supported by Windows OS.
  • Seite 9 H470 Phantom Gaming 4 • Gigabit LAN 10/100/1000 Mb/s • Giga PHY Intel® I219V • Supports Wake-On-LAN • Supports Lightning/ESD Protection • Supports Energy Efficient Ethernet 802.3az • Supports PXE Rear Panel • 1 x Antenna Bracket • 1 x PS/2 Mouse/Keyboard Port • 1 x HDMI Port...
  • Seite 10 • 1 x 4 pin 12V Power Connector • 1 x Front Panel Audio Connector • 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC R2.0 Card only) • 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) • 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
  • Seite 11 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.
  • Seite 12 Chapter 2 Installation This is an ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.
  • Seite 13: Installing The Cpu

    H470 Phantom Gaming 4 2.1 Installing the CPU 1. Before you insert the 1200-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Seite 15 H470 Phantom Gaming 4 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
  • Seite 16 2.2 Installing the CPU Fan and Heatsink...
  • Seite 17 H470 Phantom Gaming 4 2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs.
  • Seite 19 H470 Phantom Gaming 4 2.4 Expansion Slots (PCI Express Slots) There are 5 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.
  • Seite 20 2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) 2-pin Jumper (see p.1, No.
  • Seite 21 H470 Phantom Gaming 4 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard.
  • Seite 22 Power LED and Speaker Please connect the SPEAKER DUMMY Header chassis power LED and DUMMY (7-pin SPK_PLED1) the chassis speaker to this (see p.1, No. 19) header. PLED+ PLED+ PLED- Serial ATA3 Connectors These six SATA3 (SATA3_0: connectors support SATA see p.1, No.
  • Seite 23 H470 Phantom Gaming 4 USB 3.2 Gen1 Headers There are two headers on Vbus Vbus Vbus IntA_PB_SSRX- (19-pin USB3_3_4) this motherboard. Each IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (see p.1, No. 11) USB 3.2 Gen1 header can IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (19-pin USB3_5_6) support two ports.
  • Seite 24 Chassis/Water Pump Fan This motherboard provides Connectors four 4-Pin water cooling FAN_VOLTAGE (4-pin CHA_FAN1/WP) CHA_FAN_SPEED chassis fan connectors. If FAN_SPEED_CONTROL (see p.1, No. 12) you plan to connect a 3-Pin chassis water cooler fan, FAN_SPEED_CONTROL CHA_FAN_SPEED (4-pin CHA_FAN2/WP) please connect it to Pin 1-3. FAN_VOLTAGE (see p.1, No.
  • Seite 25 H470 Phantom Gaming 4 ATX 12V Power This motherboard provides Connector an 8-pin ATX 12V power (8-pin ATX12V1) connector. To use a 4-pin (see p.1, No. 1) ATX power supply, please plug it along Pin 1 and Pin ATX 12V Power...
  • Seite 26 RGB LED Headers RGB headers are used to connect (4-pin RGB_LED1) RGB LED extension cables which 12V G R (see p.1, No. 28) allow users to choose from various LED lighting effects. (4-pin RGB_LED2) Caution: Never install the RGB LED cable in the wrong (see p.1, No.
  • Seite 27 H470 Phantom Gaming 4 2.7 Post Status Checker Post Status Checker (PSC) diagnoses the computer when users power on the machine. It emits a red light to indicate whether the CPU, memory, VGA or stor- age is dysfunctional. The lights go off if the four mentioned above are functioning...
  • Seite 28 2.8 M.2 WiFi/BT Module and Intel® CNVi (Integrated WiFi/BT) Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT module and Intel®...
  • Seite 29 H470 Phantom Gaming 4 Step 3 Gently insert the WiFi/BT module or Intel® CNVi (Integrated WiFi/ BT) into the M.2 slot. Please be aware that the module only fits in one orientation. Step 4 Tighten the screw with a screwdriver to secure the module into place.
  • Seite 30 2.9 M.2_SSD (NGFF) Module Installation Guide (M2_1) The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_1) supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s).
  • Seite 31 H470 Phantom Gaming 4 Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location B by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut.
  • Seite 32 M.2_SSD (NGFF) Module Support List Vendor Interface Team SATA3 TM4PS4128GMC105 Team SATA3 TM4PS4256GMC105 Transcend SATA3 TS256GMTS400 ADATA SATA3 AXNS381E-128GM-B ADATA SATA3 AXNS381E-256GM-B ADATA SATA3 ASU800NS38-256GT-C ADATA SATA3 ASU800NS38-512GT-C ADATA PCIe3 x4 ASX7000NP-128GT-C ADATA PCIe3 x4 ASX8000NP-256GM-C ADATA PCIe3 x4 ASX7000NP-256GT-C ADATA PCIe3 x4 ASX8000NP-512GM-C...
  • Seite 33 H470 Phantom Gaming 4 Team SATA3 TM8PS4256GMC105 TEAM PCIe3 x4 TM8FP2240G0C101 TEAM PCIe3 x4 TM8FP2480GC110 Transcend SATA3 TS512GMTS600 Transcend SATA3 TS512GMTS800 V-Color SATA3 VLM100-120G-2280B-RD V-Color SATA3 VLM100-240G-2280RGB V-Color SATA3 VSM100-240G-2280 V-Color SATA3 VLM100-240G-2280B-RD SATA3 WDS100T1B0B-00AS40 SATA3 WDS240G1G0B-00RC30 PCIe3 x4 WDS256G1X0C-00ENX0 (NVME)
  • Seite 34 2.10 M.2_SSD (NGFF) Module Installation Guide (M2_2) The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_2) supports M Key type 2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s).
  • Seite 35 H470 Phantom Gaming 4 Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location B by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut.
  • Seite 36 M.2_SSD (NGFF) Module Support List Vendor Interface ADATA SATA3 AXNS330E-32GM-B ADATA SATA3 AXNS381E-128GM-B ADATA SATA3 AXNS381E-256GM-B ADATA SATA3 ASU800NS38-256GT-C ADATA SATA3 ASU800NS38-512GT-C ADATA PCIe3 x4 ASX7000NP-128GT-C ADATA PCIe3 x4 ASX8000NP-256GM-C ADATA PCIe3 x4 ASX7000NP-256GT-C ADATA PCIe3 x4 ASX8000NP-512GM-C ADATA PCIe3 x4 ASX7000NP-512GT-C Apacer PCIe3 x4...
  • Seite 37 H470 Phantom Gaming 4 Team SATA3 TM8PS4256GMC105 TEAM PCIe3 x4 TM8FP2240G0C101 TEAM PCIe3 x4 TM8FP2480GC110 Transcend SATA3 TS256GMTS400 Transcend SATA3 TS512GMTS600 Transcend SATA3 TS512GMTS800 V-Color SATA3 VLM100-120G-2280B-RD V-Color SATA3 VLM100-240G-2280RGB V-Color SATA3 VSM100-240G-2280 V-Color SATA3 VLM100-240G-2280B-RD SATA3 WDS100T1B0B-00AS40 SATA3 WDS240G1G0B-00RC30...
  • Seite 38 2.11 ASRock Polychrome SYNC ASRock Polychrome SYNC is a lighting control utility specifically designed for unique indi- viduals with sophisticated tastes to build their own stylish colorful lighting system. Simply by connecting the LED strip, you can customize various lighting schemes and patterns, including Static, Breathing, Strobe, Cycling, Music, Wave and more.
  • Seite 39 H470 Phantom Gaming 4 Connecting the Addressable RGB LED Strip Connect your Addressable RGB LED strips to the Addressable LED Headers (ADDR_LED1 / ADDR_LED2) on the motherboard. ADDR_LED2 B OOT CP U DRAM VG A ADDR_LED1 DO_ADDR VOUT 1. Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Seite 40 ASRock Polychrome SYNC Utility Now you can adjust the RGB LED color through the ASRock Polychrome SYNC Utility. Download this utility from the ASRock Live Update & APP Shop and start coloring your PC style your way! Drag the tab to customize your preference.
  • Seite 41: Einleitung

    H470 Phantom Gaming 4 1 Einleitung Vielen Dank, dass Sie sich für das ASRock H470 Phantom Gaming 4 entschieden haben – ein zuverlässiges Motherboard, das konsequent unter der strengen Qualitätskontrolle von ASRock hergestellt wurde. Es liefert ausgezeichnete Leistung mit robustem Design, das ASRock Streben nach Qualität und Beständigkeit erfüllt.
  • Seite 42: Technische Daten

    • Dualkanal-DDR4-Speichertechnologie • 4 x DDR4-DIMM-Steckplätze • Unterstützt ungepufferten DDR4 2933/2800/2666/2400/2133-Non-ECC-Speicher* * Weitere Informationen finden Sie in der Speicherkompatibilitätsliste auf der ASRock-Webseite. (http://www.asrock.com/) * Core (i9/i7) Unterstützt DDR4 bis zu 2933; Core (i5/i3), Pentium® und Celeron® Unterstützt DDR4 bis zu 2666.
  • Seite 43 H470 Phantom Gaming 4 Grafikkarte * Integrierte Intel® UHD Graphics-Visualisierung und VGA- Ausgänge können nur mit Prozessoren unterstützt werden, die GPU- integriert sind. • Hardware-beschleunigende Codecs: AVC/H.264, HEVC/H.265 8 bit, HEVC/H.265 10 bit, VP8, VP9 8 bit, VP9 10 bit, MPEG2, MJPEG, VC-1 * VP9 10 Bit und VC-1 dienen nur der Dekodierung.
  • Seite 44 M.2-SATA-III-6,0-Gb/s-Modul und M.2-PCI-Express-Modul bis Gen3 x 4 (32 Gb/s)** • 1 x Ultra-M.2-Sockel (M2_2), unterstützt M-Key-Typ- 2260/2280/22110-M.2-SATA-III-6,0-Gb/s-Modul und M.2-PCI- Express-Modul bis Gen3 x 4 (32 Gb/s)** ** Unterstützt Intel® Optane -Technologie ** Unterstützt NVMe-SSD als Bootplatte ** Unterstützt ASRock U.2-Kit...
  • Seite 45: Anschluss

    • 1 x 4-poliger 12-V-Netzanschluss • 1 x Audioanschluss an Frontblende • 1 x Thunderbolt Erweiterungskartenanschluss (5-polig) (Unterstützt nur ASRock Thunderbolt 3 AIC R2.0-Karten) • 2 x USB 2.0-Stiftleisten (unterstützt 4 USB 2.0-Ports) (unterstützt Schutz gegen elektrostatische Entladung) • 2 x USB 3.2 Gen1-Stiftleiste (unterstützt 4 USB 3.2 Gen1-Ports) (unterstützt Schutz gegen elektrostatische Entladung)
  • Seite 46 • ErP/EuP ready (ErP/EuP ready-Netzteil erforderlich) * Detaillierte Produktinformationen finden Sie auf unserer Webseite: http://www.asrock.com Bitte beachten Sie, dass mit einer Übertaktung, zu der die Anpassung von BIOS- Einstellungen, die Anwendung der Untied Overclocking Technology oder die Nutzung von Übertaktungswerkzeugen von Drittanbietern zählen, bestimmte Risiken verbunden sind.
  • Seite 47: Jumpereinstellung

    H470 Phantom Gaming 4 1.3 Jumpereinstellung Die Abbildung zeigt, wie die Jumper eingestellt werden. Wenn die Jumper-Kappe auf den Kontakten angebracht ist, ist der Jumper „kurzgeschlossen“. Wenn keine Jumper-Kappe auf den Kontakten angebracht ist, ist der Jumper „offen“. CMOS-löschen-Jumper (CLRMOS1) 2-pin Jumper (siehe S.
  • Seite 48: Integrierte Stiftleisten Und Anschlüsse

    1.4 Integrierte Stiftleisten und Anschlüsse Integrierte Stiftleisten und Anschlüsse sind KEINE Jumper. Bringen Sie KEINE Jumper- Kappen an diesen Stiftleisten und Anschlüssen an. Durch Anbringen von Jumper-Kappen an diesen Stiftleisten und Anschlüssen können Sie das Motherboard dauerhaft beschädigen. Systemblende-Stiftleiste Verbinden Sie Ein-/ PLED+ PLED- (9-polig, PANEL1)
  • Seite 49 H470 Phantom Gaming 4 Betrieb-LED- und Bitte verbinden Sie die Betrieb- SPEAKER DUMMY Lautsprecher-Stiftleiste LED des Gehäuses und den DUMMY (7-polig, SPK_PLED1) Gehäuselautsprecher mit dieser (siehe S. 1, Nr. 19) Stiftleiste. PLED+ PLED+ PLED- Serial-ATA-III-Anschlüsse Diese sechs SATA-III-Anschlüsse (SATA3_0: unterstützen SATA-Datenkabel siehe S.
  • Seite 50 USB 3.2 Gen1-Stiftleisten Es gibt zwei Stiftleisten an diesem Vbus Vbus Vbus IntA_PB_SSRX- (19-polig, USB3_3_4) Motherboard. Jede USB 3.2 IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (siehe S. 1, Nr. 11) Gen1-Stiftleiste kann zwei Ports IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (19-polig, USB3_5_6) unterstützen. IntA_PA_SSTX+ IntA_PB_D- (siehe S. 1, Nr. 24) IntA_PA_D- IntA_PB_D+ IntA_PA_D+...
  • Seite 51 H470 Phantom Gaming 4 Gehäuse-/Wasserpumpen- Dieses Motherboard bietet Lüfteranschlusse vier 4-polige Wasserkühlung- (4-polig, CHA_FAN1/WP) Gehäuselüfteranschlüsse. Falls FAN_VOLTAGE CHA_FAN_SPEED (siehe S. 1, Nr. 12) Sie einen 3-poligen Gehäuse- FAN_SPEED_CONTROL Wasserkühlerlüfter anschließen möchten, verbinden Sie ihn bitte (4-polig, CHA_FAN2/WP) mit Kontakt 1 bis 3.
  • Seite 52 ATX-12-V-Netzanschluss Dieses Motherboard bietet (8-polig, ATX12V1) einen 8-poligen ATX-12-V- (siehe S. 1, Nr. 1) Netzanschluss. Bitte schließen Sie es zur Nutzung eines 4-poligen ATX-Netzteils entlang Kontakt 1 und Kontakt 5 an. ATX-12-V-Netzanschluss An diesen Anschluss schließen (4-polig, ATX12V2) Sie ein ATX-12 V-Netzteil an. (siehe S.
  • Seite 53 H470 Phantom Gaming 4 RGB-LED-Stiftleisten RGB-Stiftleiste dient dem (4-polig, RGB_LED1) Anschließen eines RGB-LED- 12V G R (siehe S. 1, Nr. 28) Erweiterungskabels, das dem Nutzer die Auswahl zwischen (4-polig, RGB_LED2) verschiedenen LED-Lichteffekten (siehe S. 1, Nr. 7) ermöglicht. Achtung: Installieren Sie das RGB-LED-Kabel niemals falsch herum;...
  • Seite 54: Contenu De L'emballage

    à modification sans préavis. En cas de modifications du présent document, la version mise à jour sera disponible sur le site Internet ASRock sans notification préalable. Si vous avez besoin d’une assistance technique pour votre carte mère, veuillez visiter notre site Internet pour plus de détails sur le modèle que vous utilisez.
  • Seite 55 • Prend en charge les mémoires sans tampon non ECC DDR4 2933/2800/2666/2400/2133 * Veuillez consulter la liste de prise en charge des mémoires sur le site Web d'ASRock pour de plus amples informations. (http://www.asrock.com/) * Core (i9/i7) prend en charge DDR4 jusqu'à 2933; Core (i5/i3), Pentium®...
  • Seite 56 Graphiques * La technologie Intel® UHD Graphics Built-in Visuals et les sorties VGA sont uniquement prises en charge par les processeurs intégrant un contrôleur graphique. • Codecs d’accélération matérielle : AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1 * VP9 10 bits et VC-1 sont uniquement destinés au décodage.
  • Seite 57 SATA3 6,0 Go/s type 2260/2280/22110 touche M et M.2 PCI Express jusqu'à Gen3 x4 (32 Go/s)** ** Prend en charge Intel® Optane Technology ** Prend en charge les SSD NVMe comme disques de démarrage ** Prend en charge le kit ASRock U.2...
  • Seite 58 • 1 x connecteur audio panneau frontal • 1 x connecteur Thunderbolt AIC (5 broches) (Prise en charge de la carte ASRock Thunderbolt 3 AIC R2.0 uniquement) • 2 x embases USB 2.0 (4 ports USB 2.0 pris en charge) (Protection contre les décharges électrostatiques)
  • Seite 59 • FCC, CE • ErP/EuP Ready (alimentation ErP/EuP ready requise) * pour des informations détaillées de nos produits, veuillez visiter notre site : http://www.asrock.com Il est important de signaler que l’ o verclocking présente certains risques, incluant des modifications du BIOS, l’ a pplication d’une technologie d’ o verclocking déliée et l’utilisation d’...
  • Seite 60 1.3 Configuration des cavaliers (jumpers) L’illustration ci-dessous vous renseigne sur la configuration des cavaliers (jumpers). Lorsque le capuchon du cavalier est installé sur les broches, le cavalier est « court-circuité ». Si le capuchon du cavalier n’ e st pas installé sur les broches, le cavalier est « ouvert ». Cavalier Clear CMOS (CLRMOS1) 2-pin Jumper...
  • Seite 61 H470 Phantom Gaming 4 1.4 Embases et connecteurs de la carte mère Les embases et connecteurs situés sur la carte NE SONT PAS des cavaliers. Ne placez JAMAIS de capuchons de cavaliers sur ces embases ou connecteurs. Placer un capuchon de cavalier sur ces embases ou connecteurs endommagera irrémédiablement votre carte mère.
  • Seite 62 Prise LED d’alimentation et Veuillez brancher la LED SPEAKER DUMMY haut-parleur d'alimentation du châssis et le DUMMY (SPK_PLED1 à 7 broches) haut-parleur du châssis sur ce (voir p.1, No. 19) connecteur. PLED+ PLED+ PLED- Connecteurs Serial ATA3 Ces six connecteurs SATA3 sont (SATA3_0: compatibles avec les câbles de voir p.1, No.
  • Seite 63 H470 Phantom Gaming 4 Embases USB 3.2 Gen1 Cette carte mère comprend deux Vbus Vbus Vbus IntA_PB_SSRX- (USB3_3_4 à 19 broches) connecteurs. Chaque embase IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (voir p.1, No. 11) USB 3.2 Gen1 peut prendre en IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (USB3_5_6 à...
  • Seite 64 Connecteurs du ventilateur Cette carte mère est dotée de châssis/pompe à eau de quatre connecteurs pour (CHA_FAN1/WP à ventilateur de châssis à FAN_VOLTAGE CHA_FAN_SPEED 4 broches) refroidissement par eau à FAN_SPEED_CONTROL (voir p.1, No. 12) 4 broches. Si vous envisagez de connecter un ventilateur de (CHA_FAN2/WP à...
  • Seite 65 H470 Phantom Gaming 4 Connecteur d’alimentation Cette carte mère est dotée d’un connecteur d’alimentation (ATXPWR1 à 24 broches) ATX à 24 broches. Pour utiliser (voir p.1, No. 10) une alimentation ATX à 20 broches, veuillez effectuer les branchements sur la Broche 1 et la Broche 13.
  • Seite 66 Connecteur Thunderbolt Veuillez connecter une carte d’ e xtension Thunderbolt™ (AIC) à (TB1 à 5 broches) ce connecteur via le câble GPIO. (voir p.1, No. 31) *Veuillez installer la carte Thunderbolt™ AIC sur PCIE4 (emplacement par défaut). Embase LED RVB L'embase RVB sert à...
  • Seite 67: Contenuto Della Confezione

    Nel caso di eventuali modifiche della presente documentazione, la versione aggiornata sarà disponibile sul sito Web di ASRock senza ulteriore preavviso. Per il supporto tecnico correlato a questa scheda madre, visitare il nostro sito Web per informazioni specifiche relative al modello attualmente in uso.
  • Seite 68 • 4 x alloggi DIMM DDR4 • Supporto di memoria DDR4 2933/2800/2666/2400/2133 non- ECC, un-buffered * Per maggiori informazioni fare riferimento all'elenco dei supporti di memoria sul sito di ASRock. (http://www.asrock.com/) * Core (i9/i7) supporta DDR4 fino a 2933; Core (i5/i3), Pentium®...
  • Seite 69 H470 Phantom Gaming 4 Grafica * La videografica integrata della scheda video UHD Intel® e le uscite VGA possono essere supportate soltanto con processori con GPU integrata. • Codec con accelerazione hardware: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit, MPEG2, MJPEG, VC-1 * VP9 10bit e VC-1 servono solo per la decodifica.
  • Seite 70 • 1 x socket Ultra M.2 (M2_2), supporta il modulo M.2 SATA3 6,0 Gb/s di tipo M Key 2260/2280/22110 ed il modulo M.2 PCI Express fino a Gen3 x4 (32 Gb/s)** ** Supporta la tecnologia Intel® Optane ** Supporto di SSD NVMe come disco d’avvio ** Supporta kit ASRock U.2...
  • Seite 71 H470 Phantom Gaming 4 Connettore • 1 x connettore SPI TPM • 1 x connettore LED alimentazione e altoparlante • 2 x collettore LED RGB * Supporto totale di fino a 12 V/3 A, 36 W strip LED • 2 x Header LED indirizzabili * Supporto totale di strisce LED fino a 5 V/3 A, 15 W • 1 x connettore ventola CPU (4-pin)
  • Seite 72 • FCC, CE • ErP/EuP Ready (è necessaria alimentazione ErP/EuP ready) * Per informazioni dettagliate sul prodotto, visitare il nostro sito Web: http://www.asrock.com Prestare attenzione al potenziale rischio previsto nella pratica di overclocking, inclusa la regolazione delle impostazioni nel BIOS, l'applicazione di tecnologia di Untied Overclocking o l'utilizzo di strumenti di overclocking di terze parti.
  • Seite 73 H470 Phantom Gaming 4 1.3 Impostazione jumper L'illustrazione mostra in che modo vengono impostati i jumper. Quando il cappuccio del jumper è posizionato sui pin, il jumper è "cortocircuitato". Se sui pin non è posizionato alcun cappuccio del jumper, il jumper è "aperto".
  • Seite 74 1.4 Header e connettori su scheda Gli header e i connettori sulla scheda NON sono jumper. NON posizionare cappucci del jumper su questi header e connettori. Il posizionamento di cappucci del jumper su header e connettori provocherà danni permanenti alla scheda madre. Header sul pannello del Collegare il tasto PLED+...
  • Seite 75 H470 Phantom Gaming 4 Connettore LED Collegare i LED alimentazione SPEAKER DUMMY alimentazione e altoparlante e l’altoparlante a questo DUMMY (SPK_PLED1 a 7 pin) connettore. (vedere pag. 1, n. 19) PLED+ PLED+ PLED- Connettori Serial ATA3 Questi sei connettori SATA3...
  • Seite 76 Header USB 3.2 Gen1 Ci sono due connettori su questa Vbus Vbus Vbus IntA_PB_SSRX- (USB3_3_4 a 19 pin) scheda madre. Ciascun header IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (vedere pag. 1, n. 11) USB 3.2 Gen1 può supportare IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (USB3_5_6 a 19 pin) due porte.
  • Seite 77 H470 Phantom Gaming 4 Connettori ventola chassis / Questa scheda madre è dotata pompa dell'acqua di quattro connettori ventola a (CHA_FAN1/WP a 4 pin) 4 pin per il raffreddamento ad FAN_VOLTAGE CHA_FAN_SPEED (vedere pag. 1, n. 12) acqua del telaio. Se si decide di...
  • Seite 78 Connettore di alimentazione Questa scheda madre è dotata di ATX da 12 V un connettore di alimentazione (ATX12V1 a 8 pin) ATX da 12 V a 8 pin. Per (vedere pag. 1, n. 1) utilizzare un'alimentazione ATX a 4 pin, collegarla lungo il pin 1 e il pin 5.
  • Seite 79 H470 Phantom Gaming 4 Collettore LED RGB Il collettore RGB viene utilizzato (RGB_LED1 a 4 pin) per collegare la prolunga LED 12V G R (vedere pag. 1, n. 28) RGB, che consente agli utenti di scegliere tra vari effetti di (RGB_LED2 a 4 pin) illuminazione a LED.
  • Seite 80: Contenido Del Paquete

    1 Introducción Gracias por comprar la placa base ASRock H470 Phantom Gaming 4, una placa base fiable fabricada según el rigurosísimo control de calidad de ASRock. Ofrece un rendimiento excelente con un diseño resistente de acuerdo con el compromiso de calidad y resistencia de ASRock.
  • Seite 81 • 4 x ranuras DIMM DDR4 • Admite memoria DDR4 2933/2800/2666/2400/2133 no ECC, sin búfer * Para obtener más información, consulte la lista de memorias compatibles en el sitio web de ASRock. (http://www.asrock.com/) * Core (i9/i7) compatible con DDR4 de hasta 2933; Core (i5/i3), Pentium®...
  • Seite 82 Gráficos * Intel® UHD Graphics Built-in Visuals y las salidas de VGA son compatibles únicamente con procesadores con GPU integrado. • Códecs acelerados por hardware: AVC/H.264, HEVC/H.265 8 bits, HEVC/H.265 10 bits, VP8, VP9 8 bits, VP9 10 bits, MPEG2, MJPEG, VC-1 * VP9 10 bits y VC-1 son solo para descodificación.
  • Seite 83 Gb/s M.2 de tipo 2260/2280/22110 con clave M y el módulo PCI Express M.2 hasta Gen3 x4 (32 Gb/s)** ** Compatible con la tecnología Optane de Intel® ** Admite unidad de estado sólido de NVMe como disco de arranque ** Admite el kit U.2 de ASRock...
  • Seite 84 Conector • 1 x Conector SPI TPM • 1 x LED de alimentación y base de conexiones para el altavoz • 2 x Cabezales de indicador LED RGB * Admite una tira de LED de hasta 12 V/3 A (36 W) en total • 2 x cabezales de LED direccionables * Admite una tira de LED de hasta 5 V/3 A (15 W) en total • 1 x Conector para ventilador de la CPU (4 contactos)
  • Seite 85 • Preparado para ErP/EuP (se necesita una fuente de alimentación preparada para ErP/EuP) * Para obtener información detallada del producto, visite nuestro sitio Web: http://www.asrock.com Tenga en cuenta que hay un cierto riesgo implícito en las operaciones de overclocking, incluido el ajuste de la BIOS, aplicando la tecnología de overclocking liberada o utilizando las herramientas de overclocking de otros fabricantes.
  • Seite 86 1.3 Instalación de los puentes La instalación muestra cómo deben instalarse los puentes. Cuando la tapa de puente se coloca en los contactos, el puente queda “Corto”. Si no coloca la tapa de puente en los contactos, el puente queda “Abierto”. Puente de borrado de CMOS 2-pin Jumper...
  • Seite 87 H470 Phantom Gaming 4 1.4 Conectores y cabezales incorporados Los cabezales y conectores incorporados NO son puentes. NO coloque tapas de puente sobre estos cabezales y conectores. Si coloca tapas de puente sobre los cabezales y conectores dañará de forma permanente la placa base.
  • Seite 88 LED de alimentación y Conecte el LED de alimentación SPEAKER DUMMY base de conexiones para la del chasis y el altavoz del chasis a DUMMY altavoz esta base de conexiones. (SPK_PLED1 de 7 contactos) PLED+ (consulte la pág. 1, nº 19) PLED+ PLED- Conectores Serie ATA3...
  • Seite 89 H470 Phantom Gaming 4 Cabezales USB 3.2 Gen1 Hay dos bases de conexiones en Vbus Vbus Vbus IntA_PB_SSRX- (USB3_3_4 de esta placa base. Cada cabezal IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ 19 contactos) USB 3.2 Gen1 admite dos puertos. IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (consulte la pág. 1, nº 11)
  • Seite 90 Conectores del ventilador Esta placa base proporciona cuatro de la bomba de agua/ conectores para el ventilador del chasis chasis para refrigeración por agua FAN_VOLTAGE CHA_FAN_SPEED (CHA_FAN1/WP de de 4 contactos. Si tiene pensando FAN_SPEED_CONTROL 4 contactos) conectar un ventilador de (consulte la pág.
  • Seite 91 H470 Phantom Gaming 4 Conector de alimentación Esta placa base contiene un conector de alimentación ATX (ATXPWR1 de de 24 contactos. Para utilizar 24 contactos) una toma de alimentación ATX (consulte la pág. 1, nº 10) de 20 contactos, conéctela en los contactos del 1 al 13.
  • Seite 92 Cabezales de LED RGB El cabezal RGB se utiliza para (RGB_LED1 de conectar el alargador de LED RGB 12V G R 4 contactos) que permite a los usuarios elegir (consulte la pág. 1, nº 28) entre varios efectos de iluminación de LED.
  • Seite 93: Комплект Поставки

    уведомления. При необходимости технической поддержки, связанной с материнской платой, посетите веб-сайт и найдите на нем информацию о модели используемой вами материнской платы. На веб-сайте ASRock также можно найти самый последний перечень поддерживаемых VGA-карт и ЦП. Веб-сайт ASRock http://www.asrock.com. 1.1 Комплект поставки...
  • Seite 94: Технические Характеристики

    • Поддерживаются модули небуферизованной памяти DDR4 2933/2800/2666/2400/2133 без ECC * Дополнительная информация представлена в Списке совместимой памяти (Memory Support List) на веб-сайте ASRock. (http://www.asrock.com/) * Core (i9/i7) поддерживают память DDR4 с частотой до 2933; Core (i5/i3), Pentium® и Celeron® поддерживают память...
  • Seite 95 H470 Phantom Gaming 4 Графическая * Встроенный видеоадаптер Intel® UHD Graphics и выходы VGA поддерживаются только при использовании ЦП со подсистема встроенными графическими процессорами. • Кодеки с аппаратным ускорением Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8 бит, HEVC/H.265 10 бит, VP8, VP9 8 бит, VP9 10 бит, MPEG2, MJPEG, VC-1 * VP9 10 бит...
  • Seite 96 • 1 слот Ultra M.2 (M2_2), поддерживается модуль M.2 SATA3 с ключом M типа 2260/2280/22110 с пропускной способностью 6,0 Гбит/с и модуль M.2 PCI Express до версии Gen3 x4 (32 Гбит/с)** ** Поддерживается технология Intel® Optane ** Поддерживаются в качестве загрузочных SSD-диски типа NVMe ** Поддерживается комплект ASRock U.2.
  • Seite 97 • 1 разъем питания 12 В, 4-контактный • 1 аудиоразъем для передней панели • 1 AIC-разъем Thunderbolt (5-контактный) (Поддерживает только карту ASRock Thunderbolt 3 AIC R2.0) • 2 колодки USB 2.0 (4 порта USB 2.0, с защитой от электростатических разрядов) • 2 колодка...
  • Seite 98 • FCC, CE • Совместимость с ErP/EuP (необходим блок питания, соответствующий стандарту ErP/EuP) * С дополнительной информацией об изделии можно ознакомиться на веб-сайте: http://www.asrock.com Следует учитывать, что разгон процессора, включая изменение настроек BIOS, применение технологии Untied Overclocking и использование инструментов разгона...
  • Seite 99 H470 Phantom Gaming 4 1.3 Установка перемычек Установка перемычек показана на рисунке. При установке перемычки-колпачка на контакты перемычка «замкнута». Если перемычка-колпачок на контакты не установлена, перемычка «разомкнута». Перемычка сброса настроек CMOS 2-pin Jumper (CLRMOS1) (см. стр. 1, № 30) CLRMOS1 используется для удаления данных CMOS. Чтобы сбросить и обнулить...
  • Seite 100 1.4 Колодки и разъемы, расположенные на системной плате Расположенные на системной плате колодки и разъемы НЕ являются перемычками. НЕ устанавливайте на эти колодки и разъемы перемычки-колпачки. Установка перемычек-колпачков на эти колодки и разъемы может вызвать неустранимое повреждение системной платы. Колодка системной Подключите...
  • Seite 101 H470 Phantom Gaming 4 Колодка светодиодного Предназначена для SPEAKER DUMMY индикатора питания и подключения светодиодного DUMMY динамика корпуса индикатора питания и (7-контактная, SPK_ динамика корпуса. PLED1) PLED+ (см. стр. 1, № 19) PLED+ PLED- Разъемы Serial ATA3 Эти шесть разъемов...
  • Seite 102 Колодки USB 3.2 Gen1 На материнской плате имеется Vbus Vbus (19-контактная, Vbus IntA_PB_SSRX- две колодки. Каждая колодка IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ USB3_3_4) USB 3.2 Gen1 поддерживает IntA_PB_SSTX- IntA_PA_SSTX- (см. стр. 1, № 11) IntA_PB_SSTX+ два порта. IntA_PA_SSTX+ IntA_PB_D- (19-контактная, IntA_PA_D- IntA_PB_D+ IntA_PA_D+ Dummy USB3_5_6)
  • Seite 103 H470 Phantom Gaming 4 Разъемы для вентилятора Данная системная или помпы водяного плата оснащена четыре FAN_VOLTAGE охлаждения корпуса 4-контактным разъемами для CHA_FAN_SPEED FAN_SPEED_CONTROL (4-контактный CHA_ системы водяного охлаждения FAN1/WP) корпуса. 3-контактную (см. стр. 1,№ 12) систему водяного охлаждения корпуса следует подключать к...
  • Seite 104 Разъем питания АТХ Эта материнская плата (24-контакта, ATXPWR1) оснащена 24-контактным (см. стр. 1, № 10) разъемом питания АТХ. Чтобы использовать 20-контактный разъем питания ATX, подключите его вдоль контакта 1 и контакта 13. Разъем питания АТХ 12 В Эта материнская плата (8-контактов, ATX12V1) оснащена...
  • Seite 105 H470 Phantom Gaming 4 Разъем Thunderbolt AIC Подключите расширительную (5 контактов, TB1) плату (AIC-карту) Thunderbolt™ (см. стр. 1, № 31) к данному разъему с помощью интерфейсного GPIO-кабеля. * Установите плату расширения Thunderbolt™ в слот PCIE4 (слот по умолчанию). Колодки для подключения...
  • Seite 106: Conteúdo Da Embalagem

    1 Introdução Obrigado por adquirir a placa mãe ASRock H470 Phantom Gaming 4, uma confiável placa mãe ASRock produzida sob rigoroso controle de qualidade consistente. Esta placa principal oferece um excelente desempenho com um design robusto em conformidade com o compromisso da ASRock em fabricar produtos de qualidade e resistentes.
  • Seite 107: Especificações

    • 4 x Slots DIMM DDR4 • Suporta memória DDR4 2933/2800/2666/2400/2133, não ECC, sem memória intermédia * Por favor, consulte a Lista de Suporte de Memória no site da ASRock para obter mais informação. (http://www.asrock.com/) * Core (i9/i7) suporta DDR4 2933 por overclocking; Core (i5/i3), Pentium®...
  • Seite 108 Gráficos * Os gráficos incorporados Intel® UHD e as saídas VGA só podem ser suportados com processadores com GPU integrada. • Codecs Acelerados de Hardware: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1 * VP9 10bit e VC-1 são apenas para decodificação. * Codificação VP8 e VP9 não são suportados pelo SO Windows.
  • Seite 109 H470 Phantom Gaming 4 • LAN Gigabit a 10/100/1000 Mb/s • Giga PHY Intel® I219V • Suporta Wake-On-LAN • Oferece Suporte à Proteção de Relâmpago/ESD • Suporta Energy Efficient Ethernet 802.3az • Suporta PXE E/S do painel • 1 Suporte de Antena • 1 x Porta PS/2 para mouse/teclado...
  • Seite 110 • 1 x Conector de energia 4-pinos 12V • 1 x Conector de áudio do painel frontal • 1 x Conector Thunderbolt AIC (5 pinos)(Suporta Cartão ASRock Thunderbolt 3 AIC R2.0 única) • 2 x Plataformas USB 2.0 (Suporta 4 portas USB 2.0) (Suporta Proteção ESD)
  • Seite 111 • Preparada para ErP/EuP (é necessária uma fonte de alimentação preparada para ErP/EuP) * Para obter informações detalhadas sobre o produto, por favor, visite o nosso site: http://www.asrock.com Por favor, observe que existe um certo risco envolvendo overclocking, incluindo o ajuste das definições na BIOS, a aplicação de tecnologia Untied Overclocking ou a utilização de...
  • Seite 112 1.3 Configuração dos jumpers A imagem abaixo mostra como os jumpers são configurados. Quando a tampa do jumper é colocada nos pinos, o jumper é "Curto". Se não for colocada uma tampa de jumper nos pinos, o jumper é "Aberto". Apagar o Jumper CMOS (CLRMOS1) 2-pin Jumper...
  • Seite 113 H470 Phantom Gaming 4 1.4 Suportes e conectores onboard Os conectores e suportes onboard NÃO são jumpers. NÃO coloque tampas de jumpers sobre estes terminais e conectores. Colocar tampas de jumpers sobre os terminais e conectores irá causar danos permanentes à placa-mãe.
  • Seite 114 LED de alimentação e Conecte o LED de alimentação SPEAKER DUMMY Cabeçote de Autofalante do chassi e o autofalante do chassi DUMMY (SPK_PLED1 de 7 pinos) a este cabeçote. (ver p.1, N.º 19) PLED+ PLED+ PLED- Conectores série ATA3 Estes seis conectores SATA3 (SATA3_0: suportam cabos de dados ver p.1, N.º...
  • Seite 115 H470 Phantom Gaming 4 Plataformas USB 3.2 Gen1 Há dois cabeçotes nesta placa- Vbus Vbus Vbus IntA_PB_SSRX- (USB3_3_4 de 19 pinos) mãe. Cada suporte USB 3.2 Gen1 IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (ver p.1, N.º 11) pode suportar duas portas. IntA_PB_SSTX- IntA_PA_SSTX-...
  • Seite 116 Chassis / Conectores da Esta placa mãe fornece quatro ventoinha de bomba de conectores do chassi de FAN_VOLTAGE água refrigeração a água de 4 pinos. CHA_FAN_SPEED FAN_SPEED_CONTROL (CHA_FAN1/WP de Se você pretende conectar um 4 pinos) ventilador de refrigeração a água (ver p.1, N.º...
  • Seite 117 H470 Phantom Gaming 4 Conector de alimentação Esta placa-mãe inclui um conector de alimentação ATX de (ATXPWR1 de 24 pinos) 24 pinos. Para utilizar uma fonte (ver p.1, N.º 10) de alimentação ATX de 20 pinos, introduza-a no Pino 1 e Pino 13.
  • Seite 118 Cabeçotes de LED RGB Cabeçote RGB é usado para (RGB_LED1 de 4 pinos) conectar o cabo de extensão 12V G R (ver p.1, N.º 28) de LED RGB que permite aos usuários escolher entre vários (RGB_LED2 de 4 pinos) efeitos de iluminação LED. Atenção: Nunca instale o cabo (ver p.1, N.º...
  • Seite 119: Zawartość Opakowania

    H470 Phantom Gaming 4 1 Wprowadzenie Dziękujemy za zakupienie płyty głównej ASRock H470 Phantom Gaming 4, niezawodnej płyty głównej produkowanej z konsekwentnie wykonywaną przez firmę ASRock, rygorystyczną kontrolą jakości. Płyta ta zapewnia doskonałą jakość działania i solidną konstrukcję, spełniającą zobowiązanie firmy ASRock do dostarczania produktów o wysokiej jakości i wytrzymałości.
  • Seite 120 • 4 x gniazda DDR4 DIMM • Obsługa pamięci DDR4 2933/2800/2666/2400/2133 non-ECC, pamięć niebuforowana * Sprawdź listę obsługiwanej pamięci na stronie internetowej ASRock w celu uzyskania dalszych informacji. (http://www.asrock.com/) * Core (i9/i7) obsługuje DDR4 do 2933; Core (i5/i3), Pentium® i Celeron®...
  • Seite 121 H470 Phantom Gaming 4 Grafika * Wbudowana grafika Intel® UHD i wyjścia VGA są obsługiwane wyłącznie z procesorami, które mają zintegrowane GPU. • Sprzętowo przyspieszane kodeki: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit, MPEG2, MJPEG, VC-1 * VP9 10bit i VC-1 służą wyłącznie do dekodowania.
  • Seite 122 • 1 x gniazdo Ultra M.2 (M2_2), obsługa Key M typu 2260/2280/22110 modułu M.2 SATA3 6,0 Gb/s i modułu M.2 PCI Express do Gen3 x4 (32 Gb/s)** ** Obsługa technologii Intel® Optane ** Obsługa SSD NVMe, jako dysków rozruchowych ** Obsługa ASRock U.2 Kit...
  • Seite 123 H470 Phantom Gaming 4 Złącze • 1 x złącze główkowe SPI TPM • 1 x dioda LED zasilania i złącze główkowe głośnika • 2 x złącza główkowe LED RGB * Obsługa łącznie do 12V/3A, pasek LED 36W • 2 x adresowalne złącza główkowe LED * Obsługa łącznie do 5V/3A, pasek LED 15W...
  • Seite 124 • Gotowość do obsługi ErP/EuP (Wymagane zasilanie z gotowością obsługi ErP/EuP) * Dla uzyskania szczegółowej informacji o produkcie, należy odwiedzić naszą stronę internetową: http://www.asrock.com Należy pamiętać, że przetaktowywanie jest związane z pewnym ryzykiem, włącznie z regulacją ustawień w BIOS, zastosowaniem Untied Overclocking Technology lub używaniem narzędzi przetaktowywania innych firm.
  • Seite 125 H470 Phantom Gaming 4 1.3 Ustawienia zworek Ta ilustracja pokazuje ustawienia zworek. Po umieszczeniu nasadki zworki na pinach, zworka jest “Zwarta”. Jeśli nasadka zworki nie jest umieszczona na pinach, zworka jest “Otwarta”. Zworka usuwania danych z pamięci CMOS 2-pin Jumper (CLRMOS1) (sprawdź...
  • Seite 126 1.4 Wbudowane złącza główkowe i inne złącza Wbudowane złącza główkowe i inne złącza są bezzworkowe. NIE należy umieszczać zworek nad tymi złączami główkowymi i złączami. Umieszczanie zworek nad złączami główkowymi i złączami spowoduje trwałe uszkodzenie płyty głównej. Złącze główkowe na panelu Do tego złącza główkowego PLED+ PLED-...
  • Seite 127 H470 Phantom Gaming 4 Dioda LED zasilania i złącze Podłącz to tego złącza SPEAKER DUMMY główkowe głośnika główkowego diodę LED DUMMY (7-pinowe SPK_PLED1) zasilania obudowy i głośnik (sprawdź s.1, Nr 19) obudowy . PLED+ PLED+ PLED- Złącza Serial ATA3 Te sześć złączy SATA3 (SATA3_0: obsługuje kable danych SATA...
  • Seite 128 Złącza główkowe USB 3.2 Na tej płycie głównej znajdują Vbus Vbus Vbus IntA_PB_SSRX- Gen1 się dwa złącza główkowe. IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (19-pinowe USB3_3_4) Każde złącze główkowe IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (sprawdź s.1, Nr 11) USB 3.2 Gen1 może obsługiwać IntA_PA_SSTX+ IntA_PB_D- (19-pinowe USB3_5_6) dwa porty.
  • Seite 129 H470 Phantom Gaming 4 Złącze /wentylatora pompy Ta płyta główna udostępnia wodnej obudowy cztery 4-pinowe złącza FAN_VOLTAGE (4-pinowe CHA_FAN1/WP) obudowy wentylatora CHA_FAN_SPEED FAN_SPEED_CONTROL (sprawdź s.1, Nr 12) chłodzenia wodnego. Jeśli planowane jest podłączenie (4-pinowe CHA_FAN2/WP) 3-pinowego wentylatora FAN_SPEED_CONTROL CHA_FAN_SPEED (sprawdź s.1, Nr 32) chłodzenia wodnego obudowy,...
  • Seite 130 Złącze zasilania ATX 12V Ta płyta główna udostępnia (8-pinowe ATX12V1) 8-pinowe złącze zasilania ATX (sprawdź s.1, Nr 1) 12V. W celu użycia 4-pinowego zasilacza ATX, należy podłączyć je wzdłuż pinu 1 i pinu 5. Złącze zasilania ATX 12V Podłącz do tego złącza zasilacz (4-pinowe ATX12V2) ATX 12V.
  • Seite 131 H470 Phantom Gaming 4 Złącza główkowe LED RGB Złącze główkowe RGB jest (4-pinowe RGB_LED1) używane do podłączenia 12V G R (sprawdź s.1, Nr 28) przedłużacza LED RGB, który umożliwia użytkownikom (4-pinowe RGB_LED2) wybór spośród różnych efektów (sprawdź s.1, Nr 7) światła LED.
  • Seite 132 1 개요 ASRock H470 Phantom Gaming 4 마더보드를 구입해 주셔서 감사합니다 . 이 마더보드는 ASRock 의 일관되고 엄격한 품질관리 하에 생산되어 신뢰성이 우수합니다 . 품질과 내구성에 대한 ASRock 의 기준에 부합하는 우수한 성능과 견고한 설계를 제공합니다 . 마더보드 규격과 BIOS 소프트웨어를 업데이트할 수도 있기 때문에 , 이 문서의...
  • Seite 133 메모리 • DDR4 DIMM 슬롯 4 개 • DDR4 2933/2800/2666/2400/2133 비 ECC, 비버퍼링 메모리 지원 * 추가 정보를 원하시면 ASRock 웹사이트에 있는 메모리 지원 목록을 참조하십시오 . (http://www.asrock.com/) * Core (i9/i7) 는 최대 2933 까지 DDR4 를 지원하고 ; Core (i5/i3), Pentium®...
  • Seite 134 * Intel® UHD 그래픽스 빌트 - 인 비주얼과 VGA 출력은 GPU 통합 그래픽 프로세서로만 지원할 수 있습니다 . • 하드웨어 가속 코덱 : AVC/H.264, HEVC/H.265 8- 비트 , HEVC/H.265 10- 비트 , VP8, VP9 8- 비트 , VP9 10- 비트 , MPEG2, MJPEG, VC-1 * VP9 10 비트...
  • Seite 135 H470 Phantom Gaming 4 • Gigabit LAN 10/100/1000 Mb/s • Giga PHY Intel® I219V • Wake-On-LAN 지원 • 번개 /ESD 보호 지원 • 절전형 이더넷 802.3az 지원 • PXE 지원 • 안테나 브래킷 1 개 후면 패널 • PS/2 마우스 / 키보드 포트 1 개...
  • Seite 136 • 4 핀 12V 전원 커넥터 1 개 • 전면 패널 오디오 커넥터 1 개 • Thunderbolt AIC 커넥터 1 개 (5 핀 ) (ASRock Thunderbolt 3 AIC R2.0 카드 만 지원 ) • USB 2.0 헤더 2 개 (USB 2.0 포트 4 개 지원 ) (ESD 보호 지원 ) •...
  • Seite 137 • FCC, CE 인증 • ErP/EuP 사용 가능 (ErP/EuP 사용 가능 전원공급장치 필요 ) * 자세한 제품 정보에 대해서는 당사 웹사이트를 참조하십시오 : http://www.asrock.com BIOS 설정을 조정하거나 Untied Overclocking Technology 를 적용하거나 타업체의 오버클로킹 도구를 사용하는 것을 포함하는 오버클로킹에는 어느 정도의 위험이...
  • Seite 138 1.3 점퍼 설정 그림은 점퍼를 어떻게 설정하는지 보여줍니다 . 점퍼 캡을 핀에 씌우면 점퍼가 “단락” 됩니다 . 점퍼 캡을 핀에 씌우지 않으면 점퍼가 “단선”됩니다 . Clear CMOS 점퍼 (CLRMOS1) 2-pin Jumper (1 페이지 , 30 번 항목 참조 ) CLRMOS1 을 사용하여 CMOS 에 저장된 데이터를 지울 수 있습니다 . 시스템 파라미터를...
  • Seite 139 H470 Phantom Gaming 4 1.4 온보드 헤더 및 커넥터 온보드 헤더와 커넥터는 점퍼가 아닙니다 . 점퍼 캡을 온보드 헤더와 커넥터에 씌우지 마십시오 . 점퍼 캡을 온보드 헤더와 커넥터에 씌우면 마더보드가 영구적으로 손상됩니다 . 섀시의 전원 버튼 , 리셋 버튼 , 시스템...
  • Seite 140 전원 LED 및 스피커 헤더 SPEAKER 섀시 전원 LED 와 섀시 DUMMY (7 핀 SPK_PLED1) 스피커를 이 헤더에 DUMMY (1 페이지 , 19 번 항목 참조 ) 연결하십시오 . PLED+ PLED+ PLED- 시리얼 ATA3 커넥터 이들 6 개의 SATA3 커넥터는 (SATA3_0: 최대...
  • Seite 141 H470 Phantom Gaming 4 USB 3.2 Gen1 헤더 이 마더보드에는 헤더 두 Vbus Vbus Vbus IntA_PB_SSRX- (19 핀 USB3_3_4) 개가 있습니다 . 각 USB 3.2 IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (1 페이지 , 11 번 항목 참조 ) Gen1 헤더는 포트 두 개를...
  • Seite 142 섀시 / 워터 펌프 팬 커넥터 이 마더보드에는 4 핀 수냉식 (4 핀 CHA_FAN1/WP) 섀시 팬 커넥터 4 개가 FAN_VOLTAGE (1 페이지 , 12 번 항목 참조 ) 탑재되어 있습니다 . 3 핀 섀시 CHA_FAN_SPEED FAN_SPEED_CONTROL 수냉식 쿨러 팬을 연결하려는 경우...
  • Seite 143 H470 Phantom Gaming 4 ATX 12V 전원 커넥터 이 마더보드에는 8 핀 (8 핀 ATX12V1) ATX 12V 전원 커넥터가 (1 페이지 , 1 번 항목 참조 ) 탑재되어 있습니다 . 4 핀 ATX 전원공급장치를 사용하려면 핀 1 과 핀 5 을...
  • Seite 144 RGB LED 헤더 RGB 헤더는 다양한 LED 조명 (4 핀 RGB_LED1) 효과를 선택할 수 있는 RGB 12V G R (1 페이지 , 28 번 항목 참조 ) LED 연장 케이블을 연결하는 데 사용됩니다 . 주의 : RGB LED 케이블을 (4 핀 RGB_LED2) (1 페이지...
  • Seite 145 のウェブサイ トでは、 最新の VGA カードおよび CPU サポート一覧もご覧になれます。 ASRock ウェブサイ ト http://www.asrock.com. 1.1 パッケージの内容 • ASRock H470 Phantom Gaming 4 マザーボード (ATX フォームファクター) • ASRock H470 Phantom Gaming 4 クイックインストールガイ ド • ASRock H470 Phantom Gaming 4 サポート CD • 2 x シリアル ATA (SATA) データケーブル (オプション)...
  • Seite 146 メモリ • 4 x DDR4 DIMM スロッ ト • DDR4 2933/2800/2666/2400/2133 ノン ECC、 アンバッファードメ モリに対応 * 詳細については、 ASRock ウェブサイ トのメモリーサポート一覧 を参照してく ださい。 (http://www.asrock.com/) (i9/i7) は最大 2933 までの DDR4 に対応します ; Core * Core (i5/i3), Pentium® および Celeron® は最大 2666 までの DDR4 に対...
  • Seite 147 H470 Phantom Gaming 4 * Intel ョ UHD グラフィ ックス内蔵ビジュアルおよび VGA 出力は、 グラフ ィ ッ クス GPU に統合されたプロセッサーのみでサポートされます。 • ハードウェア ・ アクセラレイティ ド ・ コーデック : AVC/H.264、 HEVC/H.265 8- ビッ ト、 HEVC/H.265 10- ビッ ト、 VP8、 VP9 8- ビッ ト、 VP9 10- ビッ ト、 MPEG2、 MJPEG、 VC-1 * VP9 10 ビッ...
  • Seite 148 • 1 x Ultra M.2 ソケッ ト (M2_2)、 M Key タイプ 2260/2280/22110 M.2 SATA3 6.0 Gb/s モジュール、 および、 最大 Gen3 x4 (32 Gb/s) までの M.2 PCI Express モジュールに対応 ** テク ノロジーに対応 ** Intel® Optane ** 起動ディスクとして NVMe SSD に対応 ** ASRock U.2 キッ トに対応...
  • Seite 149 H470 Phantom Gaming 4 • 1 x SPI TPM ヘッダー コネクタ • 1 x 電源 LED とスピーカーヘッダー • 2 x RGB LED ヘッダー * 合計 12V/3A、 36W までの LED ストリ ップに対応 • 2 x アドレサブル LED ヘッダー * 合計 5V/3A、 15W までの LED ストリ ップに対応...
  • Seite 150 PCH、 VCCSA、 VCCST、 VCCIO • Microsoft® Windows® 10 64-bit 認証 • FCC、 CE • ErP/EuP Ready ( ErP/EuP 対応電源供給装置が必要です) * 商品詳細については、 当社ウェブサイ トをご覧く ださい。 http://www.asrock.com BIOS 設定の調整、 アンタイ ドオーバークロックテク ノロジーの適用、 サードパーティの オーバークロックツールの使用などを含む、 オーバークロックには、 一定のリスクを伴 いますのでご注意く ださい。 オーバークロックするとシステムが不安定になったり、 シ ステムのコンポーネントやデバイスが破損するこ とがあります。 ご自分の責任で行って...
  • Seite 151 H470 Phantom Gaming 4 1.3 ジャンパー設定 このイラストは、 ジャンパーの設定方法を示しています。 ジャンパーキャップがピンに被 さっていると、 ジャンパーは 「ショート」 です。 ジャンパーキャップがピンに被さっていない 場合には、 ジャンパーは 「オープン」 です。 CMOS クリアジャンパー (CLRMOS1) 2-pin Jumper (p.1、 No. 30 参照) CLRMOS1 を使って CMOS 内のデータをクリアできます。 ク リアして、 デフォルト設定に システムパラメーターをリセッ トするには、 コンピューターの電源を切り、 電源から電源 コードを抜いてく ださい。 15 秒間待ってから、 ジャンパーキャップを使用して CLRMOS1 上のピンを...
  • Seite 152 1.4 オンボードのヘッダーとコネクタ オンボードヘッダーとコネクタはジャンパーではありません。 これらヘッダーとコネクタ にはジャンパーキャップを被せないでく ださい。 ヘッダーおよびコネクタにジャンパー キャップを被せると、 マザーボードに物理損傷が起こるこ とがあります。 システムパネルヘッダー 電源ボタンを接続し、 ボタンを PLED+ PLED- (9 ピン PANEL1) リセッ トし、 下記のピン割り当て PWRBTN# (p.1、 No. 22 参照) に従って、 シャーシのシステムス テータス表示ランプをこのヘッ RESET# ダーにセッ トします。 ケーブル HDLED- を接続するときには、 ピンの+ HDLED+ と−に気をつけてく ださい。 PWRBTN (電源ボタン) : シャーシ前面パネルの電源ボタンに接続してく...
  • Seite 153 H470 Phantom Gaming 4 電源 LED とスピーカーヘ シャーシ電源 LED とシャーシス SPEAKER DUMMY ッダー ピーカーをこのヘッダーに接続 DUMMY (7 ピン SPK_PLED1) してく ださい。 (p.1、 No. 19 参照) PLED+ PLED+ PLED- シリアル ATA3 コネクタ これら 6 つの SATA3 コネクター (SATA3_0: は、 最高 6.0 Gb/ 秒のデータ転...
  • Seite 154 USB 3.2 Gen1 ヘッダー このマザーボードには 2 つの Vbus Vbus Vbus IntA_PB_SSRX- (19 ピン USB3_3_4) ヘッダーが装備されています。 IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (p.1、 No. 11 参照) 各 USB 3.2 Gen1 ヘッダーは、 2 IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (19 ピン USB3_5_6) つのポートをサポートできます。 IntA_PA_SSTX+ IntA_PB_D- (p.1、 No. 24 参照) IntA_PA_D- IntA_PB_D+ IntA_PA_D+...
  • Seite 155 H470 Phantom Gaming 4 シャーシ / ウォーターポ このマザーボードには 4 つの 4 ンプファンコネクタ ピン水冷却シャーシがコネクタ FAN_VOLTAGE (4 ピン CHA_FAN1/WP) 用に装備されています。 3 ピン CHA_FAN_SPEED FAN_SPEED_CONTROL (p.1、 No. 12 参照) のシャーシ水冷却ファンを接続 する場合には、 ピン 1-3 に接続 (4 ピン CHA_FAN2/WP) してく ださい。 FAN_SPEED_CONTROL CHA_FAN_SPEED (p.1、 No. 32 参照)...
  • Seite 156 ATX 12V 電源コネクタ このマザーボードは 8 ピン (8 ピン ATX12V1) ATX12V 電源コネクタが装備さ (p.1、 No. 1 参照) れています。 4 ピンの ATX 電源 を使用するには、 ピン 1 と 5 に 合わせて接続してく ださい。 ATX 12V 電源コネクタ ATX 12V 電源をこのコネクタに (4 ピン ATX12V2) 接続してく ださい。 * 電源供給プ (p.1、...
  • Seite 157 H470 Phantom Gaming 4 RGB LED ヘッダー RGB ヘッダーは RGB LED 延長 (4 ピン RGB_LED1) ケーブルの接続に使用され、 こ 12V G R (p.1、 No. 28 参照) れによりユーザーはさまざまな LED 証明効果から選択するこ と (4 ピン RGB_LED2) ができます。 (p.1、 No. 7 参照) 注意 : RGB LED ケーブルは間...
  • Seite 158 不会另外进行通知。如果您需要与此主板相关的技术支持,请访问我们的网站以 具体了解所用型号的信息。您也可以在华擎网站上找到最新 VGA 卡和 CPU 支持列 表。华擎网站 http://www.asrock.com。 1.1 包装清单 • 华擎 H470 Phantom Gaming 4 主板(ATX 规格尺寸) • 华擎 H470 Phantom Gaming 4 快速安装指南 • 华擎 H470 Phantom Gaming 4 支持光盘 • 2 x 串行 ATA (SATA) 数据线(选购) • 3 x 螺丝(供 M.2 插座使用)(选购)...
  • Seite 159 H470 Phantom Gaming 4 1.2 规格 • ATX 规格尺寸 平台 • 稳固的电容器设计 • 支持第 10 代 Intel® Core 处理器(插座 1200) • Digi Power design • 10 电源相设计 • 支持 Intel® Turbo Boost MAX 3.0 技术 • Intel® H470 芯片集 • 双通道 DDR4 内存技术...
  • Seite 160 * 只有 GPU 集成的处理器才支持 Intel® UHD Graphics 内置视效 图形 和 VGA 输出。 • 硬件加速编解码器:AVC/H.264、HEVC/H.265 8-bit、 HEVC/H.265 10-bit、VP8、VP9 8-bit、VP9 10-bit、MPEG2、 MJPEG、VC-1 * VP9 10 位和 VC-1 仅用于解码。 * Windows 操作系统不支持 VP8 和 VP9 编码。 • 显卡、媒体和计算:Microsoft DirectX 12、OpenGL 4.5、 Intel® Built In Visuals、Intel® 高速视频同步、混合 / 可切换显 卡、OpenCL 2.1 •...
  • Seite 161 H470 Phantom Gaming 4 • 1 x 天线支架 后面板 I/O • 1 x PS/2 鼠标 / 键盘端口 • 1 x HDMI 端口 • 1 x DisplayPort 1.4 • 1 x USB 3.2 Gen2 A 类型端口 (10 Gb/s) (ReDriver)(支持 ESD 保护)...
  • Seite 162 • 1 x SPI TPM 接脚 接口 • 1 x 电源 LED 和扬声器接脚 • 2 x RGB LED 接头 * 总共支持最高 12V/3A, 36W LED 灯条 • 2 x 可寻址 LED 接脚 * 总共支持最高 5V/3A, 15W LED 灯条 • 1 x CPU 风扇接口(4 针) * CPU 风扇接口支持最高...
  • Seite 163 H470 Phantom Gaming 4 • Microsoft® Windows® 10 64-bit 操作系统 • FCC、CE 认证 • ErP/EuP 支持(需要支持 ErP/EuP 的电源) * 有关详细产品信息,请访问我们的网站:http://www.asrock.com 须认识到超频会有一定风险,包括调整 BIOS 设置,应用“自由超频技术”,或使用 第三方超频工具。超频可能会影响到系统的稳定性,甚至对系统的组件和设备造成 损坏。执行这项工作您应自担风险和费用。我们对由于超频而造成的损坏概不负责。...
  • Seite 164 1.3 跳线设置 此图显示如何设置跳线。将跳线帽装到这些针脚上时,跳线“短接”。如果这些针脚 上没有装跳线帽,跳线“开路”。 清除 CMOS 跳线 (CLRMOS1) 2-pin Jumper (见第 1 页,第 30 个) CLRMOS1 允许您清除 CMOS 中的数据。要清除和重置系统参数到默认设置,请关 闭计算机,从电源上拔下电源线插头。等候 15 秒后,使用跳线帽将 CLRMOS1 上的 针脚短接 5 秒。但是,请勿在更新 BIOS 后立即清除 CMOS。如果您需要在刚完成 BIOS 更新后清除 CMOS,则必须先启动系统,并在关闭后再执行清除 CMOS 操作。 请注意,密码、日期、时间和用户默认配置文件只在卸下 CMOS 电池后才会被清 除。请记住在清除 CMOS 后取下跳线帽。...
  • Seite 165 H470 Phantom Gaming 4 1.4 板载接脚和接口 板载接脚和接口不是跳线。不要将跳线帽装到这些接脚和接口上。将跳线帽装到这 些接脚和接口上将会对主板造成永久性损坏。 系统面板接头 按照下面的针脚分配,将机箱 PLED+ PLED- (9 针 PANEL1) PWRBTN# 上的电源按钮、重置按钮和系 (见第 1 页,第 22 个) 统状态指示灯连接到此接脚。 在连接线缆前请记下正负针脚。 RESET# HDLED- HDLED+ PWRBTN( 电源按钮): 连接到机箱前面板上的电源按钮。您可以配置使用电源按钮关闭系统的方式。 RESET( 重置按钮): 连接到机箱前面板上的重置按钮。如果计算机死机,无法执行正常重新启动,按重置 按钮重新启动计算机。 PLED( 系统电源 LED): 连接到机箱前面板上的电源状态指示灯。系统操作操作时,此 LED 亮起。系统处在...
  • Seite 166 电源 LED 和扬声器接脚 SPEAKER 请将机箱电源 LED 和机箱扬声 DUMMY (7 针 SPK_PLED1) 器连接到此接脚。 DUMMY (见第 1 页,第 19 个) PLED+ PLED+ PLED- 串行 ATA3 接口 这六个 SATA3 接口支持最高 6.0 Gb/s 数据传输速率的内部存储 (SATA3_0: 见第 1 页,第 14 个) 设备的 SATA 数据线。 (SATA3_1: * 如果...
  • Seite 167 H470 Phantom Gaming 4 USB 3.2 Gen1 接脚 此主板上有 2 个接脚。每个 Vbus Vbus Vbus IntA_PB_SSRX- (19 针 USB3_3_4) USB 3.2 Gen1 接脚可以支持两个 IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (见第 1 页,第 11 个) 端口。 IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (19 针 USB3_5_6) IntA_PA_SSTX+ IntA_PB_D- (见第 1 页,第 24 个)...
  • Seite 168 机箱 / 水泵风扇接口 此主板提供四个 4 针水冷机箱 (4 针 CHA_FAN1/WP) 风扇接口。如果您打算连接 3 FAN_VOLTAGE (见第 1 页,第 12 个) 针机箱水冷风扇,请将它连接 CHA_FAN_SPEED FAN_SPEED_CONTROL 到针脚 1-3。 FAN_SPEED_CONTROL (4 针 CHA_FAN2/WP) CHA_FAN_SPEED FAN_VOLTAGE (见第 1 页,第 32 个) (4 针 CHA_FAN3/WP) (见第 1 页,第 23 个) FAN_SPEED_CONTROL CHA_FAN_SPEED FAN_VOLTAGE...
  • Seite 169 H470 Phantom Gaming 4 ATX 12V 电源接口 此主板提供 8 针 ATX 12V 电源 (8 针 ATX12V1) 接口。要使用 4 针 ATX 电源, (见第 1 页,第 1 个) 请沿针脚 1 和针脚 5 插接它。 ATX 12V 电源接口 请将 ATX 12V 电源连接到此接 (4 针 ATX12V2)...
  • Seite 170 可寻址 LED 接脚 此接脚用于连接可寻址 LED 延 (3 针 ADDR_LED1) 长线,可让用户选择不同的 DO_ADDR (见第 1 页,第 27 个) LED 灯光效果。 VOUT 注意:必须以正确的方向安装可 寻址 LED 线,否则会损坏线缆。 (3 针 ADDR_LED2) (见第 1 页,第 8 个) * 请参考第 37 页了解这个接脚 的详情。...
  • Seite 171 H470 Phantom Gaming 4 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2006「电子信 息产品污染控制标示要求」,电子信息产品应进行标示,藉以向消费者揭露产品 中含有的有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、 财产造成严重损害的期限。依上述规定,您可于本产品之印刷电路板上看见图一 之标示。图一中之数字为产品之环保使用期限。由此可知此主板之环保使用期限 为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明,请参照以下表格及 说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定...
  • Seite 172 如本文件有任何修改,可至華擎網站逕行取得更新版本,不另外通知。若您需要與本 主機板相關的技術支援,請上我們的網站瞭解有關您使用機型的特定資訊。您也可以 在華擎網站找到最新的 VGA 卡及 CPU 支援清單。華擎網站 http://www.asrock.com。 1.1 包裝內容 • 華擎 H470 Phantom Gaming 4 主機板(ATX 尺寸) • 華擎 H470 Phantom Gaming 4 快速安裝指南 • 華擎 H470 Phantom Gaming 4 支援光碟 • 2 x Serial ATA (SATA) 資料纜線(選用) • 3 x 螺絲(適用於 M.2 插座)(選用)...
  • Seite 173 H470 Phantom Gaming 4 1.2 規格 • ATX 尺寸 平台 • 固態電容設計 • 支援第 10 代 Intel® Core 處理器 (Socket 1200) • Digi Power design • 10 電源相位設計 • 支援 Intel® Turbo Boost MAX 3.0 技術 • Intel® H470 晶片組...
  • Seite 174 * 僅限整合 GPU 的處理器才可支援 Intel® UHD Graphics Built-in 顯示卡 Visuals 及 VGA 輸出。 • 硬體加速編解碼器:AVC/H.264、HEVC/H.265 8 位元、 HEVC/H.265 10 位元、VP8、VP9 8 位元、VP9 10 位元、 MPEG2、MJPEG、VC-1 * VP9 10bit 和 VC-1 僅用於解碼。 * Windows 作業系統不支援 VP8 和 VP9 編碼。 • 顯示卡、媒體和運算:Microsoft DirectX 12、OpenGL 4.5、 Intel®...
  • Seite 175 H470 Phantom Gaming 4 • Gigabit LAN 10/100/1000 Mb/s • Giga PHY Intel® I219V • 支援網路喚醒 • 支援雷擊/靜電保護 • 支援 802.3az EEE 節能乙太網路 • 支援 PXE • 1 x 天線架 後面板 I/O • 1 x PS/2 滑鼠/鍵盤連接埠 • 1 x HDMI 連接埠...
  • Seite 176 • 1 x SPI TPM 排針 接頭 • 1 x 電源 LED 及喇叭排針 • 2 x RGB LED 排針 * 總計最高支援 12V/3A,36W LED 條燈 • 2 x 可定址 LED 排針 * 總計最高支援 5V/3A,15W LED 條燈 • 1 x CPU 風扇接頭 (4-pin) * CPU 風扇接頭支援最高...
  • Seite 177 H470 Phantom Gaming 4 • 溫度感應:CPU、CPU / 水冷幫浦、機殼 / 水冷幫浦風扇 硬體顯示器 • 風扇轉速計:CPU、CPU / 水冷幫浦、機殼 / 水冷幫浦風扇 • 靜音風扇(依 CPU 溫度自動調整機殼風扇速度) :CPU、 CPU / 水冷幫浦、機殼 / 水冷幫浦風扇 • 風扇多重速度控制:CPU、CPU / 水冷幫浦、機殼 / 水冷幫 浦風扇 • 電壓監控:+12V、+5V、+3.3V、CPU Vcore、DRAM、 VPPM、PCH、VCCSA、VCCST、VCCIO • Microsoft® Windows® 10 64-bit 作業系統...
  • Seite 178 1.3 跳線設定 圖例顯示設定跳線的方式。當跳線帽套在針腳上時,該跳線為「短路」。若沒有跳線 帽套在針腳上,該跳線為「開啟」。 清除 CMOS 跳線 (CLRMOS1) 2-pin Jumper (請參閱第 1 頁,編號 30) 您可利用 CLRMOS1 清除 CMOS 中的資料。若要清除及重設系統參數為預設設定, 請先關閉電腦電源,再拔下電源供應器的電源線。在等待 15 秒後,請使用跳線帽 讓 CLRMOS1 上的 pin 短路約 5 秒。不過,請不要在更新 BIOS 後立即清除 CMOS。 若您需在更新 BIOS 後立即清除 CMOS,則必須先重新啟動系統,然後於進行清除 CMOS 動作前關機。請注意,只有在取出 CMOS 電池時才會清除密碼、日期、時間 及使用者預設設定檔。請牢記,務必在清除...
  • Seite 179 H470 Phantom Gaming 4 1.4 板載排針及接頭 板載排針及接頭都不是跳線。請勿將跳線帽套在這些排針及接頭上。將跳線帽套在 排針及接頭上,將造成主機板永久性的受損。 系統面板排針 請依照以下的針腳排列將機 PLED+ PLED- (9-pin PANEL1) PWRBTN# 殼上的電源按鈕、重設按鈕 (請參閱第 1 頁,編號 22) 及系統狀態指示燈連接至此 排針。在連接纜線之前請注 RESET# 意正負針腳。 HDLED- HDLED+ PWRBTN(電源按鈕) : 連接至機殼前面板上的電源按鈕。您可設定使用電源按鈕關閉系統電源的方式。 RESET(重設按鈕) : 接至機殼前面板上的重設按鈕。若電腦當機且無法執行正常重新啟動,按下重設按 鈕即可重新啟動電腦。 PLED(系統電源 LED) : 連接至機殼前面板上的電源狀態指示燈。系統正在運作時,此 LED 會亮起。系統 進入 S1/S3 睡眠狀態時,LED 會持續閃爍。系統進入 S4 睡眠狀態或關機 (S5) 時,...
  • Seite 180 電源 LED 及喇叭排針 SPEAKER 請將機殼電源 LED 及機殼喇 DUMMY (7-pin SPK_PLED1) 叭連接至此排針。 DUMMY (請參閱第 1 頁,編號 19) PLED+ PLED+ PLED- Serial ATA3 接頭 這六組 SATA3 接頭皆支援內 部儲存裝置的 SATA 資料纜 (SATA3_0: 請參閱第 1 頁,編號 14) 線,最高可達 6.0 Gb/s 資料 (SATA3_1: 傳輸率。 請參閱第 1 頁,編號 13) * 若...
  • Seite 181 H470 Phantom Gaming 4 USB 3.2 Gen1 排針 本主機板上含有兩組排針。 Vbus Vbus Vbus IntA_PB_SSRX- (19-pin USB3_3_4) 各 USB 3.2 Gen1 排針皆可支 IntA_PA_SSRX- IntA_PB_SSRX+ IntA_PA_SSRX+ (請參閱第 1 頁,編號 11) 援兩個連接埠。 IntA_PB_SSTX- IntA_PA_SSTX- IntA_PB_SSTX+ (19-pin USB3_5_6) IntA_PA_SSTX+ IntA_PB_D- (請參閱第 1 頁,編號 24) IntA_PA_D-...
  • Seite 182 本主機板配備四個 4-Pin 水 機殼/水冷幫浦風扇接頭 (4-pin CHA_FAN1/WP) 冷機殼風扇接頭。若您計畫 FAN_VOLTAGE (請參閱第 1 頁,編號 12) 連接 3-Pin CPU 機殼水冷風 CHA_FAN_SPEED FAN_SPEED_CONTROL 扇,請接至 Pin 1-3。 (4-pin CHA_FAN2/WP) FAN_SPEED_CONTROL CHA_FAN_SPEED (請參閱第 1 頁,編號 32) FAN_VOLTAGE (4-pin CHA_FAN3/WP) (請參閱第 1 頁,編號 23) FAN_SPEED_CONTROL CHA_FAN_SPEED FAN_VOLTAGE (4-pin CHA_FAN4/WP) FAN_VOLTAGE (請參閱第...
  • Seite 183 H470 Phantom Gaming 4 ATX 12V 電源接頭 本主機板配備一組 8-pin ATX (8-pin ATX12V1) 12V 電源接頭。若要使用 (請參閱第 1 頁,編號 1) 4-pin ATX 電源供應器,請插 入 Pin 1 及 Pin 5。 ATX 12V 電源接頭 請將 ATX 12V 電源接至此接 (4-pin ATX12V2) 頭。* 電源插頭僅能以單一 (請參閱第 1 頁,編號 2)...
  • Seite 184 RGB LED 排針 RGB 排針用於連接 RGB LED (4-pin RGB_LED1) 延長線,可供使用者選擇各 12V G R (請參閱第 1 頁,編號 28) 種 LED 照明效果。 警告:切勿以錯誤方向安裝 (4-pin RGB_LED2) RGB LED 纜線,否則纜線可 (請參閱第 1 頁,編號 7) 能損壞。 * 關於這種排針的詳細說明, 請參閱第 36 頁。 可定址 LED 排針 此排針用於連接可讓使用者 (3-pin ADDR_LED1) 選擇各種...
  • Seite 185 • Teknologi Memori DDR4 Dua Saluran • 4 x Slot DIMM DDR4 • Mendukung DDR4 2933/2800/2666/2400/2133 non-ECC, memori tanpa buffer * Lihat Daftar Dukungan Memori pada situs web ASRock untuk informasi selengkapnya. (http://www.asrock.com/) * Core (i9/i7) mendukung DDR4 hingga 2933; Core (i5/i3), Pentium®...
  • Seite 186 Grafis * Intel® UHD Graphics Built-in Visuals dan output VGA hanya didukung dengan prosesor yang terintegrasi GPU. • Codec Yang Dipercepat Hardware: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit, MPEG2, MJPEG, VC-1 * VP9 10bit dan VC-1 hanya untuk mendekode. * Enkode VP8 danVP9 tidak didukung olej Windows OS.
  • Seite 187 H470 Phantom Gaming 4 • Gigabit LAN 10/100/1000 Mb/s • Giga PHY Intel® I219V • Mendukung Wake-On-LAN • Mendukung Perlindungan dari Petir/ESD • Mendukung Ethernet 802.3az Hemat Energi • Mendukung PXE I/O Panel • 1 x Braket Antena • 1 x Port Mouse/Keyboard PS/2 Belakang • 1 x Port HDMI...
  • Seite 188 Konektor • 1 x Header SPI TPM • 1 x Header LED Daya dan Speaker • 2 x Header LED RGB * Mendukung total Strip LED hingga 12V/3A, 36W • 2 x Addressable LED Header * Mendukung total Strip LED hingga 5V/3A, 15W • 1 x Konektor Kipas CPU (4-pin) * Konektor Kipas CPU mendukung kipas CPU dengan daya kipas maksimum 1A (12W).
  • Seite 189 • FCC, CE • Mendukung ErP/EuP (memerlukan catu daya untuk ErP/EuP) * Untuk informasi rinci tentang produk, kunjungi situs web kami: http://www.asrock.com Perlu diketahui, overclocking memiliki risiko tertentu, termasuk menyesuaikan pengaturan pada BIOS, menerapkan Teknologi Untied Overclocking, atau menggunakan alat bantu overclocking pihak ketiga.
  • Seite 190: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...
  • Seite 191: Declaration Of Conformity

    13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard H470 Phantom Gaming 4 Model Number : Conforms to the following speci cations: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: is device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Seite 192: Eu Declaration Of Conformity

    EU Declaration of Conformity For the following equipment: Motherboard (Product Name) H470 Phantom Gaming 4 / ASRock (Model Designation / Trade Name) ASRock Incorporation (Manufacturer Name) 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address) EMC —Directive 2014/30/EU (from April 20th, 2016)

Inhaltsverzeichnis
