CHAPTER -3: USING YOUR FRIDGE FREEZER

Temperature indicator

In order to help you better set your refrigerator, we have equipped it with a temperature indicator located in
the coldest area.
To better store the food in your refrigerator, especially in the coldest area, make sure the message "OK"
appears on the temperature indicator. If « OK » does not appear, this means temperature has not been set
properly
It may be difficult to see the indicator, make sure it is properly lit.Each time the temperature setting device is
changed, wait for the stabilisation of the temperature inside the appliance before proceeding, if necessary,
with a new temperature setting. Please change the position of the temperature setting device progressively and wait at
least 12 hours before starting a new check and potential change.
NOTE: Following repeated openings (or prolonged opening) of the door or after putting fresh food into the appliance,
it is normal for the indication "OK" not to appear in the temperature setting indicator. If there is an abnormal build up
of ice crystals of ice crystals (bottom wall of the appliance) on the refrigerator compartment, evaporator (overloaded
appliance, high room temperature, frequent door openings), put the temperature setting device on a lower position until
compressor off periods are obtained again.
Store food in the coldest area of the refrigerator.
Your foods will be better stored if you put them in the most appropriate
cooling area. The coldest area is just above the crisper.
The following symbol indicates the coldest area of your refrigerator.
To be sure to have a low temperature in this area, make sure the shelf is
located at the level of this symbol, as shown in the illustration.
The upper limit of the coldest area is indicated by the lower side of the sticker (head of
the arrow). The coldest area upper shelf must be at the same level with the arrow head.
The coldest area is below this level.
As these shelves are removable, make sure they are always at the same level with
these zone limits described on the stickers, in order to guarantee temperatures in this
area.

Accessories

Ice box
• To remove the ice box; pull the upper freezer box out as far as possible and
then pull the ice box out.
• Fill 3/4 full of water and place the ice box in it freezer.
Note: While placing the ice box in the freezer, place it in a horizontal position.
Otherwise the water in the ice box can spill.

Freezer box

• The freezer box is for foods that need to be accessed more easily.
• Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
! Make the inverse of the same operation for the resetting the sliding
compartment.
Note: Always hold the handle of box while moving in or out.
Roller storage box
You can use this compartment for two different functions.
Note: Your fridge is delivered to you with the shown section in the open
position. The declared energy consumption and volume are according
to this setting.
1. To use for 0 °C Department: If you want to use this compartment
as 0 °C box you must take the sliding part (cover, which is indicated
in picture) from closed position to open position.
2. To use for Crisper Department: If you want to use this
compartment as crisper, you must take the sliding part (cover, which
is indicated in picture) from open position to closed position.
• While this compartment is used as an 0 °C compartment, food
retains freshness and for longer.
• Pull the chiller shelf out toward you. The cover will open
automatically.
Please note this this is not a freezer compartment.
Ice box
EN -10-
sliding part
OK
