Seite 1
ITALIANO ESPAÑOL OPERATOR'S MANUAL BEDIENUNGSANLEITUNG MANUALE PER L'OPERATORE MANUAL DE INSTRUCCIONES SRM-265 WARNING READ THE INSTRUCTIONS CAREFULLY AND FOLLOW THE RULES FOR SAFE OPERATION. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY. WARNUNG LESEN SIE DIE BEDIENUNGSANLEITUNG SORGFÄLTIG DURCH, UND BEFOLGEN SIE DIE SICHERHEITSREGELN.
Seite 3
1Cover ENGLISH (Original instructions) OPERATOR'S MANUAL GRASS-TRIMMER/BRUSHCUTTER SRM-265 WARNING READ THE INSTRUCTIONS CAREFULLY AND FOLLOW THE RULES FOR SAFE OPERATION. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY.
Contents For safe use of your product....................3 Description.......................... 8 Before you start ........................9 Packing list ........................9 Assembly ........................10 Loop handle version ....................10 U-handle version......................11 Adjusting the balance ....................13 Preparing the fuel ......................15 Engine operation.......................
For safe use of your product For safe use of your product Important information WARNING Please ensure that you read the operator's manual before using your product. About your operator's manual This manual contains necessary information about the assembly, operation, and maintenance of your product. Please read it carefully and absorb its contents.
Seite 6
For safe use of your product WARNING Vibration and cold It is believed that a condition called Raynaud's Phenomenon which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning, followed by loss of colour and numbness in the fingers.
For safe use of your product WARNING Environment of use and operation Do not use the product: under poor weather conditions. on steep slopes or in places which give no secure foothold and are thus slippery. at night or in dark places with poor visibility. ...
Seite 8
For safe use of your product Symbol form/shape Symbol description/applica- Symbol form/shape Symbol description/applica- tion tion Wear foot protection and Petrol and oil mixture gloves Choke Control "Cold Start" Emergency stop Position (Choke Closed) Warning! Choke Control "Run" Position Thrown objects! (Choke Open) Carburettor adjustment Warning, side thrust...
For safe use of your product Safety decal(s) The safety decal shown below has been attached to the products described in this manual. Ensure that you understand what the decal means before using your product. If the decal becomes unreadable due to wear and tear or damage, or peels off and is lost, please purchase a replacement decal from your dealer and attach it in the location shown in the illustrations below.
Description Description Angle transmission Having two gears to change the 10. Ignition switch "Slide switch" mounted on top of the angle of rotating axis. throttle trigger housing, move switch forward to RUN, Cutting attachment Nylon line cutting head for cutting backward to STOP position.
Before you start Before you start Packing list The following parts are packed separately in the packing box. When you have unpacked the box, please check the parts that it contains. Contact your dealer if anything is missing or broken. 1.
Before you start Assembly WARNING Read the operator's manual carefully to ensure that you assemble the product correctly. Using a product that has been incorrectly assembled could lead to an accident or serious injury. Loop handle version Loop handle assembly Assemble loop handle (A) and bracket (C) to drive shaft assem- bly.
Before you start Installing nylon line cutting head Insert locking tool (A) into a hole located on the right side of angle transmission while forcing retainer spring to the left side. Insert locking tool further into blade retainer fixing slot (B) to fix output shaft.
Seite 14
Before you start CAUTION After assembly, adjust the play of wire end (J) on carbu- rettor (L) side to 1 mm - 2 mm. K: Nuts Installation of shield Fit shield (A) to mounting portion of angle transmission and tighten 4 bolts (B).
Before you start Inspect blades (A) before installation. Check for sharpness. Dull blades increase the risk of blade kickback reactions. Small cracks can develop into fractures resulting in a piece of blade flying off during operation. Discard cracked blades no matter how small the crack. Insert locking tool (B) into a hole located on the right side of angle transmission while forcing retainer spring to the left side.
Seite 16
Before you start Slide suspension point up and down the tube to find the right balance. Rotate the clamp to level the cutting attachment and shield. Lock in position. If the suspension point is a free-spin- ning type, the unit may tend to roll over sideways, however, you should still level the attachment and shield on the front-to- rear axis.
Stored fuel ages. Do not mix more fuel than you expect to use in thirty (30) days. Fuel Recommended mixture ratio; 50: 1 (2%) for ISO-L-EGD Standard (ISO/CD 13738), JASO FC,FD grade and ECHO Premium 50: 1 oil. Do not mix directly in engine fuel tank.
Engine operation Engine operation Starting the engine WARNING Be particularly careful to observe the following precautions when starting the engine: Move at least 3m from the place where you refuelled. Place the product in a flat, well ventilated place. ...
Engine operation Move the choke lever (F) to the "Cold Start" (E) position. Alternately press and release the purge bulb (H) until the fuel is sucked up into it. Checking that the area around you is safe, hold the position closest to the engine firmly as shown in the illustration, pull- ing several times on the starter grip (I).
Trimming operation Trimming operation DANGER Always stop the engine when a cutting attachment jam occurs. Severe injury can occur if a jam is removed and the cutting attachment suddenly starts. Do not operate the product without the shield in place. Any objects that ricochet off the cutting attachment could cause an accident or serious injury.
Trimming operation Using shoulder harness Always mount the trimmer correctly using the shoulder har- ness. Buckle waist belt. Belt should be snug. Attach product to harness. Loop handle version Place shoulder harness over left shoulder and adjust straps so the quick release pin rests just below the waist.
Seite 22
Trimming operation Scything This is the cutting or mowing of large grassy areas by sweep- ing or swinging the trimmer in a level arc. Use a smooth, easy motion. Do not try to hack or chop down the grass. Tilt the ny- lon line cutting head to direct the debris away from you on the scything stroke.
Trimming operation Basic trimming operation with metal blade WARNING Please observe the following instructions when trimming. Check to ensure that the trimmer blade has been tightened securely in place. Replace the shield if it is damaged or cracked. ...
Maintenance and care Maintenance and care WARNING Observe the following precautions when checking and maintaining your product after use: Turn the engine off and do not attempt to check or maintain the product until the engine has cooled. You could burn yourself. ...
Maintenance and care Replacing fuel filter Use a piece of metal wire or the like to pick up fuel filter (A) through fuel tank opening. Pull old filter from fuel line (B). Install new fuel filter. NOTE If filter is excessive dirty or no longer fits properly, replace it. Carburettor adjustment WARNING ...
Seite 26
Maintenance and care Remove dust and dirt from between fins (A). Before each use, remove accumulated debris from bottom en- gine intake grille located between the fuel tank and starter. Air intake Cleaning silencer Carbon deposits in silencer (A) will cause a drop in engine out- put and overheating.
Maintenance and care Checking the blade Use only blade designated for this model by the manufacturer. When a crack is noticed on the blade, do not use it but replace with a new one. Ensure that the blade is correctly fitted in accordance with the instructions.
Seite 28
Maintenance and care Press "retaining pawls" (at two places) inward and remove cover. It is easier to remove one after another. Remove spool. When nylon line on the spool is almost exhausted, remove remaining line from spool and wind "new line" according to the procedures (4) and beyond.
Maintenance and care Troubleshooting table IMPORTANT For spare parts and consumables, please use only genuine parts and designated products and components. Using parts from other manufacturers or non-designated components may result in a malfunction. Problem Diagnosis Cause Solution The engine does There is no fuel in the fuel tank Fuel supply not start...
Maintenance and care Storage Long-term storage (30 days or more) WARNING Do not store in sealed locations filled with fuel gas, or close to naked flames or sparks. You could cause a fire. When storing the product for long periods of time (30 days or more), ensure that the following preparations for storage are carried out.
Do not use fuel containing methyl alcohol or more than 10 % of ethyl alcohol. Two stroke, air-cooled engine oil. ISO-L-EGD Stand- ard (ISO/CD 13738), JASO FC,FD grade and ECHO Premium 50 : 1 oil. Ratio 50 : 1 (2%) Fuel consumption at maximum engine power 0.60 L/h...
GRASS-TRIMMER/BRUSHCUTTER Brand: ECHO Type: SRM-265 complies with: * the requirements of Directive 2006/42/EC (use of harmonized standard EN ISO 11806-1: 2011) * the requirements of Directive 2004/108/EC until 19th April 2016 (use of harmonized standard EN ISO 14982: 2009)
Seite 33
1Notes and rear cover MEMORANDUM X750-026690 X750202-5109 2013...
Seite 35
1Schutzabdeckung DEUTSCH (Original Gebrauchsanleitung) BEDIENUNGSANLEITUNG RASENTRIMMER/MOTORSENSE SRM-265 WARNUNG LESEN SIE DIE BEDIENUNGSANLEITUNG SORGFÄLTIG DURCH, UND BEFOLGEN SIE DIE SICHERHEITSREGELN. ANDERNFALLS BESTEHT DAS RISIKO SCHWERER VERLETZUNGEN.
Seite 36
Inhalt Sichere Verwendung des Produkts ..................3 Beschreibung........................8 Bevor Sie beginnen ......................9 Packliste ........................9 Zusammenbau......................10 Rundgriff-Version......................10 U-Griff-Version......................11 Ausrichten der Balance....................13 Bereitstellen des Kraftstoffs ..................15 Bedienung des Motors...................... 16 Starten des Motors ...................... 16 Stoppen des Motors ....................
Sichere Verwendung des Produkts Sichere Verwendung des Produkts Wichtige Informationen WARNUNG Lesen Sie unbedingt die Bedienungsanleitung, bevor Sie das Produkt verwenden. Allgemeines zu dieser Bedienungsanleitung Diese Bedienungsanleitung enthält wichtige Informationen über Montage, Bedienung und Instandhaltung Ihres Produkts. Bitte lesen Sie sie sorgfältig durch, und machen Sie sich mit dem Inhalt vertraut. ...
Sichere Verwendung des Produkts WARNUNG Vibration und Kälte Es wird vermutet, dass das Raynaud-Syndrom, das die Finger mancher Menschen befällt, durch stark vibrierende Arbeitsgeräte und Arbeiten bei Kälte herbeigeführt wird. Durch stark vibrierende Arbeitsgeräte und dem Arbeiten bei Kälte kann sich ein Prickeln und Brennen bemerkbar machen, dem sich Farblosigkeit und Gefühllosigkeit der Finger anschließen.
Sichere Verwendung des Produkts WARNUNG Schutzausrüstung tragen Tragen Sie beim Arbeiten mit dem Trimmer immer die folgende Schutzausrüstung: 1. Kopfschutz (Helm): schützt den Kopf 2. Gehörschutzbügel oder Ohrenstöpsel: schützen das Gehör 3. Schutzbrille: schützt die Augen 4. Gesichtsschutzschild: schützt das Gesicht 5.
Sichere Verwendung des Produkts Sonstige Kennzeichnungen HINWEIS WICHTIG Kreis mit umgekehrtem Hinweise dieser Art enthalten Tipps Umrahmter Text mit der Überschrift Schrägstrich bedeutet, zur Verwendung, Pflege und Wartung „WICHTIG“ enthält wichtige dass das Dargestellte des Produkts. Informationen zur Verwendung, unzulässig ist. Überprüfung, Wartung und Lagerung des in dieser Anleitung beschriebenen Produkts.
Sichere Verwendung des Produkts Symbol Beschreibung des Symbols Symbol Beschreibung des Symbols Nicht in Räumen mit Garantierter schlechter Belüftung Schallleistungspegel verwenden Achtung, Brandgefahr Motorstart Achtung, Stromschlag-Gefahr Kraftstoffpumpe Sicherheitsaufkleber Die in dieser Anleitung beschriebenen Produkte sind mit dem unten dargestellten Sicherheitsaufkleber versehen. Machen Sie sich die Bedeutung des Sicherheitsaufklebers bewusst, bevor Sie das Produkt verwenden.
Beschreibung Beschreibung Winkelgetriebe Ermöglicht es, den Winkel der 10. Stoppschalter Schiebeschalter, der oben am Gehäuse Rotationsachse zu andern. des Gashebels montiert ist. Schalter für den Betrieb Schneidvorrichtung Nylonfadenkopf zum Schneiden nach vorn auf „RUN", zum Stoppen des Motors nach von Gras und Unkraut. hinten auf „STOP"...
Bevor Sie beginnen Bevor Sie beginnen Packliste Die nachfolgend aufgeführten Einzelteile sind in der Verpackung enthalten. Überprüfen Sie nach dem Auspacken die Vollständigkeit des Inhalts. Wenden Sie sich an Ihren Händler, wenn Teile fehlen oder beschädigt sind. 1.
Bevor Sie beginnen Zusammenbau WARNUNG Lesen Sie die Bedienungsanleitung aufmerksam durch, um sicherzustellen, dass Sie das Produkt korrekt zusammenbauen. Die Verwendung eines falsch zusammengebauten Produkts kann zu Unfällen bzw. schweren Verletzungen führen. Rundgriff-Version Befestigung des Rundgriffs Befestigen Sie den Rundgriff (A) und die Halterung (C) am Antriebswellenrohr.
Bevor Sie beginnen Montage des Nylonfadenkopfs Stecken Sie das Arretierwerkzeug (A) in das Loch auf der rechten Seite des Winkelgetriebes. Drücken Sie dabei die Rückhaltefeder nach links. Stecken Sie das Arretierwerkzeug in das Arretierungsloch (B) der Fixierplatte, um den Werkzeugaufnahmebolzen zu blockieren.
Bevor Sie beginnen VORSICHT Nach dem Zusammenbau muss der Gaszug so eingestellt werden, dass das Kabelende (J) am Vergaser (L) 1 bis 2 mm Spiel hat. K: Muttern Montage des Schutzschilds Befestigen Sie das Schutzschild (A) am Winkelgetriebe und ziehen Sie die 4 Schrauben (B) fest.
Bevor Sie beginnen Kontrollieren Sie die Messer (A) vor der Montage. Überprüfen Sie die Schärfe. Bei stumpfen Messern erhöht sich das Risiko eines Rückschlags. Kleine Risse können sich zu Brüchen entwickeln, so dass Teile des Messers während des Betriebs weggeschleudert werden. Entsorgen Sie gerissene Messer, egal, wie klein der Riss ist.
Seite 48
Bevor Sie beginnen Der mitgelieferte Schultergurt ist fur Personen mit einer Grose von 150 bis 195 cm und einem einem Bauchumfang von 60 bis 140 cm geeignet. Tragen Sie den Schultergurt, wenn dies in dieser Bedienungsanleitung empfohlen oder vorgeschrieben wird. Justieren Sie sowohl den Gurt als auch die Trageöse (A) am Gerät so, dass das Gerät mit der Schneidvorrichtung einige Zentimeter über dem Boden (B) hängt.
Gelagerter Kraftstoff altert. Mischen Sie nicht mehr Kraftstoff an, als Sie voraussichtlich innerhalb der nächsten dreißig (30) Tage verbrauchen werden. Kraftstoff Empfohlenes Mischverhältnis: 50 : 1 (2 %) Öl nach ISO-L- EGD Standard (ISO/CD 13738), JASO FC, FD und ECHO Premium 50: 1-Öl. Mischen Sie den Kraftstoff nicht direkt im Motor-Kraftstofftank. Kraftstoffversorgung ...
Bedienung des Motors Bedienung des Motors Starten des Motors WARNUNG Befolgen Sie beim Starten des Motors unbedingt die folgenden Sicherheitsregeln: Entfernen Sie sich mindestens 3 m von der Stelle, an der die Betankung erfolgte. Platzieren Sie das Produkt an einem ebenen, gut belüfteten Ort. ...
Bedienung des Motors Stellen Sie den Chokehebel (F) auf die Position „Kaltstart" (E). Betätigen Sie die Kraftstoffpumpe (H) so oft (drücken und loslassen), bis sie Kraftstoff angesaugt hat. Halten Sie das Gerät möglichst nahe am Motor (siehe Abbildung), nachdem Sie die Sicherheit des Ortes überprüft haben, und ziehen Sie mehrmals am Startergriff (I).
Seite 52
Trimmen Trimmen GEFAHR Stellen Sie den Motor sofort ab, wenn die Schneidvorrichtung blockiert wird. Wenn die Blockade beseitigt wird und die Schneidvorrichtung plötzlich anläuft, kann es zu schweren Verletzungen kommen. Verwenden Sie das Produkt niemals ohne den daran befestigten Schutzschild. Von der Schneidvorrichtung abprallende Gegenstände können Unfälle mit schweren Verletzungen verursachen.
Trimmen Verwendung des Schultergurts Hängen Sie den Trimmer immer ordnungsgemäß am Schultergurt auf. Schnallen Sie den Taillengurt fest. Der Gurt muss eng anliegen. Befestigen Sie das Gerät am Schultergurt. Rundgriff-Version Legen Sie den Schultergurt über die linke Schulter, und stellen Sie die Riemen so ein, dass sich die Schnelllöseeinrichtung knapp unterhalb der Hüfte befindet.
Trimmen durchgeschnitten werden. Setzen Sie den Nylonfadenkopf immer am unteren Bereich der Pflanze an, da sich die Pflanze sonst evtl. nur beugt und wieder aufrichtet und sich im Nylonfaden verfangen könnte. Anstatt das Unkraut sofort durchzuschneiden, führen Sie das Ende des Nylonfadens allmählich durch den Unkrauthalm.
Trimmen Achten Sie darauf, dass der Nylonfaden nicht mit beschädigtem Zaundraht in Berührung kommt. Durch den Trimmer abgebrochene Drahtstücke können mit hoher Geschwindigkeit durch die Luft geschleudert werden. Einfaches Trimmen mit Metallmesser WARNUNG Befolgen Sie beim Trimmen die folgenden Anweisungen: ...
Seite 56
Trimmen Unkraut mähen Beim Mähen wird die Schneidvorrichtung in einem horizontalen Bogen geschwungen. Dadurch lassen sich große Bereiche rasch von Gras und Unkraut befreien. Die Sensenmethode eignet sich jedoch nicht zum Mähen von hohem, zähem Unkraut oder holzhaltiger Vegetation. ...
Wartung und Pflege Wartung und Pflege WARNUNG Beachten Sie die folgenden Sicherheitsregeln, wenn Sie das Produkt nach der Verwendung überprüfen bzw. warten: Schalten Sie den Motor ab und überprüfen bzw. warten Sie das Produkt erst dann, wenn der Motor abgekühlt ist. Andernfalls können Sie sich verbrennen.
Wartung und Pflege Reinigen des Luftfilters Schließen Sie den Choke. Lösen Sie die Verriegelung der Luftfilterabdeckung und entfernen Sie die Luftfilterabdeckung (B). Entfernen Sie den Luftfilter (A) (befindet sich unter der Luftfilterabdeckung). Reinigen Sie den Filter durch Abbürsten oder mittels Druckluft.
Wartung und Pflege HINWEIS Wenn der Vergaser mit der Leerlaufanschlagschraube (T) nicht korrekt eingestellt werden kann, müssen Sie einen autorisierten Vertragshändler kontaktieren. Wartung des Kühlsystems WICHTIG Um die richtige Motorbetriebstemperatur aufrechtzuerhalten, muss die Kühlluft ungehindert den Zylinderrippenbereich durchströmen können. Durch diesen Luftstrom wird die Verbrennungswärme vom Motor abgeführt.
Seite 60
Wartung und Pflege Überprüfen der Zündkerze Prüfen Sie den Elektrodenabstand. Der korrekte Abstand beträgt 0,6 bis 0,7 mm. Prüfen Sie die Elektrode auf Verschleiß. Prüfen Sie den Isolierkörper auf Öl- oder andere Ablagerungen. Wenn die Elektroden oder Kontakte verschlissen sind oder die Keramikteile Risse aufweisen, ersetzen Sie sie durch neue Teile.
Wartung und Pflege Überprüfen Sie die Abdeckung und den Auslöseknopf auf Abnutzung. Wenn am unteren Bereich des Auslöseknopfs oder in der Nähe des Nylonfadenaustritts ein Spalt zu sehen ist, ersetzen Sie diese Teile umgehend durch neue. Prüfen Sie den Fadenkopf auf Bruch oder Absplitterung. Ersetzen Sie alle Teile, die gebrochen sind oder Absplitterungen aufweisen, umgehend durch neue.
Seite 62
Wartung und Pflege Ziehen Sie den Faden aus dem Deckel. Lösen Sie (A) den Faden aus den entsprechenden Schlitzen der Fadenspule, und führen Sie ihn (B) durch die beiden Fadendurchführungen. Fügen Sie Deckel und Gehäuse zusammen. Ordnen Sie (C) die Fadenösen des Deckels über den Aussparungen in der Fadenspule an, und drücken Sie (D) die beiden Stifte des Gehäuses ganz in die Aussparungen der Fadenspule, bis sie fest in die Fenster einrasten.
Seite 63
Wartung und Pflege Fehlerbehebung WICHTIG Verwenden Sie nur Original-Ersatzteile und -Verbrauchsprodukte, die für das Gerät zugelassen sind. Die Verwendung von Teilen anderer Hersteller oder nicht zugelassener Produkte kann zu Fehlfunktionen führen. Problem Diagnose Ursache Lösung Der Motor lässt Im Kraftstofftank ist kein Kraftstoff Kraftstoffversorgung sich nicht starten.
Wartung und Pflege Hersteller: YAMABIKO CORPORATION 7-2 SUEHIROCHO 1-CHOME, OHME, TOKIO 198-8760, JAPAN Autorisierter Repräsentant in Europa: Atlantic Bridge Limited Atlantic House, PO Box 4800, Earley, Reading RG5 4GB, Vereingtes Königreich LAGERUNG Langfristige Lagerung (30 Tage und länger) WARNUNG Lagern Sie das Gerät nicht in verschlossenen Räumen, aus denen Kraftstoffverdunstungen nicht entweichen können, und nicht in der Nähe von Flammen oder Funken.
Kraftstoff mit Methylalkohol oder mehr als Öl 10 % Ethylalkohol. Motoröl für luftgekühlte Zweitaktmotoren. ISO-L- EGD-Norm (ISO/CD 13738), JASO FC, FD und Verhältnis ECHO Premium 50: 1-Öl. 50 : 1 (2%) Kraftstoffverbrauch bei maximaler Motorleistung 0,60 L/h Spezifischer Kraftstoffverbrauch bei maximaler Motorleistung 499 g/(kW•h)
Gerät: RASENTRIMMER/MOTORSENSE Marke: ECHO Typ: SRM-265 Folgendem entspricht: * Anforderungen der Richtlinie 2006/42/EG (Verwendung der harmonisierten Norm EN ISO 11806-1: 2011) * Anforderungen der Richtlinie 2004/108/EG bis 19. April 2016 (Verwendung der harmonisierten Norm EN ISO 14982: 2009) und 2014/30/EU ab dem 20.
Seite 67
1Notizen und hintere Umschlagseite NOTIZEN X750-026690 X750202-5109 2013...
Seite 69
1Coperchio ITALIANO (Istruzioni originali) MANUALE PER L'OPERATORE DECESPUGLIATORE/BORDATORE SRM-265 AVVERTENZA LEGGERE E SEGUIRE ATTENTAMENTE LE ISTRUZIONI PER LAVORARE IN CONDIZIONI DI MASSIMA SICUREZZA. LA MANCATA OSSERVANZA DELLE ISTRUZIONI POTREBBE PROVOCARE LESIONI GRAVI.
Seite 70
Contenuto Per un uso sicuro del prodotto.................... 3 Descrizione ......................... 8 Prima di iniziare ........................9 Contenuto della confezione ................... 9 Montaggio ........................10 Versione con impugnatura ad anello ................10 Versione con impugnatura a U ..................11 Regolazione del punto di equilibrio................13 Preparazione del carburante ..................
Per un uso sicuro del prodotto Per un uso sicuro del prodotto Informazioni importanti AVVERTENZA Si raccomanda di leggere il manuale per l'operatore prima di utilizzare questo prodotto. Informazioni sul manuale per l'operatore Questo manuale contiene informazioni necessarie per l'assemblaggio, il funzionamento e la manutenzione del pro- dotto.
Seite 72
Per un uso sicuro del prodotto AVVERTENZA Vibrazioni e freddo Si ritiene che una condizione definita fenomeno di Raynaud, che colpisce le dita di alcune persone, sia causata dall'esposizione alle vibrazioni e al freddo. L'esposizione al freddo e alle vibrazioni può causare formicolio e brucio- re, seguiti da pallore e intorpidimento delle dita.
Seite 73
Per un uso sicuro del prodotto AVVERTENZA Area di lavoro e funzionamento Non utilizzare il prodotto: in condizioni di cattivo tempo. in pendii ripidi o in luoghi con punti di appoggio non sicuri e quindi scivolosi. di notte o in luoghi bui con scarsa visibilità. ...
Seite 74
Per un uso sicuro del prodotto Forma del simbolo Descrizione / applicazione del Forma del simbolo Descrizione / applicazione del simbolo simbolo Indossare protezioni per oc- Tenere gli astanti a una di- chi, orecchie e testa stanza di 15 m Indossare protezioni per i pie- Miscela di benzina e olio di e guanti...
Seite 75
Per un uso sicuro del prodotto Decalcomania/e La decalcomania riportata sotto è stata applicata sui prodotti descritti in questo manuale. Prima di utilizzare il prodotto accertarsi di aver compreso quanto riportato sulla decalcomania. Se la decalcomania diventa illeggibile a causa dell'usura, si strappa o si stacca e si perde, acquistarne una di ricambio presso il rivenditore e fissarla nel punto illustrato nella figura in basso.
Descrizione Descrizione Trasmissione angolare Due ingranaggi per cambiare 10. Interruttore di accensione Interruttore "scorrevole" l'angolo dell'asse di rotazione. montato sulla sede della leva del gas. Spostare in avanti Accessorio di taglio Testina a filo di nylon per falciare per AVVIARE e indietro per ARRESTARE. erba e erbacce.
Prima di iniziare Prima di iniziare Contenuto della confezione Le seguenti parti sono state imballate separatamente nella scatola di imballaggio. Dopo aver aperto la confezione, controllare che siano presenti tutte le parti. In caso di parti mancanti o rotte, contattare il rivenditore. 1.
Prima di iniziare Montaggio AVVERTENZA Leggere attentamente il manuale per l'operatore per essere certi di montare correttamente il prodotto. L'uso di un prodotto non montato correttamente potrebbe causare incidenti o lesioni gravi. Versione con impugnatura ad anello Montaggio dell'impugnatura ad anello Assemblare l'impugnatura ad anello (A) e il supporto (C) sul grup- po albero motore.
Prima di iniziare Montaggio della testina a filo di nylon Inserire l'utensile di bloccaggio (A) in un foro situato sul lato destro della trasmissione angolare, forzando al contempo la molla porta disco sul lato sinistro. Inserire l'utensile di bloccaggio nell'asola per il bloccaggio del fermo della lama (B), per fissare l'alberino di uscita.
Prima di iniziare ATTENZIONE Dopo l’assemblaggio, regolare il gioco dell'estremità del filo (J) sul lato del carburatore (L) a 1 -2 mm. K: Dadi Montaggio della protezione Montare la protezione (A) alla porzione di supporto della tra- smissione angolare e serrare i 4 bulloni (B). Procedura di sostituzione della protezione ...
Prima di iniziare Ispezionare le lame (A) prima del montaggio. Verificare che siano affilate. Un'affilatura scadente aumenta il rischio di re- azioni da contraccolpo della lama. Le piccole incrinature possono trasformarsi in rotture, che fanno saltare via una parte della lama durante il funzionamento. Scartare i dischi incrinati a prescindere dalle dimensioni dell'incrinatura.
Seite 82
Prima di iniziare La cinghia a spalla in dotazione e adatta per persone con una corporatura da adulto standard, con un'altezza di 150 - 195 cm e un giro vita di 60 - 140 cm. Utilizzare una cinghia a spalla se in dotazione o se consigliata in questo manuale.
Carburante Percentuale della miscela consigliata 50 : 1 (2 %) per olio standard ISO-L-EGD (ISO/CD 13738), grado JASO FC, FD ed ECHO Premium 50: 1. Non miscelare direttamente nel serbatoio carburante del mo- tore. Rifornimento carburante Non riempire mai il serbatoio del carburante (A) fino all'imboc- catura.
Funzionamento del motore Funzionamento del motore Avviamento del motore WARNING Prestare particolare attenzione alle seguenti precauzioni quando si avvia il motore: Spostarsi di almeno 3 m dal luogo in cui si è ricaricato il serbatoio di carburante. Collocare il prodotto su una superficie piana e ben ventilata. ...
Funzionamento del motore Portare la leva della valvola dell'aria (F) in posizione "Avvia- mento a freddo" (E). In alternativa, premere e rilasciare il bulbo di spurgo (H) fin- ché il carburante non viene risucchiato al suo interno. Dopo aver verificato che l'area circostante è sicura, mante- nere fermo il bordatore/decespugliatore con una mano vici- na al motore, come mostrato in figura, e con l'altra mano tirare ripetutamente la funicella (I).
Operazioni di taglio Operazioni di taglio PERICOLO Spegnere sempre il motore quando l'accessorio di taglio si inceppa. Se durante la rimozione dell'inceppamento l'accessorio di taglio si avvia improvvisamente può causare gravi lesioni. Non utilizzare il prodotto senza protezione. Qualsiasi oggetto che rimbalza dall'accessorio di taglio può...
Operazioni di taglio Uso della cinghia a spalla Montare sempre il decespugliatore correttamente utilizzando la cinghia a spalla. Agganciare la cintura. Essa deve essere aderente. Agganciare il prodotto alla cinghia a spalla. Versione con impugnatura ad anello Collocare la cinghia sulla spalla sinistra e regolare le fa- scette in modo che la spina a sgancio rapido rimanga im- mediatamente sotto la vita.
Seite 88
Operazioni di taglio Detriti Lato lama alzato Angolo con il suolo Falciatura Si tratta del taglio di aree erbose piuttosto estese, eseguito de- scrivendo un arco con il decespugliatore. con un movimento lento e uniforme, senza cercare di appiattire o tranciare l'erba. Inclinare leggermente la testina a filo di nylon per indirizzare i detriti lontano dal corpo nella corsa di falciatura.
Operazioni di taglio Funzionamento base del taglio con disco metallico AVVERTENZA Durante il taglio, attenersi alle seguenti istruzioni. Verificare che la lama bordatore sia serrata saldamente in posizione. Sostituire la protezione in caso di danni o incrinature. ...
Manutenzione e cura Manutenzione e cura AVVERTENZA Osservare le seguenti precauzioni durante il controllo e la manutenzione del prodotto dopo l'uso: Spegnere il motore ed eseguire il controllo o la manutenzione del prodotto solo dopo che il motore si è raffreddato. Interventi a motore caldo potrebbero causare ustioni.
Manutenzione e cura Pulizia del filtro dell'aria Chiudere la valvola dell'aria. Allentare il pomello del coper- chio del filtro dell'aria e rimuovere il coperchio del filtro (B). Rimuovere il filtro dell'aria (A) (situato all'interno del coper- chio del filtro dell'aria). Rimuovere lo sporco dal filtro con una spazzola o pulire con aria compressa.
Seite 92
Manutenzione e cura Manutenzione dell'impianto di raffreddamento IMPORTANTE Per mantenere la giusta temperatura di esercizio del motore, l'aria di raffreddamento deve passare liberamente at- traverso le alette del cilindro. Questo flusso d'aria allontana dal motore il calore generato dalla combustione. Il sur- riscaldamento e il grippaggio del motore possono verificarsi quando: ...
Manutenzione e cura Trasmissione angolare Rimuovere il tappo (A) e la vite di scarico (B) dalla trasmis- sione angolare (C). Aggiungere del grasso nella trasmissione fino a quando quello esausto non inizia ed essere espulso. Se necessario, utilizzare una pompa a bassa pressione. NOTA ...
Seite 94
Manutenzione e cura Sostituzione del filo di nylon PERICOLO Spegnere il motore del bordatore/decespugliatore e accertarsi che la testina a filo di nylon abbia smesso di ruotare prima di iniziare la procedura di sostituzione. La mancata osservanza di queste precauzioni potrebbe causare un incidente o lesioni gravi. AVVERTENZA ...
Seite 95
Manutenzione e cura Assemblare coperchio e alloggiamento. (C) Allineare gli "oc- chielli" del coperchio con i "recessi" dell'alloggiamento e (D) spingere i cricchetti dell'alloggiamento nelle rispettive aper- ture del coperchio fino a che non si incastrano saldamente nelle aperture. PERICOLO ...
Manutenzione e cura Problemi tecnici IMPORTANTE Per i pezzi di ricambio e gli articoli di consumo, utilizzare solo parti originali, prodotti e componenti raccomandati. L'utilizzo di ricambi di altri produttori o componenti non raccomandati potrebbe provocare guasti. Problema Diagnosi Causa Soluzione Il motore non si av-...
Manutenzione e cura Produttore: YAMABIKO CORPORATION 7-2 SUEHIROCHO 1-CHOME, OHME, TOKYO 198-8760, GIAPPONE Rappresentante autorizzato in Europa: Atlantic Bridge Limited Atlantic House, PO Box 4800, Earley, Reading RG5 4GB, Regno Unito Rimessaggio Rimessaggio per un lungo periodo (oltre 30 giorni) AVVERTENZA ...
10%. Olio per motore a due tempi raffreddato ad aria. Olio certificato ISO-L-EGD (ISO/CD 13738), JASO FC, Rapporto FD ed ECHO Premium 50 : 1. 50 : 1 (2%) Consumo carburante alla massima potenza del motore 0,60 L/h Consumo specifico di carburante alla massima potenza del motore 499 g/(kW•h)
DECESPUGLIATORE/BORDATORE Marchio: ECHO Tipo: SRM-265 è conforme a: * i requisiti richiesti dalla Direttiva 2006/42/CE (uso di norma armonizzata EN ISO 11806-1: 2011) * i requisiti richiesti dalla Direttiva 2004/108/CE fino al 19 aprile 2016 (uso della norma armonizzata EN ISO 14982:...
Seite 101
1Tapa ESPAÑOL (Instrucciones originales) MANUAL DE INSTRUCCIONES CORTABORDES/DESBROZADORA SRM-265 ADVERTENCIA LEA ATENTAMENTE LAS INSTRUCCIONES Y SIGA LAS INDICA- CIONES PARA UN FUNCIONAMIENTO SEGURO. DE NO HACERLO, PODRÍA SUFRIR LESIONES GRAVES.
Seite 102
Contenido Para una utilización segura del producto................3 Descripción ......................... 8 Antes de comenzar......................9 Lista de piezas....................... 9 Montaje ........................10 Versión con manillar único................... 10 Versión con manillar doble ..................11 Ajuste del equilibro ...................... 13 Preparación del combustible ..................15 Funcionamiento del motor ....................
Para una utilización segura del producto Para una utilización segura del producto Información importante ADVERTENCIA Asegúrese de leer el manual de instrucciones antes de utilizar el producto. Acerca del manual de instrucciones Este manual proporciona la información necesaria para el montaje, funcionamiento y mantenimiento de esta máqui- na.
Seite 104
Para una utilización segura del producto ADVERTENCIA Las vibraciones y el frío Se cree que puede contraerse una enfermedad llamada fenómeno de Raynaud, que afecta a los dedos de ciertos individuos, si está expuesto a vibraciones y frío. La exposición a las vibraciones y al frío puede causar el cosquilleo y quemazón de los dedos, seguidos de pérdida de color y sensación de dedos dormidos.
Para una utilización segura del producto ADVERTENCIA Condiciones de uso y de funcionamiento No utilice el producto: en condiciones meteorológicas adversas. sobre pendientes inclinadas o en lugares en los que no exista un apoyo firme para los pies y el terreno sea res- baladizo.
Seite 106
Para una utilización segura del producto Forma y silueta del símbolo Descripción / aplicación del Forma y silueta del símbolo Descripción / aplicación del símbolo símbolo Utilice siempre protección Mantener a los transeúntes a para los ojos, oídos y cabeza. una distancia de 15 m Utilice calzado y guantes de Mezcla de gasolina y aceite...
Seite 107
Para una utilización segura del producto Adhesivo(s) de seguridad Los productos descritos en este manual incorporan el adhesivo de seguridad mostrado a continuación. Asegúrese de compren- der el significado del adhesivo antes de utilizar el producto. Si el adhesivo se ha deteriorado debido al desgaste, está dañado o se ha despegado y perdido, adquiera un adhesivo de re- puesto en su distribuidor y colóquelo en la ubicación mostrada en las ilustraciones que aparecen a continuación.
Descripción Descripción Transmisión en ángulo Con dos engranajes para 10. Interruptor de encendido "Interruptor deslizable" cambiar el ángulo del eje giratorio. montado en la parte superior de la caja del gatillo del Accesorio de corte Cabezal con hilo de nylon para acelerador.
Antes de comenzar Antes de comenzar Lista de piezas En la caja de embalaje están empaquetadas de forma separada las siguientes piezas. Cuando haya desempaquetado la caja, compruebe que contenga las siguientes piezas. Póngase en contacto con su distribuidor si falta alguna o está rota. 1.
Antes de comenzar Montaje ADVERTENCIA Lea atentamente el manual de instrucciones para asegurarse de que monta correctamente el producto. La utilización de un producto que se haya montado incorrectamente puede ocasionar un accidente o una lesión grave. Versión con manillar único Montaje del manillar único Monte el manillar único (A) y el soporte (C) en el conjunto del ár- bol de transmisión.
Antes de comenzar Instalación del cabezal de corte de hilo de nylon Introduzca la herramienta de bloqueo (A) en el orificio ubica- do en el lado derecho de la transmisión en ángulo forzando al mismo tiempo el muelle de retén hacia el lado izquierdo. Introduzca aún más la herramienta de bloqueo en la ranura de fijación (B) del retén de la cuchilla para fijar el eje de sa- lida.
Seite 112
Antes de comenzar PRECAUCIÓN Después del montaje, ajuste la holgura del extremo del cable (J) en el lado del carburador (L) para que sea de 1 a 2 mm. K: Tuercas Instalación del escudo Instale el escudo (A) en la parte de montaje de la transmi- sión en ángulo y apriete los 4 pernos (B).
Antes de comenzar Inspeccione las cuchillas (A) antes de su instalación. Com- pruebe también que estén afiladas. Las cuchillas romas au- mentan el riesgo de contragolpes de la cuchilla. Las grietas pequeñas pueden convertirse en fracturas y, durante el uso, podrían salir volando trozos de cuchilla con el consiguiente peligro.
Seite 114
Antes de comenzar Deslice el punto de suspensión arriba y abajo del tubo hasta encontrar el equilibrio correcto. Gire la abrazadera para nive- lar el accesorio de corte y la protección. Bloquéelo en posi- ción. Si el punto de suspensión es de tipo de giro libre, puede que la unidad tienda a desplazarse lateralmente, pero aún así, deberá...
Relación de mezcla recomendada: 50 : 1 (2 %) para ISO-L- EGD Standard (ISO/CD 13738), para aceite JASO FC, FD y ECHO Premium 50 : 1. No haga la mezcla directamente en el depósito de combusti- ble del motor.
Funcionamiento del motor Funcionamiento del motor Arranque del motor ADVERTENCIA Tenga especial cuidado de seguir las siguientes precauciones cuando arranque el motor: Muévase por lo menos 3m del lugar en donde ha repostado. Coloque el producto en un lugar plano y bien ventilado. ...
Funcionamiento del motor Mueva la palanca del estrangulador (F) a la posición de "Arranque en frío" (E). Pulse y libere alternativamente el cebador (H) hasta que succione combustible. Comprobando que el área que tiene alrededor sea segura, mantenga la posición más cercana al motor firmemente tal como se muestra en la ilustración y tire varias veces del puño del arranque (I).
Funcionamiento del recorte de bordes Funcionamiento del recorte de bordes PELIGRO Pare siempre el motor cuando se produzca una obstrucción del accesorio de corte. En caso contrario, al eliminar la obstrucción, el accesorio de corte podría arrancar de repente y causarle heridas. ...
Funcionamiento del recorte de bordes Uso del arnés Coloque siempre correctamente el cortabordes utilizando el arnés. Abróchese el cinturón. El cinturón debe quedar ceñido. Coloque el dispositivo en el arnés. Versión con manillar único Coloque el arnés sobre su hombro izquierdo y ajuste las tiras de modo que el pasador de liberación rápida quede justo debajo de su cintura.
Seite 120
Funcionamiento del recorte de bordes despacio y paulatinamente el tallo. Ángulo con la pared Desechos Lado de cuchilla elevado Ángulo con el suelo Siega Consiste en el corte o siega de grandes áreas con hierbas, ba- rriendo con el cortador o haciéndolo oscilar en un arco llano. Utilice un movimiento suave y fácil.
Funcionamiento del recorte de bordes Evite el contacto del hilo de nylon con vallas de alambre de es- pino roto. Los trozos de alambre rotos por el cortador podrían salir proyectados hacia Ud. a alta velocidad. Funcionamiento básico del recorte de bordes con la cuchilla metálica ADVERTENCIA ...
Seite 122
Funcionamiento del recorte de bordes La siega de malas hierbas Consiste en el corte realizado haciendo oscilar el accesorio de corte en un arco llano. Puede limpiar rápidamente áreas de malas hierbas y césped. Este tipo de corte no debe utilizarse para cortar malas hierbas grandes y duras o ramas de made- ...
Mantenimiento y cuidados Mantenimiento y cuidados ADVERTENCIA Cuando compruebe o realice el mantenimiento del producto después del uso, tenga en cuenta las siguientes precau- ciones: Apague el motor y no intente realizar ninguna comprobación ni mantenimiento del producto hasta que el motor se haya enfriado.
Mantenimiento y cuidados Limpieza del filtro de aire Cierre el estrangulador. Afloje el botón de la tapa del filtrador de aire y retire la tapa del filtrador de aire (B). Saque el filtro de aire (A) (el filtro de aire está ubicado dentro de la tapa del filtrador de aire).
Seite 125
Mantenimiento y cuidados Mantenimiento del sistema de enfriamiento IMPORTANTE Para mantener la temperatura adecuada de funcionamiento del motor, el aire de enfriamiento debe pasar libremente a través del área de aletas del cilindro. Este flujo de aire disipa el calor de combustión del motor. Puede tener lugar un sobrecalentamiento y agarrotamiento del motor cuando: ...
Seite 126
Mantenimiento y cuidados do chispas) debe ser realizada por su distribuidor. Transmisión en ángulo Saque el tapón (A) y el tornillo de vaciado (B) de la transmi- sión en ángulo (C). Añada grasa en la transmisión hasta que salga la grasa an- terior.
Seite 127
Mantenimiento y cuidados Substitución del hilo de corte PELIGRO Para sin falta el motor. Asegúrese de que el cabezal de corte se haya parado antes de empezar los procedimientos para la substitución del hilo. De hacerlo, podría provocar un accidente o una lesión grave. ADVERTENCIA ...
Seite 128
Mantenimiento y cuidados Junte y encaje la tapa y la caja. (C) Alinee los "ojales" de la tapa con los "huecos" de la caja y (D) presione los trinquetes de la caja en las ventanas respectivas de la tapa hasta que los trinquetes queden firmemente encajados en las venta- nas.
Mantenimiento y cuidados Tabla de localización de averías IMPORTANTE Para piezas de repuesto y consumibles, utilice sólo piezas auténticas y productos y componentes indicados. La utilización de piezas de otros fabricantes o de componentes no indicados pueden derivar en un fallo de funcionamiento. Problema Diagnóstico Causa...
Mantenimiento y cuidados Fabricante: YAMABIKO CORPORATION 7-2 SUEHIROCHO 1-CHOME, OHME, TOKIO 198-8760, JAPÓN Representante autorizado en Europa: Atlantic Bridge Limited Atlantic House, PO Box 4800, Earley, Reading RG5 4GB, Reino Unido Almacenamiento Almacenamiento durante un largo periodo (30 días o más) ADVERTENCIA ...
10% de alcohol etílico. Aceite para motor de 2 tiempos refrigerado por aire. Aceite ISO-L-EGD Standard (ISO/CD 13738), JASO Proporción FC, FD y ECHO Premium 50 : 1. 50 : 1 (2%) Consumo de combustible a máxima potencia del motor 0,60 L/h Consumo de combustible específico a máxima potencia del motor...
CORTABORDES/DESBROZADORA Marca: ECHO Tipo: SRM-265 cumple con: * los requisitos de la directiva 2006/42/CE (aplicación de la norma armonizada EN ISO 11806-1: 2011) * los requisitos de la directiva 2004/108/CE hasta el 19 de abril de 2016 (aplicación de la norma armonizada EN ISO 14982: 2009) y 2014/30/UE desde el 20 de abril de 2016 (aplicación de la norma armonizada EN ISO 14982: 2009)
