7. How-to-start Guide
Put 4 pcs mignon AA batteries* in the
transmitter & take care of the polarity!
*not included
2. Move the ESC power switch to the "ON" position,
the LED will be on.
4. Plug the ESC cable to the battery cable to switch ESC on
Throttle Reverse Switcher
Steering Reverse
Switcher
6. If the direction of travel on the rudder is
opposite, slide the steering reverse switch to
the other position.
WARNING: Do NOT slide the throttle reverse
switch unless you completely understand
this function and it is necessary to switch.
Otherwise serious damage may occur.
www.modster.at
Slide the switch
UP for ON and
DOWN for OFF
3. To slowly drive forward, pull the throttle trigger slightly. Adjust the speed by pul-
ling the trigger. Push the trigger to brake/reverse. Release the trigger to keep your
vehicle still.
5. Use the steering trim dial to adjust the neutral position of the servo.
Push the dial counter-clockwise to trim left, clockwise to trim right,
until your vehicle tracks straight when steering at neutral position.
Switch Up/Down for
Switch Up/Down for
Larger/Smaller Servo Angle
Larger/Smaller Servo Angle
Dual rate
7. Adjust the servo angle by turning the switch
up or down.
Turn the switch to upper position for larger ser-
vo angle.
Turn the switch to lower position for smaller ser-
vo angle.
MODSTER ROOKIE
Solid LED light:
Battery is in good
condition (Above
4.3V)
Flashing LED:
Battery is at low
voltage
Replace batteries

Steering Trim

Trimmer
8. After you finished, turn off ESC
power, then unplug battery and put
in a dry safe place to cool down befo-
re you use it again.
