Device activity LEDs
Connector
to PC1
DIP switch settings (located underneath switch):
SW1: Reset Switch
To reset, OFF¡ON¡OFF
SW2 and SW3: TimeOut Setting
TimeOut is the amount of time the switch remains locked on a PC port after
data transfer. Use a longer TimeOut when connecting to scanners, mass
storage devices and for large print jobs.
SW2
ON
ON
OFF
OFF
4/28/00
Product Detail
Connector to Device A
Connector to PC2
PC activity LEDs
ON is UP. SW4 is not used.
SW3 TimeOut
ON 5 seconds
OFF 10 seconds
ON 20 seconds
OFF 40 seconds
3
2:12 PM Page 3
Connector to Device B
Connector to PC3
Computer button
Printer button
ON
1 2 3 4
Recommended
En
Connector
to PC4
DC power jack
(side)
DIP
