INSTALLATION ADVICE
•
Check the label on the pack to ensure you have the model shed you ordered.
Please retain info on model No. at the end of the carton.
THIS MANUAL WILL BE USED FOR THE FOLLOWING GARDEN SHED MODEL NUMBERS.
MODEL No.
ZINCALUME
COLOURBOND
UTZ1015
UTASC1015
10´ x 15´
UTZ10152
UTASC10152
10´ x 15´
UTZ1019
UTASC1019
10´ x 19´
UTZ10192
UTASC10192
10´ x 19´
Note: All dimensions are approximate. All dimensions in mm. 1 Foot = 30.48cm. Dynabolts are NOT supplied.
FG = Federation Green, IH = White and W = Wheat assembly is the same as Zincalume.
PLEASE REFER TO SEPERATE PARTS LIST FOR FG, W AND IH.
BEFORE YOU START, IT IS IMPORTANT THAT YOU READ THE FOLLOWING INSTRUCTIONS.
•
When selecting a site, choose an area that is firm and level yet allows drainage away from the site.
•
Although this shed when installed according to instructions, is designed to withstand greater wind loads than other
conventional sheds, do not assemble it in areas subject to high winds or erect on a windy day. Any building left
partially constructed may be seriously damaged if left in this state. It is your responsibility to safely and securely
anchor the shed, having regard to the windiest conditions in the area. The shed could possibly blow away causing
damage and possible injury if not properly attached to the ground foundation.
•
Do not backfill against the walls or base of the shed as this will cause corrosion and void the warranty.
The prevention of condensation inside the shed will assist in keeping the contents dry as well as minimising any
•
possible corrosion of the shed itself, the following hints may prove useful.
There is always dampness in soil, and this may rise into the shed if there is no barrier. A heavy duty polythene sheet
may be placed under the concrete slab to prevent evaporation into the shed.
Seal the space between the bottom frame and the concrete slab with a mastic (except at the front corners). The front
corners are not sealed to enable drainage out of the ends of the front base rail.
If condensation still presents a problem, panels of polystyrene (5cm thick) may be glued to the interior of the roof
between the supports. Use a glue that is resistant to moisture and temperature.
•
You will need a few tools, as indicated in the section HOW TO READ THIS MANUAL. Most holes for screws are
predrilled. A power screw driver or cordless drill equipped with a magnetic Philips tip will hasten assembly. Take care
not to over-tighten self-tapping screws.
•
Sort, separate and identify all parts and hardware before construction. Check against the illustrations shown. Framing
components are labelled.
•
Since this manual is used to instruct assembly of varying sizes of shed, Labelling of Parts in the diagrams has been
simplified as follows:
All the frame work components have the same system of part numbers but indicate different lengths, these part
numbers are stamped into the component.
e.g. Roof Beams
Therefore, in the diagrams the Roof Beam is labelled P.
IMPORTANT SAFETY FEATURES
•
Observe all special notes which indicate differences between various types of sheds.
•
You should not try to assemble the shed on your own. Get a second person to help you.
•
The statutory requirements of the local building authorities must be observed.
•
Safety gloves should be worn during assembly.
•
Safety glasses should be worn during assembly.
•
Preferably in a long sleeve shirt.
•
Beware of sharp edges.
•
WINTER SERVICE: The roof is designed for a snow load of 75 kg/m2. In order to avoid overload of the roof, timely
removal of snow from the roof area is recommended.
If the garden shed is unattended for lengthy periods during the winter months, the roofs should be propped up as a
safety precaution.
THE MANUFACTURERS CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO SHEDS THAT ARE
NOT ERECTED PER INSTRUCTIONS OR FOR DAMAGE DUE TO WEATHER CONDITIONS OR ACTS OF GOD. PARTS
MAY CONTAIN SHARP EDGES & CORNERS. CARE MUST BE TAKEN WHEN HANDLING VARIOUS PIECES TO AVOID A
MISHAP, FOR SAFETY SAKE, PLEASE USE A PAIR OF WORK GLOVES & EYE PROTECTION WHEN ASSEMBLING OR
PERFORMING ANY MAINTENANCE ON THE BUILDING.
APPROX. ROOF
OVERALL
DIMENSIONS
A x B
feet
mm
feet
3070 x 4650
79.92"
3070 x 4650
88.58"
3070 x 5880
79.92"
3070 x 5880
88.58"
9 foot length = P9
7 foot length = P7
5 foot length = P5
APPROX. BASE
HEIGHT
DIMENSIONS
C
D x E
mm
feet
2030
9´8´ x 14´8´´
2960 x 4540
2250
9´8´ x 14´8´´
2960 x 4540
2030
9´8´ x 18´8´´
2960 x 5780
2250
9´8´ x 18´8´´
2960 x 5780
• 4 •
APPROX. FOUNDATION
DIMENSIONS
X x Y
mm
feet
mm
10´ x 15'
3070 x 4700
10´ x 15'
3070 x 4700
10´ x 19'
3070 x 5900
10´ x 19'
3070 x 5900
DYNABOLT
6mm x 40mm
Qty.
27
27
29
29
