Camargue HÄLLEVIK Handbuch Seite 12

Important before installation
1. Only a certified electrician / plumber can install the whirlpool and only
a certified plumber can install the tub.
2. Bathtub is to be installed with at least 50cm distance from the
nearest object so that possible service can be done. If the bathtub is
not installed within the recommended range can the manufacturer
refuse to do the reparations within warranty period. Do not place
immovable object in that space.
3. If the bathtub is sealed with silicon remove the silicon before possible
reparation. The service man does not restore any silicon sealings.
4. Prevent the tub from damage during the installation. Be careful so
that the tub does not get scratched by sharp tools like a screwdriver
and other tools. Be careful when you move the tub so that the feet
does not damage the floor.
5. Use the adjustable feet to install the tub horizontally.
Electrical requirements
6. Electrical installations shall be made according to relevant applicable
rules. All electrical installations must be water resistant and all
electrical installation should include a waterproof switch.
7. Your electrical installation should be powerful enough to run all the
connected electrical components at the same time.
8. Additionally, install the earth wire and make sure that the earth wire
works properly. Do not let the socket and contacts come in contact
with water.
After installation
9. The distance between bathtubs edge and the wall is to be 0,5 cm.
Use bathroom silicone to fill the gap and to seal the bathtub.
Using the function knob
1. Press the knob. The light on the wheel shines purple.
2. You can select various functions by turning the knob. Each function
has its own color of light. After selecting the desired function, you can
start and stop it by pressing the button.
RED
Underwater lights
GREEN
Air massage strength 1
BLUE
Air massage strength 2
WHITE
Air massage strength 3
Care taking
1. Do not use sharp tools or cleaners containing solvents or abrasives to
clean the tub.
2. Scratches on the surface of the tub can be wet sanded. Use only
2000 sandpaper. Then lubricate the scratch with toothpaste and
polish with a soft cloth. Use car wax to polish bubble bath.
3. To get rid of limestone use a cloth soaked in warm lemon juice or
vinegar.
4. Massage jets and drain filter can be removed and cleaned if they are
blocked with hair etc.
5. Avoid scratching the tub with sharp objects. Lit cigarettes or other
objects with temperature above 70 ° C must not come in contact with
the tub surface.
6. D o not use harsh cleaners or scouring pads on the chrome parts of the
tub. You can scratch and remove the chrome surface.
Safety instructions
1. Children should not bath alone or unattended in a bubble bath.
2. People with heart problems, high or low blood pressure and pregnant
women should consult a physician before using the whirlpool.
3. The water to fill the tub should not be too hot. Check the water
temperature before stepping into the tub so you do not burn your
feet and legs.
4. When the massage function is on the people with long hair should not
lower their head under the water level at the suction filter.
Troubleshooting
If the bubble bath does not work use the table for troubleshooting and
actions. Contact 7092@camargue.se if you are unable to find the cause
of the error or if the fault is impossible to fix.
1. The blower does not work.
- The fuses have blown. Check the fuses on the tub and check the
fuses in your electrical installation.
- Check power supply - the voltage needs to be 220/230 volts and
installation has to take enough Amp
- Contact 7092@camargue.se
2. Water is lekaing under the bathtub drain.
- Drain plug and siphon are not connected properly. Teflon tape has
not been used.
- Turn of the siphon, the plastic piece where the drain hose is
mounted. Use plenty of teflon tape or oil fat / horsehair in siphon
welding and mount the siphon back into the drain plug.
3. The tub is scratched and lost the glossy surface.
- Aggressive cleaner, scouring powder or sponge has damaged the
surface.
- Use car wax to polish the surface again.
4. The chrome parts look rusty out.
- Limestone has accumulated and rust has appeared.
- Aggressive cleaner, scouring powder or sponge has damaged the
surface.
- Use descaling agent, vinegar or citric acid regularly.
5. Bubble bath is unstable.
- One of the adjustable feet is shorter than the other.
- Adjust the feet and use a water level to make the tub stable.
6. Further questions
- Contact Customer Service at 7092@camargue.se. We will be happy
to help!
