3. ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug from
the mains.
Fitting the polishing bonnet (Fig. B)
Make sure to use the right polishing bonnet
for the corresponding material. To determine
which bonnet you need, we recommend to
read and understand all information supplied
with your polish or wax.
Use undamaged and clean polishing
accessories only.
1. Hold the machine upside down.
2. Place the polishing bonnet (4, 5) onto the pad
(3) as shown in Fig. B. Make sure the bonnet is
fitted securely.
Removing the polishing bonnet
1. Hold the machine upside down.
2. Remove the polishing bonnet (4, 5) by pulling
the bonnet edges over and off the pad.
4. OPERATION
Always start and stop the polisher on or
against the surface.
Switching on (Fig. A)
1. Check that the switch (1) is in the "OFF/0"
position before connecting the machine to the
power supply.
2. Firmly hold the machine with both hands, using
both of the handles (2).
3. To switch on the machine, slide the on/off
switch (1) to the " ON/1" position.
Switching off (Fig. A)
1. To switch off the machine, slide the on/off
switch (1) to the " OFF/0" position.
2. Wait until the pad stops rotating before lifting
the polisher from the surface.
3. Unplug polisher.
Hints for optimum use
• For best results, the surface should be clean
and dry.
• Do not apply polish directly to car. Apply a small
WWW.VONROC.COM
amount of polish on the polishing bonnet.
• Do not apply too much pressure on the machine.
Let the machine do the work.
• Begin by polishing larger flat surfaces, such as
the roof and hood. Use a sweeping motion in a
criss-cross pattern.
• Once flat surfaces have been covered, polish
curved surfaces.
• For hard to reach areas, such as the underside of
bumpers or side mirrors, apply polish by hand.
• Do not use any type of abrasive cleanser as it
may damage or scratch the surface.
5. MAINTENANCE
Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that the
ventilation openings are free of dust and dirt. Re-
move very persistent dirt using a soft cloth moiste-
ned with soapsuds. Do not use any solvents such
as gasoline, alcohol, ammonia, etc. Chemicals such
as these will damage the synthetic components.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/
EC for Waste Electrical and Electronic Equipment
and its implementation into national right, power
tools that are no longer usable must be collected
separately and disposed of in an environmentally
friendly way.
WARRANTY
VONROC products are developed to the highest
quality standards and are guaranteed free of defects
in both materials and workmanship for the period
lawfully stipulated starting from the date of original
purchase. Should the product develop any failure
during this period due to defective material and/or
workmanship then contact VONROC directly.
EN
7
