3
Clearance and safety surfaces
Platzbedarf und Fallschutzunterlage • Pladshensyn og faldunderlag
Safety surface in accordance with EN 1176
Fallschutzunterlage gemäß EN 1176
Faldunderlag i overensstemmelse med EN 1176
Height • Höhe • Højde
B
A
Total
Scale • Maßstab • Målstok 1:100
0
1
0
1
A
2
3
4
5
175 x 706 cm
(12,4 m
)
2
6
7
m
175 cm
223 cm
3
2
1
0
* Height without decoration – see our website for height including decoration.
Höhe ohne Dekoration – siehe unsere Website für Höhe einschließlich Dekoration.
Højde uden dekoration – se vores hjemmeside for højde inklusiv dekoration.
Area • Fläche • Areal
(*)
129 cm
12,4 m
2
12,4 m
2
2
3
4
5
227 cm
If seats are placed at different heights, than specified in the installation instructions,
!
compliance with the EN1176 safety rules cannot be guaranteed.
Wenn Sitze in einer anderen Höhe aufgehängt werden, als in der Installationsanleitung
angegeben, kann die Einhaltung der Sicherheitsvorschriften nach EN1176 nicht garantiert
werden.
Hvis sæderne placeres i andre højder, end der er angivet i montagevejledningerne, kan der
ikke garanteres for overholdelse af sikkerhedsreglerne i EN1176.
6
7
8
9
10
11
12
13
14
m
