MaxPro PROFESSIONAL MPCD14Li/2E Bedienungsanleitung Seite 6

PART NO. ARTICLE CODE
17 112-0020-017
18 112-0020-018
19 112-0020-019
20 112-0020-020
21 112-0020-021
22 112-0020-022
23 112-0020-023
24 112-0020-024
25 112-0020-025
26 112-0020-026
27 112-0020-027
28 112-0020-028
29 112-0020-029
30 112-0020-030
31 112-0020-031
32 112-0020-032
33 112-0020-033
34 112-0020-034
42 112-0020-042
51 112-0020-051
6 112-0020-006
10 112-0020-010
11 112-0020-011
12 112-0020-012
MPCD18Li/2E SPARE PART LIST
DESCRIPTION
2-Stage planetary gear
Dynamic teeth ring
Screw ST2.9*12
Rear gear box
Gear steel wire
Center wheel for no.3 layer
Washer
3-Stage planetary gear
Gear ring
Planet carrier
Self-locking pin
Shaft lock block
Locking collar
Self-locking washer
Circlips for shaft
Deep groove ball bearing
Front gear box
Output shaft
Screw
Motor Assembly
Motor
Gear for motor
Motor holder
Screw M3*8
SPECIFICATION WEARING PART
×
×
ST2.9*12
×
×
×
×
×
×
×
×
×
×
×
×
φ10
×
61800-2Z
×
×
×
ST2*4
×
×
GRS-550WFL
×
√
×
M3*8
×
QTY REQUIRED UNIT
3 Pcs
1 Pcs
4 Pcs
1 Pcs
1 Pcs
1 Pcs
1 Pcs
5 Pcs
1 Pcs
1 Pcs
6 Pcs
1 Pcs
1 Pcs
1 Pcs
1 Pcs
2 Pcs
1 Pcs
1 Pcs
2 Pcs
Set
1
1 Pcs
1 Pcs
1 Pcs
2 Pcs
