Camera layout

1
2
3
4
9
8
7
1 Shutter button
2 Flash
3 POWER button
Microphone
4
5 AF-assist light/timer lamp
6 Internal antenna
Lens
7
8 Speaker
9 Battery chamber cover
4
ST5500_QSM_EUR1.indb 4
All manuals and user guides at all-guides.com
5
6
10
11
12
16
15
10 Playback button
Status lamp
11
12 Zoom button
13 HDMI port (Accepts HDMI cable)
USB and A/V port
14
(Accepts USB cable or A/V cable)
15 Touch screen
16 Tripod mount
