Josef Kihlberg JK20T777L
KUDA PACKAGING
TABLE OF CONTENTS
5.2 Compressed-air connection / Lubrication
6.1 Loading the stapler
7.4 Replace driver blade
7.6 Adjust the clinch
9 Spare parts kit
10 Parts list with recommended wear parts
Exploded drawing
We take sole responsibility for declaring that the
bottom stapler JK20T777L, to which this declaration
refers, is in full compliance with the current require-
ments of the guidelines laid down by the council
on 17th May 2006 (2006/42/EG) "Machine
Guidelines".
Complies with norms: ISO 12100:2010
SERVIS A NAHRADNÍ DÍLY
2
www.kuda-packaging.com
1
Page
Weight
2
3
3
4
Magazine capacity
5
5
Staple leg length
5
Nose length
6
6
Throat depth
6
Recommended
7
working air pressure
7
Max. air pressure
7
8
Air consumption
8
per driving operation at
6 bar operating pressure 0.4 litres
8
9
Noise characteristic levels
9
according to: EN 12549
10
A-weighted single-event
10
emission sound pressure
11
level at work station
42
A-weighted sound
43
energy level
Vibration level:
45
FASTENERS
Staple JK777-10 (3/8")
Staple JK777-12 (1/2")
Staple JK777-16 (5/8")
DECLARATION OF CONFORMITY
SE-544 50 HJO, 11.06.2014
Production Manager:
Anders Pettersson
Agent for the publication of technical documentation:
Josef Kihlberg AB, Industrigatan 37B SE-544 50 HJO
+420 607 237 237
info@kuda-packaging.com
TECHNICAL DATA
2,3 kg (5,1 lbs)
Length 375 mm (14,8")
Width
68 mm (2,7")
Height 250 mm (9,8")
100 staples
10 - 16 mm (3/8" - 5/8")
14 mm (0,6 in.)
140 mm (5,5 in.)
5 - 6 bar (75-85 psi)
89 dB
96 dB
Vibration below the limit of
decla ration according to EN
792- 13 meassured
according to ISO 8662-11.
Art.No 400449
Art.No 400450
Art.No 400451
servis@josef-kihlberg.eu
06.14
