Sending MIDI file dump

Tap the FLASH button 4 three time while holding down the RECORD button. The display reads OUT indicating
the controller is ready to send a file
.
NOTES
1 During file dump, all other operations will not function. Functions will automatically return when the file dump is
completed.
2 File dump will be interrupted and stop if errors occur or power failure.

Implementation

1 With the MIDI function, you can transmit the memory content between two Scene Setters or to another Midi
Sys-Ex compatible sequencer or computer. Connect the Midi Out output of the sending unit to the Midi In
input of the receiving unit.
2 A received Sys-Ex Dump can delete all settings of a device. If you do not wish that a device accidentally
receives Sys-Ex data, switch it off or adjust another Midi channel.
3 During receiving and sending file dump, the controller will automatically search for or send Device ID of 55h
(85 decimal), a file named DC2448 with an extension of ".BIN".
4 The controller will send and receive Note On Off data via the Flash buttons.
Note No. (decimal)
22-69
70-93
94
95
96
97
98
99
100
101
102
The product is maintenance-free, except for occasional cleaning. You can use a lint-free, slightly dampened cloth
for cleaning. Refer all servicing to qualified personnel.
Power supply:
Power consumption:
Number of control channels:
DMX512 output:
Sound control:
Audio input:
Input sensitivity:
Dimensions (LxWxH):
Weight:
Specifications are subject to change without notice due to product improvements.

Accessories

No. 70064490
No. 30111556
No. 3022047N
.
Velocity
Program master
Channel intensity

CLEANING AND MAINTENANCE

TECHNICAL SPECIFICATIONS

12 V DC, 500 mA via supplied power unit connected to 230 V AC, 50 Hz
<10 W
48
3-pin XLR connector with polarity selector
via built-in microphone or via audio input
RCA
0.1-1 V
710 x 264 x 90 mm
7.5 kg
EUROLITE Foot controller with stereo jack
ROADINGER Mixer Case Pro MCB-27, sloping, bk, 7U
XLR cable 3pin 3m bk
31 • EN
Function
Program 1-48 on/off
Channel 1-48 on/off
Full On
Dark
Hold
Sound control on/off
Chaser/Scenes
Double Preset mode
Single Preset mode
Step
Blackout
