Modify a step or steps

1 Enter Edit mode.
2 Tap the STEP button to scroll to the step you wish to modify.
3 Press and hold the UP button if you want to raise the intensity. If you want to lower the intensity, press and
hold down the DOWN button.
While holding down the UP or DOWN button, tap the FLASH button corresponding to the DMX channel of the
4
scene you wish to modify until you reach the desired intensity value read from the display. Then you may tap
the FLASH buttons until you are satisfied with the new scene.
5 Repeat steps 2, 3 and 4 until all the steps have been modified.
6 Exit Edit mode. Tap the REC EXIT button while pressing and holding down the RECORD button. The scene
LED goes out, indicating the exit of Edit mode.

Running chase programs

Tap the MODE SELECT button to select CHASE/SCENES mode indicated by the red LED.
1
2 Tap the PAGE button to select the correct page the program you wish to run is located.
3 Push Master Fader B to its maximum position (fully down).
4 Move the desired Channel fader (25-48) to its maximum position to trigger the program, and the program will
fade in depending upon current fade time.
5 You may also hold down the respective FLASH button to trigger the program.
Move the Channel fader to adjust the output of the current program.
6
7 Multiple programs can be selected at a time. Simply move multiple channel faders or hold down the respective
FLASH buttons to trigger the desired programs.
8 Use the PARK button to switch between SINGLE CHASE mode and MIX CHASE mode.
• SINGLE CHASE LED lights: All chase programs will run in sequential order.
• MIX CHASE LED lights: All chase programs will run synchronously.

Sound control

1 Use the built-in microphone or plug an audio source into the RCA audio jack.
2 Select your program as described above.
3 Tap the AUDIO button until its LED lights, indicating Sound control mode is active.
4 Use the AUDIO LEVEL fader to adjust the music sensitivity.
5 To return to normal mode, tap the AUDIO button a second time causing its LED to go out. The Sound control
mode is disengaged.

Running a program with a standard speed

You can define and memorize a standard speed for every chase program.
1 Be sure the Sound control mode is disengaged. Tap the MODE SELECT button to select CHASE/SCENES
mode.
2 Tap the PARK button to select MIX CHASE mode. The LED lights indicating this selection.
3 Select your program as described above.
4 Move the SPEED fader until the display reads your desired value. You may also tap the TAP SYNC button
twice to define your speed.
While pressing and holding down the REC SPEED button, tap the FLASH button (25-48) that stores the
5
program.
6 The program will then run with the set speed when engaged.
7 Repeat steps 4 and 5 to set a new speed.
.
NOTE
Programs with memorized standard speed do not react to manual speed settings or Sound control mode.

RUNNING PROGRAMS

28 • EN
