Technische Daten
Maße:
Gewicht:
Betriebsspannung:
Betriebsstrom:
maximale Winkelgeschwindigkeit: 80°/ sec
mit Servo kompatibel: 1,52 µs analog
mit Sender kompatibel: PPM / PCM / 2,4G
Arbeitstemperatur:
Funktionen und Verbindungen
Eingangssignale
AILE IN
Querruder
ELE (E)
Höhenleitwerk
RUD (R)
Querruder
SW
Locking - Mode - Schalter
AUX IN
Landeklappe
Ausgangssignale
AILE OUT
Querruder
ELEV OUT
Höhenleitwerk
RUDD OUT
Querruder
FLAP OUT
Landeklapen
Modell - Auswahl
S1 • S2 • S3
Setting
Normal Airplane
Flying Wing (delta)
V-Tail
36 x 28 x 6 mm
15 g
DC 3,5 V - 9 V
20 mA
1,52 µs digital
-15°C bis +60°C
S1
S2
S3
AIL OUT
0
0
0
-
1
0
0
AIL servo
0
1
0
left wing servo
0
0
1
AIL servo
Specification
Dimensions:
Weight:
Operating voltage:
Operating current:
Maximal angular velocity: 800 degrees/ sec
Servo compatibility
Radio compatibility:
Operating Temperature:
Function and connection
Signal Input
AILE IN
Signal input for Aileron
ELE (E)
Signal input for Elevator
RUD (R)
Signal input for Rudder
SW
Locking mode switch
AUX IN
Signal input for Flap
Signal Output
AILE OUT
Signal output for Aileron
ELEV OUT
Signal output for Elevator
RUDD OUT
Signal output for Rudder
FLAP OUT
Signal output for Flap
Model Selection
S1 • S2 • S3
ELEV OUT
-
ELE servo
right wing servo
left wing servo
36 x 28 x 6 mm
15 g
DC 3.5 V - 9 V
20 mA
1.52 µs analog servo
1.52 µs digital servo
PPM / PCM / 2.4G
-15°C to +60°C
RUDD OUT
-
RUD servo
RUD servo
right wing servo
