Operation; Specifications - BST IPS10-400 Bedienungsanleitung

6 • IPS10-400
5. The unit has a TONE control (8), BASS (11) and TREBLE (12) controls.
6. Set the overall volume via the MASTER control (13).
7. Voice priority: Set the switch (3) to on. If you speak into the microphone, the music will be cut off and
resume once the microphone is not used anymore.

Operation

1. Playing audio files: Select Bluetooth mode via the remote control or unplug the USB input so that the
audio player selects automatically Bluetooth mode.
2. Bluetooth connection: Turn on the Bluetooth function on your mobile device. Search and select "BST" for
Bluetooth connection.
3. Selecting an audio file: Press the number keys on the remote control to select the desired file. If the num-
ber has two digits, press 0 first and then enter the other two digits. Example: 58 = 0+5+8

SPECIFICATIONS

MAIN UNIT
Woofer ...........................................................................................................................................10"/25cm
RMS/max. power.......................................................................................................................... 70/400W
Tweeter...........................................................................................................................................1"/25mm
Amplifier .......................................................................................................................................... class D
Power supply ....................................................................................................... AC: 220-240V~ 50/60Hz
.................................................................................................................DC: 25.2V�� 8Ah Lithium battery
Charging time........................................................................................................................................ 7-9h
Operating time ...................................................................................................................................... 4-6h
Freq. range ...................................................................................................................... 50Hz-18Khz±3dB
UHF Frequencies .................................................................................................. 863.05MHz/864.65MHz
BT frequency band ............................................................................................................ 2402-2480MHz
Max. RF power.............................................................................................................................. 1.99dBm
Dimensions ................................................................................................................... 474 x 442 x 638mm
Weight................................................................................................................................................... 15kg
MICROPHONES
Type .............................................................................................................................. Dynamic handheld
Frequency ............................................................................................................ UHF 863MHz – 865MHz
........................................................................................................................................... CH A 863.05MHz
........................................................................................................................................... CH B 864.65MHz
Spurious emissions ....................................................................................................................... >55dBm
Power source .......................................................................................2 x AA 1.5V batteries (included)
Operating time ................................................................................................................. Approx. 6 hours
On-board indicators............................................................................................ Power status / On / Off
Dimensions ..................................................................................................................... Ø50mm, L 260mm
Weight................................................................................................................................................... 162g
