In CYCLE mode, the current charge and discharge settings are used.
Starting charge/discharge
Hold the START button pressed for 3 sec. to start charge/discharge/
cycle.
Changing the charging current during charge/discharge:
Press the START/ENTER button – change the charging current with
the DEC/INC buttons (press Enter to save new value).
Changing display indications: ( Information under "Additional
display indications")
Press the DEC/INC buttons to select the indications (battery values).
Completion of charge/discharge is indicated by the message "FULL"
in the display or by an acoustic signal.
Charging can be stopped at any time by pressing the MODE/ESC
button.
6.3 Lead batteries
Press the ESC/MODE button to access the PROGRAMM/SELECT
menu and select the battery type (Pb).
Press the START/ ENTER button to access the battery settings.
Press the DEC/INC buttons to select function mode:
Pb CHARGE- normal charging
Pb DISCHARGE- battery discharge
Changing the battery settings
Press the START button, Charging current or Battery voltage will
flash. Press the DEC/INC buttons to change the values - do not
forget to press ENTER to save changes. Press the DEC/INC button
again to enter discharge mode. Press the START button, Discharge
current will flash.
Make further settings as described above.
(setting range 2V-20V-1P-20P)
Starting charge/discharge
Hold the START button pressed for 3 sec. to start charge/discharge.
GB // 14
All manuals and user guides at all-guides.com
CHG = normal
charge mode
DSC = discharge
mode
D>C = discharge-
charge cycle
C>D = charge-
discharge cycle
Changing the charging current during charge/discharge:
Press the START/ENTER button – change the charging current with
the DEC/INC button (press Enter to save new value).
Changing display indications: ( Information under "Additional
display indications")
Press the DEC/INC buttons to select the indications (battery values).
Completion of charge/discharge is indicated by the message "FULL"
in the display or by an acoustic signal.
Charging can be stopped at any time by pressing the MODE/ESC
button.
6.4 Power supply function
This function enables the charger to be used as a variable power
supply.
Adjustable output ranges:
voltage: 3 V - 24 V
current: 0.1 A - 6.0 A
Battery memory
The charger can store up to 10 different charging profiles. The
stored profiles can be quickly accessed without going through the
set-up process.
CHG = normal
charge mode
DSC = discharge
mode
Press the START/ ENTER button to
access the settings.
Press the DEC/INC buttons to
select the memory (do not forget
to press START/ENTER to save the
selection).
