Tungsram Inlumino Gen 2 Einbauanleitung Seite 10

4
6
2
+5 °+10° +15 °
0°
-5°
-10°
-15°
!
250/400 V
16 A
1
Class I.
Class I.
Class I.
0-10 V
5
7
4,6
II.
I.
5Nm 15Nm
+5°+10° +15°
0°
-5°
-10°
-15°
30mm 10mm
L BROWN
N BLUE
YELLOW/GREEN
DALI BLACK
DALI GRAY
L BROWN
N BLUE
YELLOW/GREEN
L
BROWN
N BLUE
DALI BLACK
DALI GRAY
L BROWN
N BLUE
A+ BLACK
A- GRAY
L BROWN
N BLUE
YELLOW/GREEN
