RICOO WM0623 Montageanleitung Seite 12

ENGLISH
ERROR
E05
The collision avoidance system has been activated. Remove all objects within the movement range.
An electrical problem has occurred. Unplug the power plug and plug it in again. If this does not remedy the problem, replace the
E06
control unit.
> The collision avoidance system has been activated. Remove all objects within the range of motion.
> The control unit is not properly attached. Make sure that the control unit is properly attached to the table frame as described in
E08 the mounting instructions.
> The power cables are not properly plugged into the control unit. Make sure that the cables are correctly connected to the control
unit.
The motor cables have been disconnected. Check the connection or replace the motor cables. E11 corresponds to the M1
E11 / E21
connector and E21 corresponds to the M2 connector.
An electrical problem has occurred. Unplug the power plug and plug it in again. If this does not remedy the problem, replace the
E12 / E22
control unit.
The connection to the motor may be interrupted. Check the connection or replace the motor cables. E13 corresponds to the M1
E13 / E23
connector and E23 corresponds to the M2 connector.
The cable connection may be interrupted. Check the connection or replace the motor cables. E14 corresponds to the M1 connector
E14 / E24
and E24 corresponds to the M2 connector.
E15 / E25
Short circuit. Replace the motors or stand legs. E15 corresponds to connector M1 and E25 corresponds to connector M2.
E16 / E26
An overload will cause the motor to stop running. Remove the objects from the work surface and reset the system.
The table moves in the wrong direction. Check the connection or replace the motor cables. E17 corresponds to the M1 connector
E17 / E27
and E27 corresponds to the M2 connector.
E18 / E28
An overload has occurred. Remove the objects from the work surface and reset the system.
The memory cannot be read. Unplug the power plug and plug it in again. If this does not remedy the situation, replace the control
E42
unit.
E43
Failure of the collision avoidance system. Replace the control unit.
Press the [ M ] and [ T ] keys simultaneously for about 5 seconds until the device beeps and the „
keys to toggle between „ " to „
operation is performed within this time, the user-defined mode is terminated.
When the display flashes „
Adjusting the minimum height
altitude limit will be displayed (by default „
limit
desired altitude.
(62~118cm / 24.4"~46.4")
When the display flashes „
altitude limit will be displayed (by default „
Adjusting the maximum
desired altitude.
height limit
(Note: For display range reasons, the display will not show the number immediately when the [▲]/[▼]buttons are
(72~112cm / 28.3"~50.4")
pressed when setting the metric system).
When the display flashes „
Set anti-collision sensitivity
sensitivity is displayed (by default „
(upward direction)
level.
(Level 0 ~ Level 8)
When the display flashes „
Set anti-collision sensitivity sensitivity is displayed (by default „
(downward direction)
level.
(Level 0 ~ Level 8)
When the display flashes „
Set anti-collision sensitivity
sensitivity is displayed (by default „
(Gyrosensor)
level.
(Level 0 ~ Level 8)
When the display flashes „
Set current table top
top thickness is displayed (by default „
thickness
desired table top thickness.
(0~5cm / 0~1.9")
When the display flashes „
Operation lock top thickness is displayed (by default „
Switch on / off
operation/display lock on / off.
(0: OFF / 1: ON)
- To cancel a custom operation, press the [ T ] button or wait approx. 8 seconds until the display automatically returns to the table height display.
- The maximum/minimum height limit displayed in the user-defined mode does not include the thickness of the working surface.
TROUBLESHOOTING GUIDE
DESCRIPTION
CUSTOM PROGRAMMING GUIDE
STEP: 1
". The custom mode is active while the display is flashing (for about 10 seconds). However, if no
STEP: 2
", press [ M ] buttononce and the current minimum
", press [ M ] button once and the current minimum
", press the [ M ] button once and the current anti-collision
"). Then press [ ▲ ] / [ ▼ ] key to set the desired
", press the [ M ] button once and the current anti-collision
"). Then press [ ▲ ] / [ ▼ ] key to set the desired
", press the [ M ] button once and the current anti-collision
"). Then press [ ▲ ] / [ ▼ ] key to set the desired
", press the [ M ] button once and the currently set table
", press the [ M ] button once and the currently set table
12
" indicator flashes. Press the [ ▲ ] / [ ▼ ]
"). Then press [ ▲ ] / [ ▼ ] key to set the
"). Then press [ ▲ ] / [ ▼ ] key to set the
"). Then press [ ▲ ] / [ ▼ ] key to set the
"). Then press [ ▲ ] / [ ▼ ] key to turn the
ENGLISH
STEP: 3
[ M ] press: save.
- successful
- failed
[ M ] press: save.
- successful
- failed
[ M ] press: save.
- successful
- failed
[ M ] press: save.
- successful
- failed
[ M ] press: save.
- successful
- failed
[ M ] press: save.
- successful
- failed
[ M ] press: save.
- successful
- failed
