6. Out of Range Alarm Setting (F5)
After entering F5 function interface, the display shows the current alarm time after out of range and you can select your desired time. When
the Pager is taken out of range of keypad for a certain time, the pager will beep and let customers know that they will miss the call. The time
can be set to 0-30 minutes (0 means the alarm is off. The other numbers represent when the pager will beep after being out of range. )
The beep will automatically stop when they step back within range.
NOTE: You have to set the pager ID again to activate the settings.
Note: When out of range alarm function is turned on, if the keyboard is turn off (unplug the power adapter), the Pager will
automatically alarm because it cannot receive the transmitted signal.
7. Service Countdown Time Setting (F6)
After entering F6 function interface, the display shows the current service countdown time and you can select your desired countdown
time(0-99 minutes). 0 means the function is off, the other numbers represent when the pager will automatically beep again after the first call
is received if they do not collect orders in time.
The beep will automatically stop when the pager is placed on the charging station.
NOTE: You have to set the pager ID again to activate the settings.
8. Keypad ID Setting (F7)
After entering F7 function interface, the display shows the current keypad ID and you can select your desired channel (1-99). When you
input the expected number and press OK button, the keypad beeps at the same time, it means the setting is successful.
NOTE: You have to set the pager ID again to make the pager system work after changing keypad ID.
9. Keypad Password Setting (F8)
After entering F8 function interface, the display shows "0.0.0.0.". To set up the password for the keypad, input four-digit number and press
OK button, the keypad beeps at the same time, it means the setting is successful.
("2580" is the default password, you can unlock the keypad in any situation. )
10. Frequency Setting (F9)
After entering F9 function interface, the display shows the current frequency and you can select your desired frequency (channel 01-31,
each channel stands for a frequency list below). When you input the expected number and press OK button, the keypad beeps at the same
time, it means the setting is successful.
NOTE: You have to set the pager ID again to make the pager system work after changing the frequency.
11.Keyboard Prompt Mode Setting (F10)
After entering F10 function interface，the display shows the current prompt setting. "1" means the Beep is turned on, "0" means the keypad
in Mute function. If you want to change the prompt mode, you could enter the corresponding number and press OK button the confirm. The
keypad beeps at the same time, it means the setting is successful.
Frequency Channel Comparison Table(MHz)
1 433.92
5 444.4
2 433.925 6 447.675
3 434.7 7 447.963
4 439.7 8 447.925

Specifications

Pager
Operating Voltage
Working frequency
Standby current
Standby time
Receiving sensitivity
Battery capacity
Modulation technology
Charging Tray's Power Source
Reminder Method
Size
Keypad Transmitter
Power input
Working Frequency
Modulation technology
Size
9 447.938 13 450.25
10 447.95 14 450.325
11 449.75 15 450.375
12 450 16 452.575
DC 3.7V (Rechargeable battery)
424.8-469.025MHz
7mA
≈25Hour
-120dBm
300mAh
FM
12V/1A
Vibrating, Buzzing & LED Flashing
135*58*23mm
DC12V/1A
424.8-469.025MHz
FM
162*98*40mm
17 453.025 21 457.575
18 453.075 22 458.55
19 453.125 23 458.663
20 457.525 24 459.05
2
25 461.263 29 469.025
26 461.475 30 424.8
27 462.75 31 433.5
28 464.638
