Transmitter Preparation
調整遙控器
A new Ni-MH battery must be charged before it is used.Refer to the charger instruction manual for charging.
在使用之前，一個新電池必須先充電。詳情請參考充電器說明書。
Set up the radio control system as indicated below。
如下圖所示安裝接收機控制系統
Battery
電池
2
11
5
DIGITAL
PROPORTIONAL
RADIO CONTROL
SYSTEM
6
ON
5
8
10
OFF
1
Start
1
2
3
4
5
6
7
8
Finish
9
10
11
Tools required
組裝需要的工具
Needie Nose Pllers
尖嘴鉗
Ball differential Grease(Clear)
差速滾珠油(清澈)
Molybdenum Grease(Black)
鉬油(黑)
Hex Wrench
Hex Wrench
十字套筒
六角扳手
All manuals and user guides at all-guides.com
3
8
Transmitter
發送機
6
ON
10
OFF
Install batteries.(Transmitter)
Extend the antenna.(Transmitter)
Connect the battery
Extend the antenna.(Reveiver)
Center the trims.
Switch on.(Transmitter)
Switch on.(Reveiver)
Make sure the servos are in command.
Switch off.(Reveiver)
Switch off.(Transmitter)
Retract the antenna(Transmitter)
Awi
錐
SP KINFE EDGE REAMER
刀刃 絞刀
No need to pre-drill precise holes
(1mm to 15mm)can be drilled
可以對預鑽的孔準確的鑽深
1mm-15mm,不需要穿透
Servo
伺服機
開始
結束
Screw Cement
Grease
螺絲膠水
潤滑油
Wire Cutters
鋼絲鉗
Sharp Hobby knife
美工刀
Electronic Speed
Controller
電子加速控制器
4
Receiver
接收 機
1
安裝電池(發送機)
2
拉出天線(發送機)
3
連接電池
4
拉出天線(接收機)
中心對整齊
5
開關(發送機)
6
7
開關(接收機)
8
確定控制伺服機
9
關閉開關(接收機)
10
關閉開關(發送機)
11
收回天線(發送機)
Instant Glue
瞬間膠水
ROUND CUTTER&SANDER
剪刀&挫刀
For trimming bodies!
用於修剪車殼！
Motor
馬達
7
9
Switch
開關
