Front Swaybar
Bag
Stabi vorne
T08606 M3x3
Screw
Cement
T08601
Swaybar Mount
Stabi Halterung
T08601 M2.5x8
T08601 M3x3
T08601 M3x3
T08601 M2.5x8
-
8
Front Hub Carrier
Bag
Achsschenkel vorne
T08703
95.5mm Front CVD
95.5mm CVD vorne
T08703 5x8.5
T08703 5x8.5 CVD Shaft
T08703 2.5x12.8 Pin
..................2
T08603 King Pin Bushing
T08665 13x19x4 Ball Bearing
Kugellager
T08649 2.5x16.8 Pin
.........2
T08703 M4x4 Screw
T08664 8x16x5 Ball Bearing
Kugellager
T08673 M4x14 Screw
.........2
Assemble both Left and Right
L
R
Beide Seiten (links/rechts) auf
die gleiche Weise montieren
All manuals and user guides at all-guides.com
T08601 M2.5x8
D
T08703 2.5x12.8
T08703
CVD Schaft
........................2
Blockhalterung
.........4
...............2
Schraube
T08673 M4x14
.....................2
Schraube
L
......4
R
Assemble as many times as specified
x2
So oft montieren wie angegeben
T08674 M2.5x8 Screw
Schraube
..................3
T08601/T08606 M3x3 Screw
Schraube
........................4
T08606 6.8 Ball stud
Kugelkopf
.....................2
T08606 M3x3
Screw
Cement
T08647
Front Swaybar
Satbi vorne
Right
Left
Links
Rechts
Front Hub Carriers 12 Degree
T08603
Achsschenkel vorne 12 Grad
T08665 13x19x4
Apply threadlock
Schraubensicherungslack verwenden
Screw
Cement
4
T08606 6.8 Ball stud
Kugelkopf
.....................2
T08606 6.8 Ball End
Kugelpfanne
..................2
T08606
x2
Left
Links
Steering Block
T08604
Lenkhebel
T08603
King Pin Bushing
Blockhalterung
T08649 2.5x16.8
T08664 8x16x5
T08649
Wheel Hex Hub
Radmitnehmer
T08703 M4x4
Screw
Cement
Right
Rechts
