A
G
Fig. 2: PrimoTherm® 180-2 DN 32
Product description
B
180-1 DN 32 / 180-2 DN 32 / 180-3 DN 32 RTA
C
A. Ball valve, with thermome-
ter blue
B. Wall bracket kit, complete
with all mounting parts
C. Ball valve, with thermome-
ter red
D. Circulation pump (optional
component)
E. 3-way mixer with actuator
D
ARM343
F. EPP Insulation, 5 pieces
G. Return pipe with inte-
grated gravity brake and T
E
piece bypass
F
EN
9
