General Safety Rules - CUOGHI NADER midi 3 DL EG Bedienungsanleitung

M1277-0
Indicative handling volume [m³]
Condensate capacity [L/24hour]
Working temperature [°C]
Working humidity [%R.H.]
Air flow [m³/hour]
Power supply voltage
Current absorption [A]
Power absorption [W]
Power absorption in standby (max) [W]
Motor protection rating
Current type
Refrigerating gas charge [g]
Refrigerating gas
Refrigerating circuit maximum pressure [MPa]
Noise level at 1 metre distance [dBa]
Dimensions w×h×d [mm]
Weight [Kg]
Condensate collection tank capacity [L]
s
ymboLs
B
This symbol indicates that the appliance
has been loaded with flammable refriger-
ant gas.
D
Read this manual carefully.
A
Operator's manual, instructions for op-
eration and routine maintenance.
E
ATTENTION: every notes under this
symbol will evidence dangerous condi-
tions that can cause problems to persons
and thinks if not made in the right way.
Follow carefully the description.
C
Important note: notes will evidence con-
ditions and features that can make easier
and better the use of the unit.
F
DANGER, live electrical parts
at 25°C and 65% U.R.
(*)
Tab.A – Main data
g
eneraL safety ruLes
D
Preserve and carefully read this manual as all warn-
ings provide important safety information on instal-
lation, use and maintenance.
B
This appliance contains flammable pressurized refrig-
erant: any maintenance concerning the refrigerant
circuit must be carried out by technical personnel who
have a valid certificate issued by an accredited orga-
nization, which certifies their competence to operate
safely with this type of refrigerants.
• The refrigerant fluid is odorless: if you suspect that there is a
refrigerant gas leak, properly ventilate the room before doing
anything else.
• The appliance must be placed in a room where there are NO
sources of ignition continuously operating (for example: open
flames, electric or gas heaters).
• This dehumidifier is NOT intended for people, including chil-
dren, with limited physical, sensory or mental capabilities or
without enough experience and knowledge, unless they have
been instructed on its proper use by a person responsible for
their safety. Keep it away from children and animals.
• This dehumidifier SHOULD not operate in rooms where a
danger of explosion exists.
• Do NOT use this dehumidifier in environments with air con-
taining oil, sulphur or chlorine.
• Always keep the inlet and outlet air grids free (10 centimeters
at least).
• The appliance must always operate in a vertical position with
the four wheels turned downwards.
• Do NOT move the dehumidifier when working.
• To move the dehumidifier switch it off and empty the conden-
sate tank.
• Do NOT put any tool inside the unit.
• Do not puncture or burn.
ENGLISH
Nader midi 3 DL
300
10.0 19.1
(*) (**)
+5 / +32
40 / 95
250
230 V, 50 Hz
1.12 1.32
(*) (**)
248 296
(*) (**)
2
IP20
Alternating
See label
R1234yf
1.2
50
340×501×320
15.8
4.5
at 32°C / 90% U.R.
(**)
9
