6 Mounting the camera as an autoguider and
scope of delivery
Illustration 1: Mounting the Full HD Deep-Sky Camera as Autoguider
1 Full HD Deep-Sky Camera
3 USB connecting cable
5 Telescope
7 Control panel of the mount
9 Recording device
camera or other deep sky camera)
11 USB 2.0 socket on the camera
1
Additional accessories may be required for mounting a recording device
Delivery content
Camera (A), ST4 connection cable (B), USB connection cable (C), C-mount adapter, software CD
6 / 16
6
8
10
1
(e.g. single lens reflex
4
1
A
5
7
2 ST4 connecting cable
4 Guiding scope
6 ST4-capable mount
8 ST4 socket on control panel
10 Computer
12 USB 2.0 socket on the camera
11
12
9
C
B
2
3
