Hotkey and push-button reference sheet
Hotkey sequence
The hotkey sequence is activated by pressing the ScrLk key twice and then entering the desired hotkey command.
All SwitchView Switches
COMMAND HOTKEYS
Select PC ScrLk + ScrLk + X
x = 1 ~ 2 or 1 ~ 4 for PC channel number
Next Higher/Lower ScrLk + ScrLk + Up Arrow/Down
Channel Arrow
Beep Sound ScrLk + ScrLk + B
On/Off
Autoscan ScrLk + ScrLk + S
SwitchView DVI, MM1 and MM2 Switches only
Switch KVM and ScrLk + ScrLk + Fx
Fx is the function key that corresponds
USB Hub
(No Audio) to the port number
(F1 ~ Port 1, F2 ~ Port 2,
F3 ~ Port 3, F4 ~ Port 4)
Switch KVM and ScrLk + ScrLk + Fy
Audio Fy = F5 ~ F8
(No USB Hub) (F5 ~ Port 1, F6 ~ Port 2,
F7 ~ Port 3, F8 ~ Port 4)
Bind PC and Hub Port ScrLk + ScrLk + Z
Control Switching
Unbind PC and ScrLk + ScrLk + X
Hub Port Control
Switching
Bind PC and Audio/ ScrLk + ScrLk + Q
Mic Switching
Unbind PC and Audio/ ScrLk + ScrLk + W
Mic Switching
Autoscan with ScrLk + ScrLk + S + X
Programmable X = 1 ~ 6
1 - 10" ; 2 - 20" ; 3 - 3" ;
Delay Time
4 - 40" ; 5 - 50" ; 6 - 60"
Previous PC Channel ScrLk + ScrLk + (backspace)
SwitchView DVI and MM2 Switches only
Define Hotkey ScrLk + ScrLk + H + (y)
Preceeding Sequence y = ScrLk, Caps Lock, Esc, F12 or
Num Lock
Autoscan with ScrLk + ScrLk + S + (z)
Programmable z = 0 ~ 9
Delay Time 1 - 10" ; 2 - 20" ; 3 - 3" ;
4 - 40" ; 5 - 50" ; 6 - 60" ;
7 - 70" ; 8 - 80" ; 9 - 90" ;
0 - 100"
SwitchView PC and MM1 Switches only
Reset KVM ScrLk + ScrLk + End
NOTE: The default setting of the SwitchView MM1 USB KVM switch is appropriate for most systems. However, to utilize a USB keyboard/mouse, you may
need to disable the PS/2 option in the BIOS and enable the USB option instead. In order for your PC to find your USB keyboard and mouse, you will need to
sync your hub port control and PC port selection (for example, the green PC port LED and red USB hub port LED should be aligned). Also, USB keyboard
users will NOT be able to utilize the SwitchView MM1 switch hotkey function.
To Contact Avocent Technical Support
Avocent, the Avocent logo, The Power of Being There and SwitchView are registered trademarks of Avocent Corporation or its affiliates. ©2005 Avocent Corporation. All rights reserved.
All manuals and user guides at all-guides.com

PUSH-BUTTON

Press the Select button to
select the next channel
Press the Select button to
toggle to the next channel
N/A
Press any key to
stop Autoscan
Press the corresponding
button to select the specific
PC + USB hub port control.
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
CALL (888) 793-8763 VISIT www.avocent.com/support
DESCRIPTION
Select the active channel
Select the next
connected channel
Toggle on/off beep sound for switching
confirmation
Autoscan through every connected channel for
quick screen browsing of each channel
Select the PC channel for all USB hub ports
control (joint select PC port and hub port control
if binding is enabled)
Select the active audio and mic
channel (joint select PC/Audio and mic channel if
binding is enabled
Enable the binding of PC port and hub port
control switching (factory default)
Disable the binding of PC port and hub port
control switching
Enable the binding of PC port and audio/mic
switching (factory default)
Disable the binding of PC port and audio/mic switching
Specify delay time within a range of 10 ~ 60
seconds (4-port only)
Toggle between previous channel and current channel
Select the hotkey preceding sequence from the
following: ScrLk, Caps Lock, Esc, F12 or
Num Lock
Specify delay time within a range of 10 ~ 100
seconds
Reset the KVM switch for switch system reboot
