13.4 Cutting with workbench
WARNING: Always cut in a forward direction. Never draw the tool
backwards. If you are a novice user, practice by cutting thin wood until
proficient.

Set cutting angle of workbench. (See Cutting angle adjustment Section)

Place the work-piece onto the workbench and clamp the work-piece with clamp
subassembly (20). (See Installing and adjusting the clamp Section)
NOTE: if the length of the work-piece is longer than normal level, you can
use extended function of extension rod (23), hold the Tiltable support (24)
and pull the extension rod to a suitable position for current work-piece.
(Refer to Fig. 9 and Fig. 10)

Fit the correct blade ensuring it is sharp and not damaged.

Set the depth of cut. (See Setting the Cutting Depth Section)

Grasp the tool firmly (See Holding and Switching ON/OFF Section), switch on the tool and
wait for a moment for the blade to run up to speed. Next, depress the safety lock button
(3) and plunge the blade into the material slowly and gently, but firmly. Then push the tool
forwards along the guide rails (19) to be cut.
NOTE: Never draw the tool backwards.

Once the cut has been finished, lift the tool from the workbench before switching off. If a
lot of dust has been created, keep switched on for a few seconds extra to allow the dust to
clear from within the tool.
NOTE: if cutting without workbench, you can refer to the below
descriptions:

Check the blade whether is correct and ensuring it is sharp and not damaged.

Set the depth of cut, switch on the tool and wait for a moment for the blade to run up to
speed.

Depress and hold the safety lock button (3) on, plunge the blade into the material slowly
and gently, but firmly.

Push the tool forwards along the line to be cut. If necessary, switch on the laser generator
(1). (Refer to Laser line generator Section)

14 CLEANING AND MAINTENANCE

Regular cleaning is required for the safe operation of the tool, as an excessive build up of dust
will prevent the tool from operating correctly.
The dust extraction hose (b) may block and require cleaning occasionally, especially if damp
wood is being cut.

Unplug from mains supply.

Clean thoroughly with a small soft brush, like a paint brush.

Keep the cooling vents on the motor housing clean and unobstructed at all times.

Never use any caustic agents or solvents to clean the plastic parts.
