3. Mount the handle (5) to the basket (9). In the internal part of basket there are 2 holes: insert the 2 pins
present in the handle (5) inside the holes, then pull strongly the handle until it blocks.
4. Insert the basket in the oil container, and close the lid (3).

OPERATING THE UNIT

CAUTION: Do not turn on the fryer without oil in the reservoir.
1. Place the unit on a flat, stable and heat-resistant surface.
2. Open the lid (3) and remove the basket (9), using the handle (5).
3. Fill the reservoir with cooking oil (3 liters) between MIN and MAX level mark.
4. Spread a little of oil on the view window (2) to prevent condensation during use.
5. After making sure that the power knob (7) is set to OFF, connect the power cable to compatible electric
outlet. The Power light (6) will switch ON.
6. Set the desired temperature using the regulator (8). At the switch on also the temperature light (4) turns on.
Once you have reached the desired temperature, the green light will turn off (TEMP).
7. Put food in the basket, immerse the basket in oil and close the lid (3).
CAUTION: Do not immerse the frozen food with crystal ice on it.
8. Once finished, open the lid (3) and lift the basket (9) using the handle (5); place the basket over the
container (12) using the support on the basket. Allow to drain the oil in excess directly into the basket for a
few seconds, then roll out the foods and let them dry on paper towels before serving.

COOKING TIME AND TEMPERATURE

FOOD
CHICKEN WINGS
FRENCH FRIES
CHICKEN (slices)
SHRIMPS
ONION RINGS
FISH
EGGPLANT, ZUCCHINI
NOTE: The table is for guidance only. It is therefore recommended to adjust temperature and cooking
times by referring to the weight, thickness and type of storage of food to be cooked, constantly checking
the state of cooking and always referring to your own experience and taste.

CLEANING

WARNING: Turn the power knob to OFF and unplug the appliance from the electrical outlet before
cleaning.
- Do not immerse the housing (10) in water, but wash it with a damp cloth and non-abrasive detergent. Also
avoid any infiltration of water inside the motor unit.
- All parts except heating element and housing (10) can be washed like every day crockery with non-
abrasive sponge and dish detergent. Dry them completely before you assembling the motor unit again.

TECHNICAL FEATURES

•
Power supply: AC 230V
•
Capacity 3 lt
•
Stainless steel basket
•
Temperature control switch (from 90° up to 190°C)
•
Stainless steel oil tank
TEMPERATURE
150°C
190°C
190°C
170°C
190°C
170°C
190°C
~
50Hz - Power 2000W
COOKING TIME
12/14 mins
8/10 mins
5/8 mins
2/4 mins
3 mins
5 mins
2 mins
12
