Parameter and Functions
To enter the programming mode, press buttons [S1/-] and [mA/+] for at least 3 s until the display starts fl ashing.
Step Parameter
0 Cod
1 SP
2 hS
3 OU
4 dS
5 dr
6 nF
I
7 A4
8 A20
9 Cod
To terminate programming and save all values press button [M] for at least 3 s until the display stops fl ashing.
Technical data (s. also page 10)
Operating voltage ................................................................................... 24 VDC ± 10 % .............................................24 VDC ± 10 %
Current consumption ....................................................................................... < 100 mA ...................................................... < 100 mA
Switching output ................................................................PNP, NO/NC programmable ..........................PNP, NO/NC programmable
Switching current ............................................................................................ < 200 mA ...................................................... < 200 mA
Analogue output ...................................................................................4...20 mA (linear) ...........................................4...20 mA (linear)
Analogue output with defect measuring system ...................................................... 2 mA ............................................................. 2 mA
............................................................................................. 200...500 Ω .......................................................200...500 Ω
Load R
L
Measuring tolerance
– 1...5 l/min .............................................................................................≤ ± 0,1 l/min ....................................................................–
– 5,1...40 l/min ........................................................................................≤ ± 2 % o. Mv. ....................................................................–
– 0...10 l/min ...............................................................................................................– ................................................≤ ± 0,2 l/min
– 10,1...80 l/min .......................................................................................................... – ...............................................≤ ± 2 % o. Mv.
Operating range ........................................................................................... 1...40 l/min ................................................... 1...80 l/min
Adjustable range SP1 ................................................................................... 1...40 l/min ................................................... 1...80 l/min
Hysteresis SP1 ............................................................................................. 0,2...5 l/min ................................................... 0,2...8 l/min
Electrical conductivity of the medium .........................≥ 10 µS/cm (≥ 15 µS/cm for water) ................≥ 20 µS/cm (≥ 30 µS/cm for water)
Switch-on/switch-off delay ................................................................................. 0...50 s ......................................................... 0...50 s
Availability time .................................................................................................. 6...10 s ......................................................... 6...10 s
Response time .................................................................................................. 0,5...8 s ........................................................ 0,5...8 s
Sensor material ...........................................................A4 (1.4571)/AISI 316Ti and PVDF ..................A4 (1.4571)/AISI 316Ti and PVDF
Process connection material ........................................................ A4 (1.4571)/AISI 316Ti ................................. A4 (1.4571)/AISI 316Ti
Housing material .......................................................................................................PBT ...............................................................PBT
Pressure resistance ............................................................................................. 10 bar ........................................................... 10 bar
Flow rate display ...............................................................................7-segments/3 digits ...................................... 7-segments/3 digits
Connection ........................................................................................4-pole, M12 x 1 .............................................4-pole, M12 x 1
Hans Turck GmbH & Co.KG Witzlebenstraße 7
•
All manuals and user guides at all-guides.com
Parameter value Parameter value
FCMI-10D08... FCMI-15D12...
0...255
1...40
0.2...5
nO or nC nO or nC
0...50
0...50
0...8
0...30
10...40
0...255
45472 Mülheim/Ruhr Germany Tel. +49 (0)208 4952-0
• • •
Function
0...255 Enter access code (Factory setting 0)
1...80 Adjustable range switch point S1 [l/min]
0.2...8 Hysteresis switch point S1 [l/min]
Output switch point S1 [NO/NC]
0...50 Switch-on delay switch point S1 [s]
0...50 Switch-off delay switch point S1 [s]
0...8 Average forming [s]
0...60 MIN value [l/min] for 4 mA
20...80 MAX value [l/min] for 20 mA
0...255 Modifi cation of the access code
FCMI-10D08
Fax +49 (0)208 4952-264
•
more@turck.com www.turck.com
• •
FCMI-15D12
7
