Seite 1
All manuals and user guides at all-guides.com LE 5 000 DF LE 10 000 DF Leister Technologies AG Galileo-Strasse 10 CH-6056 Kaegiswil/Switzerland Tel. +41 41 662 74 74 +41 41 662 74 16 www.leister.com sales@leister.com...
Seite 2
All manuals and user guides at all-guides.com Size 3, 4 Wiring Diagram Deutsch Bedienungsanleitung English Operating Instructions...
Seite 3
All manuals and user guides at all-guides.com LE 5000 DF Size mm...
Seite 4
All manuals and user guides at all-guides.com LE 10 000 DF Size mm...
Seite 5
All manuals and user guides at all-guides.com Wiring Diagram LE 5000 DF; LE 10 000 DF Power...
LE 5000 DF; LE 10 000 DF Anwendung Die Leister Lufterhitzer LE 5000 DF und LE 10 000 DF eignen sich für den Einbau in Maschinen, Anlagen oder Geräte und sind für den Dauerbetrieb ausgelegt. Ihre wichtigsten Anwendungen sind zum Beispiel Trocknen und Aufheizen, Auftauen, Beschleunigen und Auflösen, Sterilisieren, Glätten, Glänzen, Aktivieren und Lösen, Trennen und Verschmelzen, Schrumpfen,...
All manuals and user guides at all-guides.com Einbauerklärung (im Sinne der EG-Maschinenrichtlinie 2006/42; Anhang II B) Leister Technologies AG, Galileo-Strasse 10, CH-6056 Kaegiswil/Schweiz erklärt hiermit, dass die unvollständige Maschine Bezeichnung Lufterhitzer LE 5000 DF; LE 10000 DF - soweit es vom Lieferumfang her möglich ist - den anwendbaren grundlegenden Anforderungen der EG-Maschinenrichtlinie (2006/42) entspricht.
• Der Lufterhitzer Typ DF darf nur mit Luft bis max. 160 °C / 320 °F versorgt werden. • Luftdurchflussrichtung beachten. • Bei staubhaltiger Luft Leister Edelstahlfilter verwenden. Aufschiebbar auf Gebläseflansch. Bei besonders kriti- schen Stäuben (z.B. Metall-, elektrisch leitende oder feuchte Stäube) müssen spezielle Filter verwendet werden, um Kurzschlüsse im Gerät zu vermeiden.
All manuals and user guides at all-guides.com Schulung • Leister Technologies AG sowie deren autorisierte Service-Stellen bieten kostenlose Kurse im Bereich der Anwendungen an. 3D Zeichnungen • 3D-Zeichnungen sind bei Ihrer Service-Stelle oder auf www.leister.com erhältlich. Zubehör • Es darf nur Leister-Zubehör verwendet werden.
Seite 10
LE 5000 DF; LE 10 000 DF Application The Leister LE 5000 DF and LE 10 000 DF air heaters are suitable for building into machines, installations or appliances and are designed for continuous operation. Their most important applications include; drying and heating, thawing, accelerating and removal, sterilising, smoothing, polishing, activation and dissolving, separating and fusing, shrinking, removal.
All manuals and user guides at all-guides.com Declaration of incorporation (in terms of the EC machinery directive 2006/42; Appendix II B) Leister Technologies AG, Galileo-Strasse 10, CH-6056 Kaegiswil/Schweiz hereby declares the partly completed machinery Designation Air heater Type LE 5000 DF; LE 10000 DF - as far as it is possible from the scope of supply –...
• Observe direction of air flow. • For use in a dusty environment the tool should be fitted with a Leister stainless steel filter on the air intake connection. Where a particularly critical dust problem exists (e.g. metal, electrically charged or damp dust) special filters must be used to avoid short circuiting the tool.
• Accessories at www.leister.com Service and repairs • Repairs should only be carried out by authorised Leister Service Centres. They guarantee a correct and reliable repair service within reasonable period, using original spare parts in accordance with the circuit diagrams...
Seite 14
All manuals and user guides at all-guides.com...
Seite 15
All manuals and user guides at all-guides.com...
