4.2) Alarms / Warnings
These appear on the display during operation and can be accompanied
by a warning sound to provide the operator with tool status notifi cations.
Message Description
LOW BATTERY: replace the battery immediately. When the
battery voltage drops below the minimum safety level, the
BATTERY
tool can no longer be switched on; the tool will be able to
complete any work cycle already in progress
HIGH BATTERY TEMPERATURE: remove the battery and
BATTERY
wait for it to cool
INTERRUPTION OF THE SIGNAL FROM THE NTC TEM-
NTC
PERATURE PROBE OF THE BATTERY: damaged battery,
FAULT
replace the damaged battery.
If the problem persists, please contact Press fi t .
SCHEDULED MAINTENANCE APPROACHING:
39500
500 work cycles remaining before scheduled maintenance.
- 500
Number of work cycles before scheduled maintenance.
SCHEDULED MAINTENANCE REQUIRED: the tool
continues to operate normally but in "maintenance mode"
40001
Number of work cycles carried out that exceeds the pre-set
+ 1
threshold number.
Send to Press fi t for full inspection (Ref. to § 5.3)
START-UP RELEASE: the tool is operating in "maintenance
TOUCH TO UNLOCK
mode". The operator must press the capacitive touch button
each time the tool is to be started. This is the only way to
release the electronic lock and start the motor (Ref. to § 5.3) .
4.3) Error messages
These appear on the display during operation, combined with a beep and
fl ashing LEDs to notify the operator of procedural or operational errors.
Message Error description
Pressing cycle error.
Pressure release button (7)
ERROR
activated before reaching
the set parameters (Force/
Pressure).
Motor current absorption
error.
The tool stops working.
001
Pressure transmitter output
002 voltage out of set range.
Failure to reach calibrated
003 pressure within 30 s of con-
tinuous tool operation.
Battery overload with safety
device activated.
The tool stops working.
004
NOTE: Errors 00.. displayed for about 30 seconds before being reset, but will display repea-
tedly in the event of permanent anomalies.
GB
4.4) Enabling/disabling the LED Worklights
To switch on/off during tool operation:
4.5) Return to original factory settings
To recover the tool's initial factory settings:
Check that every part of the tool is intact before starting any maintenance
work.
The tool is robust, completely sealed and does not require any particular
attention; to maintain in good working order, observe the following
precautions:
Solution
5.1) Careful cleaning
Repeat the pressing cycle and Dust, sand and dirt can be dangerous to any hydraulic equipment. After
wait for the motor to switch
each day of use, the tool must be cleaned with a clean cloth, taking care
off automatically.
to remove all dirt residue, especially any close to moving parts.
Avoid the accumulation of dirt on the thrust rollers and grease them regularly.
Regularly lubricate the locking pin with light oil (Fig. p).
Wait for the display to switch
Make sure that the motor ventilation system is free from dust and dirt.
off (60 s) or remove and
reinsert the battery, then
Do not use hydrocarbon products to clean rubber parts.
restart to tool. In the event
of frequent reoccurrence,
contact Press fi t.
5.2) Storage case
Repeat the work cycle. In the
When not in use, store the tool in a dry place inside the sealed plastic
event of frequent reoccur-
storage case, to protect it from accidental knocks and dust exposure.
rence, contact Press fi t .
The ideal battery storage temperature is between 10°C and 30°C.
Repeat the work cycle. In the
The Press fi t PCS1 storage case is designed to hold the tool and accessories;
event of frequent reoccur-
the case size is 714x466x179 mm and it weighs 4.1 kg.
rence, contact Press fi t .
Wait for the display to switch
off (60 s) or remove and
reinsert the battery, then
restart to tool. In the event
of frequent reoccurrence,
contact Press fi t.
LED
Select the LED option from the "main menu".
ON
LED Hold down button (6) until a long beep to confi rms
OFF
selection.
Select the RESET option from the "main menu".
RESET
Hold down button (6) until a long beep to confi rms
SW S1K07202
selection.

5. MAINTENANCE

Remove the battery from the tool before carrying out any
type of maintenance.
