EN: Installation instructions
Figure 1. Removing the sensor cover.
1
Cover.
2
Slot.
3
Cover screw mounting hole.
Figure 2. Battery insertion.
4
+ end of battery.
Figure 3. Mounting holes.
5
Mounting hole for T screw.
6
Mounting hole for L screw.
Figure 4. Sensor and magnet alignment.
7
Alignment marks.
Figure 5. External contact wiring.
8
Door/Window Sensor.
9
4.7 Kohm.
10
EOL 4.7 Kohm.
11
Contacts.
Figure 6. Input selection jumper.
12
Reed 1.
13
Reed 2.
14
Input selection jumper.
15
Reed 1 = Top two pins covered.
16
Reed 2 = Bottom two pins covered.
17
External contact = Jumper removed.
Introduction
This is the GE 433 Door/Window Sensor Installation Instructions .
You can install the sensor on doors, windows, and other objects
that open and close. The sensor transmits signals to the control
panel when a magnet mounted near the sensor is moved away
from or closer to the sensor. The sensor is equipped with a wall
and cover tamper for additional security.
Installation guidelines
Use the following installation guidelines:
•
Mount the sensor on the door frame and the magnet on the
door. If the sensor is used on double doors, mount the sensor
on the least-used door and the magnet on the most-used
door.
•
If possible, locate sensors within 30 m (100 ft.) of the panel.
While a transmitter may have a range of 150 m (500 ft.) or
more out in the open, the environment at the installation site
can have a significant effect on transmitter range. Sometimes
a change in sensor location can help overcome adverse
wireless conditions.
•
Make sure the alignment arrow on the magnet points to the
alignment mark on the sensor.
•
Place sensors at least 12 cm (4.7 in.) above the floor to avoid
damaging them.
•
Avoid mounting sensors in areas where they will be exposed
to moisture or where the sensor operating temperature
range of 0 to 49°C (0 to 120°F) will be exceeded.
2 of 9
•
If possible, mount directly to a stud. If a stud is not available,
use plastic anchors.
•
Avoid mounting the sensor in areas with a large quantity of
metal or electrical wiring.
•
Only one input can be used at any given time.
•
End-of-line (EOL) resistors must always be connected to the
external contact terminals. The sensor is shipped with a
single EOL resistor already installed. The single resistor must
be removed if the external contact is going to be used. See
External contact wiring on page 2 for proper wiring details.
•
Mount sensors with screws, not double-sided tape.
Materials needed
You will need the following tools and materials:
Two ∅6 x 1.00 in. PPH (Phillips pan head) screws and two
•
plastic anchors for mounting the sensor (included).
Two ∅6 x 0.625 in. PPH screws for mounting the magnet
•
(included).
One ∅4 x 0.250 in. PPH screw to secure the sensor cover to
•
the sensor base (included).
•
External contact end-of-line (EOL) resistors (included).
•
Phillips screwdriver.
Caution:
You must be free of all static electricity when handling
electronic components. Touch a grounded, bare metal surface
before touching a circuit board or wear a grounded wrist strap.
Programming
The following steps describe general guidelines for programming
(learning) the sensor into panel memory. Refer to the specific
panel/and or receiver's documentation for complete
programming details.
1.
To remove the sensor cover, press a small screwdriver into
the slot on the end of the sensor while lifting the cover (see
fig. 1).
2.
If required, insert the battery into the battery holder,
observing correct polarity (see fig. 2).
3.
Set the panel to program mode.
4.
Proceed to the Learn sensors menu.
5.
Press and release the tamper switch on the sensor until the
panel responds.
6.
Select the appropriate sensor group and sensor number.
7.
Exit program mode.
Verify RF communication
Before mounting the sensor, verify that the sensor mounting
location provides good RF communications to the panel.
To verify, do the following:
1.
Put the panel/receiver into sensor test mode.
2.
Take the sensor to the mounting location.
3.
Hold the magnet next to the arrow on the end of the sensor
and then pull the magnet away from the sensor.
P/N 466-2285B • REV 04.00 • ISS 04MAR09
