Description and characteristics of the device
sed The set consists of the medolight device and the AC adapter . The device is
used to radiate with light emitted by LED in the range of visible light and inf-
rared light wavelengths .
lled
ible

Principle of operation

y of
The medolight BluDoc device is equipped with a matrix consisting of 171 blue
im- LEDs (emitting light with wavelength of 470nm) and 36 infrared LEDs (emitting
e for
infrared light with a wavelength of 940nm) . The device is powered up by a
built-in battery which can be charged using the AC adapter included with the
device . It is possible to use the device while the battery is being charged . Ho-
with
wever, it increases the charging process . The unit is controlled by a micropro-
ains
cessor . You can select one of five programs and one of five radiation durations .
The processor controls the battery charging status and indicates the need of
ting
charging .
hem

How to use

the-
The medolight devices are an important part of a daily body care .
ater
mo-
1. The device can be used 1-2 times a day for 1-2 cycles (1 cycle from 5 to
25 minutes) . The device can be used at any time when you have time and
opportunity to enjoy biostimulation . According to specialists the best re-
con-
sults are achieved when using medolight device in the morning and eve-
ning .
ma-
s to 2. Before using the medolight device, clean and disinfect the area subjected
to radiation .
sho-
3. Relax and direct the stream of light to the place undergoing treatmen
from a distance of about 5 mm . While using the device, make sure that, if
old possible, the stream of light does not move . For large surfaces you should
gradually direct the stream to next areas by moving the device to the non-
well
-radiated area after radiating the previous one .
nt if
afe

Device Operation

od.
su-
1. Activation
the
Press and hold the ON/OFF button by at least 2s . Bottom icon bar (5-25) will
indicate the battery status for 2 s – number of lit icons indicates the battery
charging status . Then, program selection icon will light up (P1-P5) along
with the time selection icon (5-25), in line with last settings before stand-by
ctor
mode .
2. Program selection
ANT
Pressing the „P" button (PROGRAM) changes the radiation program signal-
EPI-
led by lighting the appropriate icon with red light:
LSE
BY A
P1 –continuous light
P2 – pulsating light 10 Hz
P3 – pulsating light 600 Hz
P4 – pulsating light 3000 Hz
P5 – pulsating light 8000 Hz
