4. TRANSMITTER RW16B
The RW16B hand-held radio microphone features the following controls:
1.
mini-XLR connector
2.
on/off LED
3.
on/off button
4.
battery cover
5.
microphone attenuation selector (2 positions: 0 dB / -10 dB)
RW16B sync procedure:
•
connect the receiver's power supply cable to a power outlet. Press the on/off button for about 1"
to turn it on.
•
open the battery cover and insert the supplied batteries, respecting the indicated polarity. Press
the on/off button for about 3".
•
align the IR ports as shown
•
press the ASC sync button on the receiver. The display starts flashing and stops once the operation
has been completed.
RW16 MS/BS
4
2
1
2
3
4
2
Cod. 420120321 REV. 1.0
19
