OVERVIEW
GB
Limit DDB digital dial indicator allows quick and accurate measurement. Can work under
moist conditions thanks to the IP rated housing.
FEATURES
• Manufacture according to DIN 878
• Absolute and incremental measurement
• Zero setting at any position
• mm and inch switchable
• With tolerance and preset function
• with a flat cover and cover with lug
• IP67 housing

SPECIFICATION

Model
Measuring range
Resolution
Accuracy
POSITIONS
9
7
2
3
FUNCTION
Height measurement
2
DDB 12
0 ~ 12.7 mm/0.5"
0.001 mm/0.00005"
0.007 mm/0.0003"
11
5
10
1
6
8
4
Flatness measurement
1. LCD display
2. Clamping rod
3. Measuring shaft
4. Measuring head
12 5. Data output port
6. Zero/On/Off key
7. mm/inch/ABS key
8. Preset key
9. Tolerance setting key
10. +/- key
11. Dust cap
12. Back lug
DDB 25
0 ~ 25.4 mm/1"
0.001 mm/0.00005"
0.008 mm/0.0003"
Radial measurement
