COMPACTCHEF 480 G
A LID HANDLE
Pos. Art. Nr. Description
A1 18.370.76 Teflonwasher
A2 18.370.62 Washer
A3 18.370.04 Screw
B LOGO PLATE
Pos. Art. Nr. Description
B1 18.370.48 Nut
B2 18.371.02 Washer
B3 18.371.03 Teflonwasher
C CONTROL PANEL + VALVE
Pos. Art. Nr. Description
C1 18.370.25 Screw
C2 18.370.62 Washer
C3 18.370.76 Teflonwasher
C4 18.370.23 Screw
D ELECTRODE
Pos. Art. Nr. Description
D1 18.370.23 Screw
2 OUTDOORCHEF.COM
B
B
B
C
B
B B
B
DECKELGRIFF
Beschreibung
U-Scheibe Teflon
U-Scheibe
Schraube
C
C
D
C C
LOGOPLATTE
C
C
Beschreibung
C
Mutter
U-Scheibe
U-Scheibe Teflon
BEDIENUNGSKONSOLE + VENTIL
Beschreibung
Schraube
D
D D
E
U-Scheibe
D
U-Scheibe Teflon
D
D
Schraube
D
ELEKTRODE
Beschreibung
Schraube
E E
E
E
E
E
E
A
B
B
C
C
D
C1 C2 C3
D
E
D1
OUTDOORCHEF.COM
A1
A2
A3
B1
B2
B3
C4
