Installing Brackets - Wood Stud
Instale Rieles - Viga de Madera
Installation des supports - Montant en bois
Halterungen installieren – Holzrahmenwerk
1
32"
81.28 cm
TYP.
2
J
(12X)
3
5/32" dia. x 2-1/2" deep
Ø 4mm x 6.35cm
J
(12X)
4
M (6X)
J
X
5
G
J
M (6X)
X
Installing Brackets - Concrete
Instale Rieles - Concreto
Installation des supports - Béton
Halterungen installieren – Beton
1
2
3/8" dia. x 2-1/2" deep
Ø 10mm x 6.35cm
3
4
5
J
6
32"
81.28 cm
TYP.
J
(12X)
(12X)
L (12X)
J
M (6X)
M (6X)
G
