- Seite 1 Large Extend Mount VEL-B Grande Grand Groß Support Extensible Halterung, Ausziehbar Suporte Extensible Screen Size Range: Max Weight Load - Monitor Mount: Hole Pattern Range: 37 - 52 in. 120 lbs / 54 kg VESA® 200 x 100 94 - 132 cm...
- Seite 2 Concrete only Instrumentos Tools Instruments Werkzeuge 3/8” or 10mm 5/32 or 4mm...
-
Seite 3: Parts List
Brick Wall installation. Preview all steps before beginning. Should any portion of these instructions be unclear, contact us directly at 800-582-9595 or by email at support@thinkvp.com for assistance. Do not attempt to assemble this Vantage Point Mount System, if you have any doubts as to its proper assembly and installation. - Seite 4 Installation and Assembly TV Mounting Hardware Kit Hardware Kit TV que Monta equipo de Hardware Instalación y equipo de Hardware de Asamblea Installation et kit de Matériel d’Assemblage TV Montant le kit de Matériel Fernsehen, das Hardware-Bastelsatz Besteigt Installierung und Zusammenbau-Hardware-Bastelsatz M4 X 16MM PHILLIPS HEAD SCREW YELLOW #14 X 2-1/2”...
- Seite 5 Clavo de Madera Clou de Bois Wood Stud Holz Knopf 16” 40.64 cm mark @ 16” 16” typical 40.64 cm 40.64 cm Ø 5/32” X 2-1/2” DEEP Ø 4mm X 6.35 cm Ø 5/32” X 2-1/2” DEEP Ø 4mm X 6.35 cm Go to Install Monitor Step Vaya para Instalar Paso de Monitor...
- Seite 6 Concreto Béton Concrete Beton mark @ 16” 40.64 cm Ø 3/8” X 2-1/2” DEEP Ø 10mm X 6.35 cm Ø 3/8” X 2-1/2” DEEP Ø 10mm X 6.35 cm Go to Install Monitor Step Vaya para Instalar Paso de Monitor Allez Installer le Pas de Moniteur Gehen Sie, um Monitor-Schritt Zu installieren...
- Seite 7 Instalar el Monitor de Monte Installez le Mont de Moniteur Install Monitor Installieren Sie Monitor-Gestell Back View...
-
Seite 8: Back View
Ajustes Ajustages Adjustments Anpassungen Nivel Niveau Niveau Back View Level Inclinación Pencher Neigung Back View Tilt... - Seite 9 Dirección de Alambre Administration Métallique Wire Management Leitungsmanagement 1X @ 42 in - 106 cm Back View...
- Seite 10 VANTAGE POINT PRODUCTS CORP. P.O. BOX 2485 SANTA FE SPRINGS CA 90670 USA TEL: 1.800.582.9595 FAX: 562.946.3898 EMAIL: support@thinkvp.com CANADA TEL: 905.607.9994...
