Configuring Wired Device Settings
Network Type
The Network type can be selected as Wired or Wireless
Device, in accordance with the active connection to the
TV set. Select this as Wired Device if you are connecting
via an ethernet.
Configuration Status
This section displays the status of the connection.
IP Address
If an active connection is available, the IP address will
be displayed on this section. If you want to configure an
IP address preferences, press the Green button and
switch to the advanced mode.
Configuring Wired Network Settings in
Advanced Mode
After pressing the Green button, the advanced mode
will be available. While in advanced mode, press the
Red button to edit settings. When finished, press OK
to save, Press Return/Back to exit.
Wireless Connectivity
To Connect to a Wireless Network
IMPORTANT: "Veezy 200" USB dongle (not supplied)
is required to use wireless network features.
The TV cannot connect to the networks with a hidden
SSID. To make your modem's SSID visible, you should
change your SSID settings via the modem's software.
To Connect to a wireless LAN, you should perform
the following steps:
1. Ensure that Nero Media Home software is
installed to your PC (for DLNA function).
2. Then connect the wireless adaptor (not supplied)
3. to one of the USB inputs of the TV.
4. To configure your wireless settings please refer
to the Network settings section in this manual.
(not supplied)
A Wireless-N router (IEEE 802.11a/b/g/n) with
simultaneous 2.4 and 5 GHz bands is designed to
increase bandwidth. These are optimized for smoother
and faster HD video streaming, file transfers and
wireless gaming.
• Use a LAN connection for quicker file sharing
between other devices like computers.
• The frequency and channel differ depending on the area.
• The transmission speed differs depending on the
distance and number of obstructions between the
transmission products, the configuration of these
products, the radio wave conditions, the line traffic
and the products that you use. The transmission may
also be cut off or may get disconnected depending
on the radio wave conditions, DECT phones or any
other WiFi 11b appliances. The standard values of
the transmission speed are the theoretical maximum
values for the wireless standards. They are not the
actual speeds of data transmission.
• The location where the transmission is most effective
differs depending on the usage environment.
• The Wireless LAN adaptor (not supplied) should be
connected directly to the TV's USB port. USB hubs
are not supported.
• The Wireless LAN feature supports 802.11 a,b,g &
n type modems. It is highly recommended that you
should use the IEEE 802.11n communication protocol
in order to avoid any possible problems while watching
videos.
• Use the other USB input, if you experience problems
with audio/video performance.
• You must change your modem's SSID when there are
any other modems around with the same SSID. You
can encounter connection problems otherwise. Use
a wired connection if you experience problems with a
wireless connection.
Configuring Wireless Device Settings
To enable Wi-Fi features, plug in the Wi-Fi dongle (not
supplied) to one of the USB ports. Open the Network
English - 40 -
