SPECIFICATION

Drive:
Max. Torque:
Max. Pressure:
Average air consumption:
Max. Speed:
Air inlet:
Noise:
Vibration:
Weight:
Length:

IMPORTANT SAFETY INFORMATION

CAUTION!
Read, understand and follow all instructions and warnings before first use of this air ratchet. Disregard
might cause property damage and/or personal injury as well as expiration of warranty.
Grease the air ratchet with 4 to 5 drops of air tool lubricant before each use.
Only connect with air pressure systems that provide an appropriate air pressure as well as sufficient
air capacity (L/min) for this tool.
1. Make sure that the tool is in OFF-position, when connecting it with the air pressure system.
2. Always wear certified safety gloves and goggles. Stirred up dust might make wearing a suitable
respirator mask a necessity.
3. Use air tool accessories only (e.g.: Do not use ordinary bits for an air driven impact wrench, but
special impact bits)!
4. Cut the ratchet from the air supply before you install accessories, service the tool or when not in
use.
5. Always stick to your common sense! Do not wear loose clothes or jewelry which might be caught
up in revolving parts because this might lead to injuries. Operate the tool in a safe distance from
yourself and others.
6. Follow manufacturer's notes when installing regulators, filters and other accessories.
SW-Stahl und Werkzeugvertriebs GmbH
L e v e k r u s r e t S a r s s e 6 5
D 4 - 2 8 9 7 R e m s c h e d i
3/8" Reversible Air Ratchet
3/8"
34 Nm (25 ft-lbs)
6.2 Bar (90psi)
595 L/min (21 cfm)
265 U/min
1/4"
LpA= 94.69 dB(A)
LwA= 105.69 dB(A)
ahd= 3.54 m/s²
K= 1.5 m/s²
0,6 Kg
175 mm
Tel. +49 (0) 2191 / 46438-0
F ax +49 (0) 2191 / 46438-40
- E M a : l i n i o f @ s w s a t l h d . e
Art. 3239
