Offgridtec Remote Meter Bedienungsanleitung Seite 31

NOTE:
1) When the battery type is sealed, gel, flooded, the adjusting range of equalizing duration is 0 to180min, and
boost duration is 10 to180min.
2) The following rules must be observed when modifying the value of the parameter in user battery type(factory
default value is the same as sealed type):
a) Over Voltage Disconnect Voltage > Charging Limit Voltage ≥ Equalize Charging Voltage ≥ Boost Charging
Voltage ≥ Float Charging Voltage > Boost Reconnect Charging Voltage.
b) Over Voltage Disconnect Voltage > Over Voltage Reconnect Voltage
c) Low Voltage Reconnect Voltage > Low Voltage Disconnect Voltage ≥ Discharging Limit Voltage.
d) Under Voltage Warning Reconnect Voltage > Under Voltage Warning Voltage ≥ Discharging Limit Voltage.
e) Boost Reconnect Charging voltage > Low Voltage Disconnect Voltage.
Lithium Battery Control Voltage Parameters
The parameters are in the 12V system at 25 ºC; please double the values in the 24V system.
Voltage parameter
Over Voltage Disconnect Voltage
Charging Limit Voltage
Over Voltage Reconnect Voltage
Equalize Charging Voltage
Boost Charging Voltage
Float Charging Voltage
Boost Reconnect Charging Voltage
Low Voltage Reconnect Voltage
Under Voltage Warning Reconnect Voltage
Under Volt. Warning Voltage
Low Volt. Disconnect Voltage
Discharging Limit Voltage
The following rules must be observed when modifying the parameter values in User for the lithium battery.
A. Over Voltage Disconnect Voltage>Over charging protection voltage(Protection Circuit Modules(BMS))+0.2V
B. Over Voltage Disconnect Voltage>Over Voltage Reconnect Voltage＝Charging Limit Voltage ≥ Equalize Charging
Voltage＝Boost Charging Voltage ≥ Float Charging Voltage>Boost Reconnect Charging Voltage;
C. Low Voltage Reconnect Voltage>Low Voltage Disconnect Voltage ≥ Discharging Limit Voltage;
D. Under Voltage Warning Reconnect Voltage>Under Voltage Warning Voltage≥ Discharging Limit Voltage;
E. Boost Reconnect Charging voltage> Low Voltage Reconnect Voltage;
F. Low Voltage Disconnect Voltage ≥ Over-discharging protection voltage
(BMS)+0.2V.
The voltage parameters of the lithium battery can be set, but you must refer to the voltage parameters of lithium battery BMS.
The required accuracy of BMS shall be at least 0.2V. If the deviation is higher than 0.2V, the manufacturer will assume no liability for any system
malfunction caused by this.
Allgemeine Informationen
Offgridtec GmbH
Im Gewerbepark 11
84307 Eggenfelden
WEEE-Reg.-Nr. DE37551136
Battery type
Kontaktinformation
Tel: 08721-91994 00
Email: info@offgridtec.com
Web: www.offgridtec.com
GFR: Christian & Martin Krannich
Offgridtec Remote Meter
LiFePO (4S) Li-NiCoMn (3S)
4
15.6V 13.5V
14.6V 12.6V
14.5V 12.5V
14.5V 12.5V
14.5V 12.5V
13.8V 12.2V
13.2V 12.1V
12.4V 10.5V
12.5V 11.0V
12.0V 10.5V
11.0V 9.3V
10.8V 9.3V
Konto Sparkasse Rottal-Inn
Konto: 10188985
BLZ: 74351430
IBAN: DE69743514300010188985
BIC: BYLADEM1EGF (Eggenfelden)
User
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
9 - 17V
;
※
