Operation

Turn on:
By activating the E-Bikes battery, the lamp will turn on automatically.
After turning it on, the lamp lights either with daytime running light or low
beam (depending on the ambient light).
Light sensor:
The light sensor is positioned behind the lens and meassures the ambient
light in a 5 sec. frequency as long as daytime running light is activated.
This can be perceived visually. When it's dark enough, the light switches to
low beam automatically.
Note: There's no sensor controlled switch from low beam to daytime
running light.
Turn off:
To turn off the lamp, keep the button pressed for about 2 seconds. You can
only turn off the lamp by pushing the big button of the remote control.
Customizing the settings at the lamphead:
Keep the small button pressed (let go to select) until the lamp lights up as
many times you'll need it to. Note: It will take about 6 sec. until the program-
ming starts.
Keep the button Available
pressed settings
(let go to
until lamp ...
select)
Lights up 1x
ECO mode
Lights up 2x
Reset to factory settings
(High beam: 14W, Low beam: 8W, Daytime running light: 2W)
High beam: 8W
Low beam: 5W
Daytime running light: 2W
Bluetooth remote control
Operation of the Bluetooth remote control
Small button:
- Short press: Activate low beam
- Keep it pressed for about 2 sec.: Activate daytime running light
- When high beam is activated: Switch to low beam is possible
Big button:
- When daytime running light is activated: Switch to low beam is possible
- When low beam is activated: Switch to high beam is possible
- When high beam is activated: Switch to low beam is possible
Movement sensor:
To protect the button cell of the remote control from getting discharged
too quickly, the sensor will cut the connection to the remote control, after
not recognizing any movement for more than 5min. To connect it again, the
sensor needs to recognize a strong movement.
