• (Optional/CN2A only) USB keyboard. For a list of supported
keyboards, see the CN2A Mobile Computer User's Manual
(P/N 075464).
Installing the Modem Dock
1 Place the modem dock on a flat, stable, and clean surface that
is within 1.5 m (5 ft) of an AC outlet.
2 Connect the power supply to the Power port on the back of
the modem dock.
Keyboard USB
port port
3 (Optional) The keyboard port may be covered by a label that
indicates the CN2B does not support this port. You may
remove this label if you have a CN2A and you plan to connect
a USB keyboard, as described in Step 9.
4 Connect the country-specific power cord to the power supply.
5 Connect the other end of the country-specific power cord to
an AC power outlet. The green Power light on the front of the
modem dock turns on.
4
Phone Power
port port
