Application program
OPTO-RS test
This program is available free of charge on the Sylvac web site or at your distributor. It is a Visual Basic
program with all source files for testing connections and transmission.
Winwedge
WinWedge is designed to transfer any data obtained using Sylvac measuring instruments to a computer
application program running under Windows.
Different versions of the Winwedge program are available (light, professional, Windows CE). For more
information contact TAL Technologies, Inc. or consult the www.taltech.com web site.
A light version of WinWedge named GageWedge is available free of charge on the Sylvac web site or at your
distributor. However, this program version has restrictions regarding data transfer from the instrument.
Hyperterminal
This program is available as standard with Windows 95, 98, 2000 and Me (millenium). It can only be used with a
simplex cable and as data transmission from the instrument.
Parameter:
- In menu [connect to], select
– In menu [parameter], select
- In menu [port parameters], select :

Specifications

Connection ......................................................... RS232 compatible, Dsub 9p female or open
Power supply...................................................... from periphery, with TXD, DTR and RTS lines
Data transmission parameters ............................. 4800 bds, even parity, 7 data bits, 2 stop bits
Max. cable length................................................ 15 m according to IEC standards
Number of transmissions /sec.............................. 4-8/sec (depends on the instrument connected)
Data transmission format..................................... [ Sign ¦ E1-En ¦ "." ¦ F1-Fn ¦ CR ]
[connection using]
[terminal keyboard]
[emulation]
[bits/sec]
[data bits]
[parity]
[stop bits]
[Flux control]
[ "ERR" ¦ Number ¦ CR ]
Directed to {n}
Suppr.
ANSI
4800
7
Even
2
None
15
