Performance In Lighting LASER+ Bedienungsanleitung Seite 9
1 OPTION A
DRILL
1
4 x
4x Ø 8.5
134
2
4
LASER+ 20 : DRIVER BOX DALI WIRING
CABLE:
H07RN-F 5G 1,5 mm
Max Ø 14,5 mm
OUT
Max 100 m
-
+
-
+
MODULE 2
MODULE 1
LASER+ 30 : DRIVER BOX DALI WIRING
CABLE:
H07RN-F 7G 1,5 mm
Max Ø 17,5 mm
OUT
Max 100 m
-
+
-
+
-
+
MODULE 3
MODULE 2
MODULE 1
4
2 Nm
4
NOT INCLUDED
CABLE:
Min H05RN-F
IN
IN
N
L
DA DA
DA DA
IN
IN
L2
L1
RELAUNCH
CABLE:
Min H05RN-F
IN
IN
N
L
DA DA
DA DA
IN
IN
L2
L1
RELAUNCH
5
CLOSE
1 OPTION B
2
2 x
4 x
B
C
1
LASER+ 20 : DRIVER BOX DMX WIRING
CABLE:
H07RN-F 5G 1,5 mm
Max Ø 14,5 mm
OUT
Max 100 m
-
+
-
+
-
MODULE 3
MODULE 2
MODULE 1
LASER+ 30 : DRIVER BOX DMX WIRING
CABLE:
H07RN-F 7G 1,5 mm
Max Ø 17,5 mm
OUT
Max 100 m
-
+
-
+
-
MODULE 3
MODULE 2
MODULE 1
CH 33 7,5 Nm
IN
OUT
IN/OUT
CH 42
CONTROL
CH 22
2,5 Nm
A
-
6
2 x
M8x20
B
-
2 x
A
M8-CH13
C
-
2 x
2 x
Ø8
+
S
S
B B A A
+
S
S
B B A A
8 Nm
3107619 | ED. 01 | 09 - 2020
CABLE:
Min H05RN-F
IN
IN
N
L
L2
L1
CABLE:
Min H05RN-F
IN
IN
N
L
L2
L1
9
