Performance In Lighting LASER+ Bedienungsanleitung Seite 2

LASER+ 10
Ø 22
45
203 43.5
81
545.5
OPTION A
1
100 Nm
A
B
RECOMMENDED
A
-
1 x
M20x30-CH30
B
-
1 x
Ø60x22
2
4A
ON/OFF WIRING
LINE
L
MARRONE/BROWN
NEUTRAL
N
BLU/BLUE
L N
GROUND
GIALLO-VERDE
YELLOW-GREEN
8 mm
H07RN-F
30 mm
3G 1÷1,5 mm
Ø9÷16 mm
20 mm
2
3107619 | ED. 01 | 09 - 2020
Max 24 Kg
NO
UP LIGHT
RECOMMENDED
A
-
2 x
M20x30-CH30
B
-
2 x
Ø60x22
1 4 x
4 x
NO
M5x12-CH8
4B
DALI WIRING
L
MARRONE/BROWN
NEUTRAL
N
BLU/BLUE
L N DA DA
GROUND
GIALLO-VERDE
YELLOW-GREEN
8 mm
DA
H07RN-F
BIANCO/WHITE
30 mm
5G1÷1,5 mm
2
DA
Ø9÷16 mm
20 mm
BIANCO/WHITE
OPTION B
B
A
100 Nm
B
A
OPEN
2
5
LINE
2,5 Nm
DALI
DALI
OPTION C
100 Nm
A
Min 250 mm
B
RECOMMENDED
A
-
1 x
M20x30-CH30
B
-
1 x
Ø60x22
3
6
CLOSE
OPEN
